| Ref | Part Number | Description |
|---|
| 1 |
532434487 |
DECK.SVC.WELDMNT.30"419272X418 This part replaces 532442048. Price: $219.99 |
| 1 |
94-3307 |
PAD-PEDAL, TRACTION Price: $12.11 |
| 2 |
593824001 |
STUD.W/"D"ANTI-ROTATION This part replaces 532195161. Price: $3.99 |
| 2 |
94-3591 |
DISCONTINUED Price: Call Us |
| 3 |
596135701 |
GSPW Nuts This part replaces 873900500. Price: $2.99 |
| 3 |
94-3308 |
PAD-PEDAL, TRACTION Price: $8.96 |
| 4 |
32121-6 |
PIN-ROLL, SLOTTED Price: $0.28 |
| 4 |
532417645 |
BRACKET.CLUTCH.CABLE Price: $4.99 |
| 5 |
28-5220 |
FRICTION WHEEL ASM Price: $108.15 |
| 5 |
817000510 |
BOLT.5/16HEX.WHS.HD Price: $4.99 |
| 6 |
5-7570 |
WASHER-FLAT Price: $6.19 |
| 6 |
532418863 |
ARMS.SUSP.MOWER.REAR.SRD Price: $17.99 |
| 7 |
92-5093-03 |
ARM-PIVOT ASM This part replaces 92-5093. Price: $129.11 |
| 8 |
583379801 |
ARM.IDLER.30"SRD This part replaces 532420252. Price: $7.99 |
| 8 |
92-5537 |
PIN-PEDAL, TRACTION Price: $41.17 |
| 9 |
3272-10 |
PIN-COTTER Price: $0.25 |
| 9 |
532199092 |
SPACER.RETAINER Price: $5.99 |
| 10 |
256-156 |
BUSHING-FLANGE Price: $12.99 |
| 10 |
817000616 |
SCREW 3/8-16X1 Price: $5.99 |
| 11 |
256-116 |
BUSHING-FLANGE Price: $3.52 |
| 11 |
532137729 |
SCREW.1/4-20X5/8 Price: $3.99 |
| 12 |
3256-24 |
WASHER-FLAT Price: $0.28 |
| 13 |
596136101 |
GSPW Bolts This part replaces 872110612. Price: $2.99 |
| 13 |
92-5721 |
LINK-TRACTION Price: $10.99 |
| 14 |
3272-6 |
PIN-COTTER Price: $0.25 |
| 14 |
597024901 |
Keepers This part replaces 532156085. Price: $3.99 |
| 15 |
593787801 |
PULLEYS This part replaces 532146763. Price: $27.99 |
| 15 |
92-5536-03 |
TUBE-CONTROL, PUMP ASM This part replaces 92-5536. Price: $203.02 |
| 16 |
3220-3 |
NUT-HJ Price: $0.28 |
| 16 |
532409149 |
NUT.HEX.FLANGE.3/8-16.LOCKNUT This part replaces 873900600. Price: $3.99 |
| 17 |
323-9 |
SCREW-HH Price: $1.29 |
| 17 |
596134801 |
Nuts This part replaces 532400234. Price: $1.00 |
| 18 |
2411-36 |
BEARING-END, ROD Price: $32.13 |
| 19 |
256-219 |
BUSHING Price: $7.59 |
| 19 |
585323901 |
BEARING.MANDREL.TOP.EXTENDED Price: $12.99 |
| 20 |
584953901 |
BOLT.HEX.WASHR.HED.313-18X1.19 This part replaces 532173984. Price: $3.99 |
| 20 |
92-5094-03 |
ARM-TRACTION This part replaces 92-5094. Price: $117.79 |
| 21 |
3296-39 |
NUT-LOCK, NI Price: $2.29 |
| 22 |
596481401 |
Pulleys This part replaces 532175820. Price: $22.99 |
| 22 |
92-5075 |
SHAFT-PEDAL, TRACTION Price: $41.09 |
| 23 |
32128-49 |
NUT-HHF Price: $1.04 |
| 23 |
599972501 |
BOLT This part replaces 817490628. Price: $2.99 |
| 24 |
32128-56 |
NUT-HF Price: $1.09 |
| 24 |
596134901 |
GSPH This part replaces 819132012. Price: $2.99 |
| 25 |
3230-2 |
BOLT-CARR Price: $0.47 |
| 25 |
529311701 |
KEEPER, BELT, BLACK This part replaces 532420253. Price: $4.99 |
| 26 |
583481101 |
COVER.ASM.MANDREL.30" This part replaces 532420255. Price: $49.99 |
| 26 |
92-5534 |
SHAFT-PEDAL, TRACTION Price: $55.59 |
| 27 |
532419271 |
V-BELT.DRIVE.MOWER.30" Price: $49.99 |
| 27 |
92-5077 |
BRACKET-FOOTREST Price: $10.24 |
| 28 |
32128-44 |
NUT Price: $2.69 |
| 29 |
593885101 |
Rods This part replaces 532420895. Price: $5.99 |
| 29 |
92-5532 |
LINK-TRACTION Price: $75.52 |
| 30 |
92-5514-01 |
FOOTREST ASM This part replaces 92-5514. Price: $37.73 |
| 31 |
92-5750 |
PAD-FOOTREST Price: $11.26 |
| 32 |
532197251 |
SPRING.MOWER.DRIVE.ELECTRIC Price: $9.99 |
| 33 |
587819701 |
KIT.MANDREL.NONGREASE.TALL This part replaces 532187281. Price: $49.99 |
| 34 |
587819701 |
KIT.MANDREL.NONGREASE.TALL This part replaces 587256501. Price: $49.99 |
| 35 |
532419274 |
BLADE.MOWER.BAGGING.30" Price: $29.99 |
| 38 |
532196539 |
BOLT.SHOULDER Price: $5.99 |
| 39 |
532193003 |
BOLT.WASHER.ASM.7/16-2 This part replaces 584309301. Price: $6.99 |
| 43 |
525568002 |
PULLEY.MANDREL 6.5" PULLEY This part replaces 532416877. Price: $24.99 |
| 72 |
583364501 |
CHUTE.UPPER.SRD.30R" This part replaces 532417236. Price: $59.99 |
| 73 |
532425274 |
CHUTE.LOWER.SRD.30R" Price: $69.99 |
| 74 |
532124670 |
RETAINER-SPRNG RB Price: $5.99 |
| 76 |
532415598 |
PORT.WASHOUT Price: $6.99 |
| 78 |
583394901 |
GUARD.DECK.SRD.ARM.CLUTCH This part replaces 532422566. Price: $9.99 |
| 79 |
596134101 |
Screws This part replaces 532142432. Price: $2.99 |
| 80 |
532423062 |
PALNUT 1/4 Price: $2.99 |
