| Ref | Part Number | Description |
|---|
| 1 |
114-5422 |
ROLLER-SHOULDER, PLASTIC Price: $525.86 |
| 2 |
114-5403 |
SHAFT-ROLLER, FRONT Price: $82.00 |
| 2 |
532149723 |
MUFFLER.TWIN.CYL.LOW.TONE Price: $49.99 |
| 3 |
114-3717 |
SEAL-OIL Price: $2.77 |
| 4 |
112-5290 |
BEARING-STEEL, STAINLESS Price: $12.64 |
| 5 |
112-7494 |
SEAL Price: $6.37 |
| 6 |
114-5411 |
NUT-LOCK, BEARING Price: $24.46 |
| 7 |
302-5 |
FITTING-GREASE Price: $0.59 |
| 9 |
532194319 |
KEEPER.BELT.ENGINE.3.25 Price: $7.99 |
| 12 |
532405140 |
PULLEY.ENGINE.5.0.PD Price: $54.99 |
| 15 |
583462301 |
TANK ASM.REAR.2.5GA.DAPCO.E10 This part replaces 532418179. Price: $89.99 |
| 18 |
584248701 |
CAP.ASSY.FUEL.3".N-EPA.BLK.428 This part replaces 532430218. Price: $7.99 |
| 20 |
532423502 |
CONTROL.TH/CK.COBRA.B&S.TWN. Price: $19.99 |
| 21 |
532416358 |
SCREW.#10 X 0.750.BOS (2 2) Price: $2.99 |
| 28 |
532008543 |
Line Fuel 54" (AYP part number) This part replaces 532142158. Price: $7.99 |
| 29 |
532137180 |
KIT.SPARK ARRESTOR(392390 B&S) Price: $129.99 |
| 37 |
532123487 |
HOSE CLAMP Price: $3.99 |
| 42 |
539990247 |
WASHER 7/16 LOCK This part replaces 810040700. Price: $1.99 |
| 45 |
873680400 |
NUT.CROWNLOCK.1/4 This part replaces 873510400. Price: $2.99 |
| 50 |
114-5430 |
ROLLER REBUILD KIT Price: $99.53 |
| 62 |
532434017 |
SHIELD.HEAT.MUFFLER Price: $11.99 |
| 69 |
532165391 |
GASKET.MUFFLER Price: $9.99 |
| 79 |
532183906 |
SCREW.SOCKET.HEAD.5/16-18 Price: $3.99 |
| 81 |
532148456 |
TUBE, DRAIN OIL ASM. Price: $2.99 |
| 82 |
532428287 |
VALUE.OIL.DRAIN Price: $11.99 |
| 84 |
817060620 |
SCREW.3/8-16 Price: $3.99 |
| 85 |
501606501 |
Speed Clip This part replaces 532173937. Price: $1.99 |
| 87 |
532171877 |
BOLT, 5/16-18 X 1 3/4 Price: $3.99 |
| 90 |
817000616 |
SCREW 3/8-16X1 Price: $3.99 |
