| Ref | Part Number | Description |
|---|
| 1 |
47-3650 |
CHAIN-LIFT, NO. 2 AND 3 Price: $119.48 |
| 1 |
532401042 |
SEAT.XG090.BLK.KB/BLT.NO-LOG This part replaces 532140116. Price: $149.99 |
| 2 |
531152401 |
SERVICE KIT BRACKET SEAT PIVOT This part replaces 532140551. Price: $8.99 |
| 2 |
8-0280 |
DISCONTINUED Price: Call Us |
| 3 |
283-10 |
PIN-CLEVIS Price: $7.43 |
| 3 |
871110616 |
BOLT, HEX 3/8-16X1 Price: $3.99 |
| 4 |
51-0850-01 |
SUPPORT-PULLEY This part replaces 51-0850. Price: $306.47 |
| 4 |
819131610 |
WASHER PM Price: $4.99 |
| 5 |
325-17 |
SCREW-HH Price: $2.90 |
| 5 |
532145006 |
PUSH CLIP Price: $2.99 |
| 6 |
47-3930-01 |
LOCKUP BRACKET ASM This part replaces 47-3930. Price: $270.92 |
| 6 |
596322601 |
Nuts This part replaces 873800600. Price: $2.99 |
| 7 |
32128-23 |
NUT-HF Price: $1.51 |
| 8 |
47-3640-01 |
CYLINDER REST ASM This part replaces 47-3640. Price: $44.42 |
| 8 |
817000616 |
SCREW 3/8-16X1 Price: $5.99 |
| 9 |
3290-216 |
WASHER Price: $3.83 |
| 9 |
596140201 |
Washers This part replaces 819131614. Price: $2.99 |
| 10 |
325-6 |
SCREW-HH Price: $1.42 |
| 10 |
532195530 |
PAN.ASM.SEAT.1SLOT This part replaces 532182493. Price: $17.99 |
| 11 |
47-3870-01 |
RH CHANNEL ASM This part replaces 47-3870. Price: $235.39 |
| 12 |
3272-13 |
PIN-COTTER Price: $0.25 |
| 12 |
532174648 |
BRKT.MNTNG.SWITCH.SEAT.BLACK This part replaces 532121246. Price: $8.99 |
| 13 |
26-8590 |
PIN-CYLINDER Price: $23.00 |
| 13 |
532121248 |
BUSHING Price: $4.99 |
| 14 |
237-79 |
O-RING Price: $5.46 |
| 14 |
872050412 |
BOLT.ROUND.HEAD.SQUARE.NECK Price: $4.99 |
| 15 |
353-537 |
FITTING-ELBOW, 90 DEG Price: $12.91 |
| 15 |
532134300 |
SPACER SPLIT 28X.96 Price: $3.99 |
| 16 |
115-4949-01 |
HYDRAULIC CYLINDER ASM (14.00 STROKE) This part replaces 47-3720. Price: $1,376.05 |
| 16 |
532121250 |
SPRING Price: $3.99 |
| 17 |
20-4390 |
SPACER Price: $12.54 |
| 17 |
586668901 |
NUT HEX_LRG FLG_1_4-20_LOCK This part replaces 532123976. Price: $3.99 |
| 18 |
32104-17 |
SCREW-HWH Price: $0.99 |
| 19 |
42-3550-01 |
COVER-MOUNT, CYLINDER This part replaces 42-3550. Price: $108.41 |
| 20 |
3-0144 |
SHAFT Price: $53.89 |
| 21 |
3272-24 |
PIN-COTTER Price: $0.54 |
| 21 |
587907801 |
BOLT.5/16-18X5/8.SHOULDER This part replaces 532171852. Price: $2.99 |
| 22 |
47-3860-01 |
LH CHANNEL ASM This part replaces 47-3860. Price: $215.68 |
| 22 |
596040501 |
Hardware This part replaces 873800500. Price: $2.99 |
| 23 |
13-6200 |
PIN-HITCH, POINTED Price: $40.83 |
| 23 |
871110814 |
BOLT.HEX.BLACK Price: $8.99 |
| 24 |
3290-343 |
PIN-HAIR Price: $0.76 |
| 24 |
819171912 |
WASHER Price: $3.99 |
| 25 |
47-3010-01 |
TRAILER ASM This part replaces 47-3010. Price: $3,956.22 |
| 25 |
532127018 |
BOLT,SHOULD Price: $4.99 |
| 26 |
322-3 |
SCREW-HH Price: $0.79 |
| 26 |
810040800 |
LOCKWASHER Price: $5.99 |
| 27 |
3253-4 |
WASHER-LOCK Price: $0.25 |
| 28 |
60-9110-01 |
LIFT BAIL PIN ASM This part replaces 60-9110. Price: $84.41 |
| 29 |
125-5196 |
BUSHING This part replaces 3-0348. Price: $6.00 |
| 30 |
302-5 |
FITTING-GREASE Price: $0.59 |
| 31 |
47-3230-01 |
NO. 1 LIFT ARM ASM This part replaces 47-3230. Price: $907.15 |
| 32 |
32153-5 |
NUT-HEX Price: $1.59 |
| 33 |
3-2196-01 |
SHEAVE This part replaces 3-2196. Price: $141.72 |
| 34 |
3272-10 |
PIN-COTTER Price: $0.25 |
| 35 |
47-3660 |
CHAIN-LIFT, NO. 1 Price: $197.71 |
| 36 |
5-2942 |
SHACKLE Price: $16.99 |
