| Ref | Part Number | Description |
|---|
| 1 |
22-8330 |
PLUG Price: $64.59 |
| 2 |
237-42 |
O-RING Price: $2.78 |
| 3 |
22-8340 |
SPRING Price: $19.09 |
| 4 |
22-8350 |
BALL Price: $12.28 |
| 5 |
22-8370 |
SEAT-VALVE Price: $88.05 |
| 6 |
22-8360 |
PIN Price: $43.02 |
| 8 |
22-8420 |
SPOOL Price: $437.22 |
| 9 |
22-8500 |
O-RING Price: $18.87 |
| 10 |
22-8380 |
RETAINER Price: $17.86 |
| 11 |
22-8410 |
SPRING Price: $17.61 |
| 12 |
22-8390 |
RETAINER Price: $56.56 |
| 13 |
22-8400 |
SPACER Price: $42.41 |
| 14 |
22-8480 |
RING-SNAP Price: $49.87 |
| 506500701 |
506500701 |
PULLEY Price: $49.99 |
| 506500801 |
506500801 |
SPACER Price: $8.99 |
| 506522401 |
506522401 |
ROLLER Price: $9.99 |
| 506539401 |
506539404 |
SHAFT This part replaces 506539401. Price: $14.99 |
| 506554601 |
506554601 |
STEERING CHAIN Price: $17.99 |
| 506554701 |
506554701 |
LINK Price: $4.99 |
| 506570104 |
506570104 |
BOLT Price: $4.99 |
| 506576103 |
506576103 |
GUIDE PLATE Price: $30.64 |
| 506589101 |
501604801 |
WIRE ASSY This part replaces 506589101. Price: $24.99 |
| 506592001 |
506592001 |
STEERING WHEEL Price: $99.99 |
| 506863301 |
506863301 |
SHAFT Price: $84.99 |
| 506863401 |
587080901 |
DRIVER STEERING WHEEL This part replaces 506863401. Price: $7.99 |
| 506863601 |
506863601 |
WASHER Price: $7.99 |
| 506887801 |
506887801 |
SPACER Price: $7.99 |
| 725249751 |
725249751 |
SCREW Price: $4.99 |
| 728745505 |
728745505 |
SCREW Price: $3.99 |
| 728844305 |
728844305 |
Screw Price: $1.99 |
| 731231801 |
731231801 |
NUT Price: $3.99 |
| 731232051 |
731232001 |
Nut This part replaces 731232051. Price: $3.99 |
| 732212051 |
732212001 |
NUT This part replaces 732212051. Price: $3.99 |
| 734117441 |
734117441 |
WASHER Price: $3.99 |
| 735311420 |
735311420 |
RETAINING RING Price: $2.99 |
| 735314010 |
735314010 |
CIRCLIP SGH 47 Price: $4.99 |
| 738210404 |
738210404 |
BALL BEARING 6004-2RS1 Price: $9.99 |
