| Ref | Part Number | Description |
|---|
| 1 |
340-3 |
FITTING-STRAIGHT Price: $10.42 |
| 2 |
19132012 |
WASHER Price: Call Us |
| 2 |
83-1450 |
SENSOR-LEVEL, OIL Price: $265.93 |
| 3 |
17490612 |
SCREW Price: Call Us |
| 3 |
237-80 |
O-RING Price: $6.10 |
| 4 |
124181X |
SPRING COMPRESSIO Price: Call Us |
| 4 |
136-8550 |
KIT-HYDRAULIC TANK This part replaces 105-9783. Price: $1,272.96 |
| 5 |
83-1520 |
SCREEN-FILLER Price: $35.12 |
| 6 |
109596X |
HOSE CLAMP T Price: Call Us |
| 6 |
354-121 |
FITTING-STR Price: $17.60 |
| 7 |
124144X |
PAD FOOTREST Price: Call Us |
| 8 |
17490512 |
SCREW Price: Call Us |
| 8 |
93-7160 |
CAP-OIL, HYD Price: $42.72 |
| 9 |
2412-141 |
CLAMP-DRIVE, WORM Price: $2.40 |
| 10 |
139783 |
PLATE LOCK SHIFT Price: Call Us |
| 10 |
140-5278 |
HOSE-FORMED This part replaces 83-2070. Price: $19.31 |
| 11 |
124346X |
NUT Price: Call Us |
| 11 |
83-1550 |
SPACER-TUBE, SHORT Price: $7.73 |
| 12 |
145190 |
CHASSIS.WELD.ASM. Price: Call Us |
| 12 |
83-1470 |
WASHER-NEOPRENE Price: $1.97 |
| 13 |
109238X |
TUBE T Price: Call Us |
| 13 |
3256-71 |
WASHER-FLAT Price: $0.81 |
| 14 |
322-14 |
SCREW-HH Price: $1.01 |
| 15 |
136-8547 |
LEAK DETECTOR TANK KIT This part replaces 83-2100. Price: $724.57 |
| 15 |
73640400 |
NUT HXKEP 1/4X20 Price: Call Us |
| 16 |
141736 |
SUB= 146613 Price: Call Us |
| 16 |
68-6150 |
BREATHER Price: $27.22 |
| 17 |
140782 |
DRAWBAR ASM LR Price: Call Us |
| 17 |
322-29 |
SCREW-HH Price: $2.69 |
| 18 |
83-1560 |
SPACER-TUBE, LONG Price: $8.33 |
| 19 |
140955X421 |
FENDER/FOOTREST Price: Call Us |
| 20 |
19091413 |
WASHER Price: Call Us |
| 21 |
354-120 |
FITTING-ELBOW, 90 Price: $30.04 |
| 22 |
321-11 |
SCREW-HH Price: $0.36 |
| 23 |
3253-3 |
WASHER-LOCK Price: $0.31 |
| 24 |
161-4678 |
SOLENOID VALVE ASM This part replaces 83-1460. Price: $932.37 |
| 25 |
139-2716 |
HOSE-FORMED This part replaces 83-2090. Price: $11.29 |
| 26 |
83-2080 |
HOSE-VALVE, TANK Price: $8.76 |
| 27 |
2412-34 |
CLAMP-HOSE Price: $2.14 |
| 28 |
83-0870 |
FITTING-HOSE, BARBED Price: $62.08 |
| 29 |
323-6 |
SCREW-HH Price: $0.66 |
| 30 |
63-8410 |
WASHER Price: $1.76 |
| 31 |
240-11 |
BUSHING-FLANGE Price: $5.32 |
| 32 |
83-2390 |
PAD-TANK Price: $18.44 |
| 33 |
83-2400 |
SPACER Price: $6.31 |
| 34 |
321-2 |
SCREW-HH Price: $2.79 |
| 35 |
2412-36 |
CLAMP-HOSE Price: $1.28 |
| 36 |
92-8020 |
ADAPTER-BREATHER Price: $10.50 |
