| Ref | Part Number | Description |
|---|
| 1 |
125-7016 |
TAPPET Price: $16.62 |
| 2 |
125-7017 |
ROD-PUSH Price: $10.14 |
| 2 |
532188655 |
MUFFLER.SINGLE.CYL.KOHL/B&S Price: $39.99 |
| 3 |
127-3113 |
CAMSHAFT ASM Price: Call Us |
| 4 |
125-7008 |
METAL-THRUST Price: $25.42 |
| 6 |
127-3052 |
GEAR-CAMSHAFT Price: $199.39 |
| 7 |
125-7185 |
KEY Price: $2.16 |
| 8 |
127-3053 |
PULSER-CAMSHAFT Price: $19.46 |
| 9 |
125-7205 |
BOLT Price: $2.67 |
| 9 |
596501502 |
Keepers This part replaces 532194320. Price: $9.99 |
| 10 |
125-7213 |
BOLT Price: $2.67 |
| 11 |
127-3054 |
SENSOR-REV, GEAR Price: $158.02 |
| 12 |
127-3184 |
BOLT Price: $4.58 |
| 12 |
586478501 |
ENGINE.PULLEY This part replaces 532405471. Price: $27.99 |
| 13 |
127-3063 |
SHAFT-IDLE, GEAR A Price: Call Us |
| 14 |
127-3066 |
IDLE GEAR A ASM Price: $135.01 |
| 15 |
581289901 |
FUEL.TANK.ASM.NON-EPA This part replaces 532407545. Price: $44.99 |
| 17 |
125-7219 |
BOLT Price: $4.58 |
| 18 |
127-3070 |
GEAR-PUMP, SUPPLY Price: $121.19 |
| 18 |
581075501 |
CAP.2.25'.VENTED.RATCHET.EPA This part replaces 532197725. Price: $22.99 |
| 19 |
127-3167 |
WASHER-SPRING Price: $1.94 |
| 20 |
127-3185 |
NUT-LOCK Price: $5.51 |
| 20 |
532176636 |
CONTROL.TH/CK.C.BLACK This part replaces 532183897. Price: $27.99 |
| 21 |
127-3064 |
SHAFT-IDLE, GEAR B Price: Call Us |
| 21 |
596321701 |
Screws This part replaces 532191611. Price: $2.99 |
| 22 |
127-3067 |
IDLE GEAR B ASM Price: $110.72 |
| 25 |
127-3068 |
PLATE-IDLE, SHAFT Price: Call Us |
| 26 |
127-3069 |
GASKET-IDLE, SHAFT B Price: $4.14 |
| 27 |
125-7218 |
BOLT Price: $3.48 |
| 28 |
125-6927 |
BUSHING Price: $74.51 |
| 28 |
587044820 |
HOSE 1/4" LOW PERMEATION FUEL This part replaces 532137040. Price: $9.99 |
| 37 |
532123487 |
HOSE CLAMP Price: $3.99 |
| 42 |
596238901 |
Washers This part replaces 810040700. Price: $2.99 |
| 44 |
817670412 |
SCREW HEXWSHR 1/4-20X3/4 Price: $3.99 |
| 45 |
586668901 |
NUT HEX_LRG FLG_1_4-20_LOCK This part replaces 873510400. Price: $3.99 |
| 46 |
596135301 |
Washers This part replaces 819091416. Price: $2.99 |
| 69 |
532185909 |
GASKET.EXHAUST.KOHLER Price: $7.99 |
| 79 |
596134201 |
Screws This part replaces 532192334. Price: $2.99 |
| 81 |
532148456 |
TUBE, DRAIN OIL ASM. Price: $5.99 |
| 82 |
532428287 |
VALUE.OIL.DRAIN This part replaces 532181654. Price: $14.99 |
| 83 |
532171877 |
BOLT.5/16-18UNCX3/4 W/SEMS.BLK Price: $4.99 |
| 90 |
817000616 |
SCREW 3/8-16X1 Price: $5.99 |
| 92 |
817120616 |
SCREW 3/8-16X1 Price: $4.99 |
| 94 |
583955301 |
TUBE.EXHAUST.KOHLER.COURAGE This part replaces 532188654. Price: $27.99 |
| 95 |
501606501 |
BOLT.HEX.7/16-20X4.GR5.1.5BLUE This part replaces 532173937. Price: $2.99 |
| 102 |
532428867 |
BOLT.HEX.HD.WASHER.5/16-18X.75 This part replaces 817000512. Price: $4.99 |
| 105 |
532410528 |
SHIELD.SIDE.LH.3842"TEX FRENCH Price: $6.99 |
| 106 |
532410529 |
SHIELD.SIDE.RH.3842"TEX FRENCH Price: $7.99 |
| 107 |
532137729 |
SCREW.1/4-20X5/8 Price: $3.99 |
| 108 |
532410532 |
NEEDS DESCRIPTION Price: Call Us |
