| Ref | Part Number | Description |
|---|
| 1 |
58-5860 |
HOSE ASM Price: $420.33 |
| 2 |
530016153 |
Screw Price: $1.99 |
| 2 |
75-8200 |
HOSE-FILTER / COOLER Price: $646.34 |
| 3 |
530059006 |
Reflector-Tape Price: $1.99 |
| 3 |
92-5677 |
TUBE-TRACTION Price: $331.48 |
| 4 |
33113-025 |
SCREW-HH Price: $1.97 |
| 4 |
530039238 |
Module - Ignition Price: $28.99 |
| 5 |
43-5930 |
WASHER-LOCK, SPRING Price: $0.75 |
| 5 |
530016432 |
Screw Price: $1.99 |
| 6 |
33093-00 |
WASHER-FLAT Price: $0.70 |
| 6 |
530047442 |
Strap-Ground Price: $1.99 |
| 7 |
530057943 |
Assy-Wire Harness Price: $5.99 |
| 7 |
75-8210 |
HOSE-MANIFOLD / COOLER Price: $519.29 |
| 8 |
530058687 |
Cover-Air Filter Price: $4.99 |
| 8 |
60-1900 |
TUBE Price: $604.94 |
| 9 |
530057925 |
Filter-Air Price: $0.99 |
| 9 |
58-3880 |
CLAMP-DOUBLE Price: $7.34 |
| 10 |
530016425 |
Screw Price: $1.99 |
| 11 |
530057892 |
Housing-Air Filter Price: $4.99 |
| 11 |
98-7415 |
HOSE-HYD Price: $72.36 |
| 12 |
545070601 |
Carb-Zama W-26B This part replaces 530035590. Price: $27.99 |
| 12 |
92-4748 |
ADAPTER-HYD, TEE Price: $131.52 |
| 13 |
340-69 |
ELBOW-BULKHEAD, 45 DEG Price: $31.67 |
| 13 |
530069247 |
Kit-Fuel Line (Small) Price: $3.69 |
| 14 |
530047721 |
Bulb-Purge "snap-in" Price: $3.99 |
| 14 |
92-4726 |
TUBE-TRACTION Price: $402.37 |
| 15 |
92-5694 |
HOSE-HYDRAULIC Price: $92.15 |
| 16 |
530071894 |
Gasket-cyl. o-ring (kit) Price: $6.99 |
| 16 |
98-7416 |
HOSE-HYD Price: $118.92 |
| 17 |
503235111 |
BPMR7A NGK SPARK PLUG This part replaces 952030150. Price: $3.69 |
| 18 |
2412-92 |
CLAMP-HOSE Price: $2.44 |
| 18 |
530071884 |
Kit-Cylinder (Incl. 25,33) Price: $22.99 |
| 19 |
530016136 |
Clip-High Tension Lead Price: $1.99 |
| 19 |
60-1250 |
HOSE-DRAIN Price: $155.85 |
| 20 |
340-23 |
CROSS-UNION Price: $31.69 |
| 21 |
530057942 |
Backplate-Muffler Price: $5.99 |
| 22 |
530071894 |
Gasket-Muffler (kit) Price: $6.99 |
| 23 |
530071886 |
Kit-Spark Arrestor Price: $9.99 |
| 24 |
530016338 |
Bolt-Muffler Price: $1.99 |
| 24 |
60-1360 |
CLAMP-SINGLE Price: $5.97 |
| 25 |
545015301 |
Insert-Left (black) Cyl. This part replaces 530057885. Price: $2.99 |
| 25 |
58-4790 |
TUBE-STEEL Price: $136.25 |
| 26 |
340-68 |
FITTING-TEE, BULKHEAD Price: $36.00 |
| 26 |
545112901 |
Assy-Crankshaft/Rod This part replaces 530012537. Price: $46.99 |
| 27 |
530016417 |
Bolt Price: $1.99 |
| 27 |
58-4860 |
TUBE-STEEL Price: $187.46 |
| 28 |
530057941 |
Cap-Crankcase Price: $5.99 |
| 28 |
74-2820 |
TUBE ASM Price: $146.08 |
| 29 |
530056363 |
Assy-Bearing/Seal Price: $11.99 |
| 31 |
340-70 |
NUT-LOCK Price: $2.10 |
| 31 |
530015697 |
Retainer-Piston Pin Price: $1.99 |
| 32 |
545160401 |
Ring-Piston This part replaces 530038729. Price: $2.99 |
| 32 |
74-2780 |
TUBE ASM Price: $113.04 |
| 33 |
545015401 |
Insert-Right (gray) Cyl. This part replaces 530057886. Price: $2.99 |
| 33 |
58-5720 |
HOSE ASM Price: $128.46 |
| 34 |
530071894 |
Seal-Adaptor (kit) Price: $6.99 |
| 34 |
58-5870 |
HOSE ASM Price: $112.01 |
| 35 |
530016426 |
Screw Price: $1.99 |
| 35 |
74-2810 |
TUBE ASM Price: $182.29 |
| 36 |
530071894 |
Gasket-Carb. (kit) Price: $6.99 |
| 36 |
74-2790 |
TUBE ASM Price: $111.73 |
| 37 |
530057926 |
Tube-Intake Price: $1.99 |
| 38 |
530057909 |
Wire-Throttle Price: $1.99 |
| 39 |
530016101 |
Nut-Carb. Price: $1.99 |
| 41 |
530031163 |
Wrench-Bar Price: $4.99 |
| 43 |
340-65 |
O-RING Price: $3.58 |
| 48 |
58-4710 |
TUBE-STEEL Price: $142.13 |
| 49 |
48-7890 |
NUT-HEX Price: $0.25 |
| 50 |
237-30 |
O-RING Price: $2.50 |
| 54 |
340-71 |
FITTING-STRAIGHT, BULKHEAD Price: $20.74 |
| 55 |
105-3333 |
HYD TUBE KIT Price: $303.88 |
