| Ref | Part Number | Description |
|---|
| 1 |
110-4817 |
KIT - AXLE HOUSING This part replaces 95-7538. Price: $657.17 |
| 2 |
115-0622 |
SEAL - OIL This part replaces 100-2557. Price: $10.23 |
| 2 |
195223 |
Shaft Asm., Lift Price: Call Us |
| 3 |
104-2378 |
BUSHING Price: $40.73 |
| 3 |
195231 |
Lever Asm., Lift Rh Price: Call Us |
| 4 |
106-1069 |
O-RING This part replaces 104-2372. Price: $5.20 |
| 5 |
104-2373 |
KNUCKLE Price: $58.69 |
| 6 |
104-2374 |
BOLT Price: $6.33 |
| 7 |
100-3768 |
LH STEERING ARM ASM Price: $207.28 |
| 7 |
196492X421 |
Grip, Lever Price: Call Us |
| 8 |
100-3766 |
RH STEERING ARM ASM Price: $207.28 |
| 10 |
196314 |
Spring Torsion Price: Call Us |
| 10 |
95-7547 |
SHIM 0.1 Price: $2.53 |
| 10 |
95-7548 |
SHIM 0.2 Price: $3.52 |
| 10 |
95-7549 |
SHIM 0.3 Price: $3.82 |
| 11 |
99-7597 |
PIN-DOWEL Price: $3.74 |
| 12 |
104-2375 |
BOLT Price: $18.54 |
| 13 |
99-7599 |
BOLT Price: $3.17 |
| 14 |
99-7525 |
STUD Price: $7.03 |
| 15 |
99-7526 |
NUT Price: $1.29 |
| 16 |
99-7527 |
WASHER-SPRING Price: $1.02 |
| 18 |
106-1141 |
STEERING TIE ROD ASM This part replaces 100-3762. Price: $642.02 |
| 87 |
194209 |
Pin Cotter 7/16 Bow Tie Lock Price: Call Us |
| 88 |
195303 |
Spring Lift Assist Price: Call Us |
| 89 |
19191912 |
Washer Clear Zinc Price: Call Us |
| 90 |
194208 |
Pin Cotter 5/16 Bow Tie Lock Price: Call Us |
| 91 |
195181 |
Link Lift Susp Mower Rear Price: Call Us |
| 97 |
17060612 |
Screw 3/8-16 x .75 Smgml Tap/R.Z Price: Call Us |
| 98 |
195270 |
Link Lift Susp. Front Mower Price: Call Us |
