| Ref | Part Number | Description |
|---|
| 1 |
111-4783 |
RH LIFT ARM ASM This part replaces 111-4784-01. Price: $679.09 |
| 1 |
530057991 |
ASSY THROTTLE CABLE Price: $8.99 |
| 2 |
530049107 |
TRIGGER RED Price: $1.99 |
| 2 |
631045 |
RET SPRING Price: Call Us |
| 3 |
631036 |
SHUTTER Price: $1.20 |
| 4 |
119-2200 |
PAD-RUBBER, REAR HOC Price: $10.33 |
| 4 |
530015880 |
SCREW Price: $1.99 |
| 4 |
650506 |
SCREW Price: $0.87 |
| 5 |
119-2230 |
PAD-PLASTIC, REAR HOC Price: $7.14 |
| 5 |
530015821 |
BOLT\-1/4-20X1-1/2 Price: $1.99 |
| 6 |
110-0606 |
RIVET-BLIND Price: $1.15 |
| 7 |
105-7441 |
BEARING-SPHERICAL Price: $56.85 |
| 7 |
630735 |
SPRING Price: $1.25 |
| 8 |
32151-34 |
RING-RETAINING Price: $0.67 |
| 8 |
530091373 |
Nut This part replaces 530016152. Price: $1.99 |
| 9 |
3269-26 |
WASHER-PLAIN Price: $0.99 |
| 9 |
530071661 |
Assy-Drive Shaft Hsg. This part replaces 530071662. Price: $24.99 |
| 9 |
630758 |
SHUTTER Price: $1.20 |
| 10 |
302-5 |
FITTING-GREASE Price: $0.59 |
| 10 |
530096075 |
SHAFT FLEX 52" Price: $6.99 |
| 10 |
631562 |
ADJ SCREW Price: $3.74 |
| 11 |
530016014 |
SCREW - CARB. ADAPTOR Price: $1.99 |
| 11 |
630738 |
SPRING Price: $1.25 |
| 11A |
630738 |
SPRING Price: $1.25 |
| 12 |
530016224 |
SCREW Price: $1.99 |
| 12 |
630739 |
WASHER Price: $1.25 |
| 12A |
630739 |
WASHER Price: $1.25 |
| 13 |
580345001 |
PLUG This part replaces 575724501. Price: $1.99 |
| 13 |
630740 |
O RING Price: $1.49 |
| 13A |
630740 |
O RING Price: $1.49 |
| 14 |
530052285 |
LINE LIMITER 17" Price: $1.99 |
| 14 |
630737 |
ADJ SCREW Price: $3.95 |
| 15 |
530015957 |
Screw This part replaces 530015966. Price: $1.99 |
| 15 |
630748 |
WELCH PLUG Price: $1.17 |
| 16 |
530015820 |
BOLT, TYPE 2 Price: $1.99 |
| 17 |
632554 |
WELCH PLUG This part replaces 630746. Price: $1.17 |
| 18 |
530091373 |
Nut This part replaces 530016152. Price: $1.99 |
| 18 |
631049 |
SPRING Price: $1.20 |
| 19 |
530096067 |
BRACKET SHIELD Price: $2.99 |
| 19 |
630742 |
GASKET Price: $1.25 |
| 20 |
530096068 |
GEARBOX ASSY 3/4 Price: $34.99 |
| 20 |
630932A |
INLET NEEDLE Price: $4.39 |
| 21 |
630750A |
GASKET This part replaces 630750. Price: $3.00 |
| 22 |
530095772 |
TNG VI HUB ASSY LH Price: $5.42 |
| 22 |
630978 |
DIAPHRAGM Price: $4.49 |
| 23 |
530053241 |
SPRING Price: $1.99 |
| 23 |
630751 |
COVER Price: $8.60 |
| 24 |
530401957 |
RETAINER Price: $1.99 |
| 24 |
650545 |
SCREW Price: $1.20 |
| 25A |
630904 |
SHAFT & LEV Price: $5.16 |
| 28 |
632164 |
FUEL FITTING This part replaces 631803. Price: $5.95 |
