| Ref | Part Number | Description |
|---|
| 1 |
04001-46 |
Bolt, Hex Head 3/8-16 x 2-1/4" - 61" Price: Call Us |
| 1 |
5-3164 |
Seat and Post Price: Call Us |
| 2 |
323-14 |
SCREW-HH Price: $1.34 |
| 2 |
43886 |
Spacer Price: Call Us |
| 3 |
04117-02 |
Nut, Flange Elastic Stop Nut, 3/8-16 Price: Call Us |
| 3 |
3256-5 |
WASHER-FLAT Price: $0.27 |
| 4 |
426016 |
Angle Bracket, GC Price: Call Us |
| 4 |
5-3162 |
Frame Price: Call Us |
| 5 |
426024 |
Wear Plate, GC Price: Call Us |
| 5 |
5-3174 |
Eye Bolt Price: Call Us |
| 6 |
04001-16 |
Bolt, Hex Head 3/8-16 x 1" Price: Call Us |
| 6 |
3217-9 |
NUT-HH Price: $0.37 |
| 7 |
04003-22 |
Carriage Bolt, 3/8-16 x 1-1/4" Price: Call Us |
| 7 |
603773 |
LOCKNUT This part replaces 32146-2. Price: $2.09 |
| 8 |
04001-46 |
Bolt, Hex Head 3/8-16 x 2-1/4" - 61" Price: Call Us |
| 8 |
5-3150 |
Decal Price: Call Us |
| 9 |
04066-04 |
Quick Pin, 5/16" Dia. Price: Call Us |
| 9 |
302-5 |
FITTING-GREASE Price: $0.59 |
| 10 |
3296-15 |
NUT-LOCK, NI Price: $1.75 |
| 10 |
426012 |
Mounting Bracket, Tube Price: Call Us |
| 11 |
241-107 |
Rim Assy. Price: Call Us |
| 11 |
453043 |
MTG BRKT WLMT, GC-STC/SCVZ This part replaces 452382. Price: Call Us |
| 12 |
426015 |
Tube, Upright Price: Call Us |
| 12 |
5108 |
VALVE This part replaces 232-27. Price: $6.29 |
| 13 |
231-17 |
DISCONTINUED Price: Call Us |
| 13 |
426011 |
Mounting Bracket, GC R.H. Price: Call Us |
| 14 |
110513 |
BEARING-WHEEL This part replaces 251-210. Price: $20.99 |
| 14 |
426010 |
Mounting Bracket, GC L.H. Price: Call Us |
| 15 |
426017 |
Angle Bracket, GC Price: Call Us |
| 15 |
5-3163 |
Axle Price: Call Us |
| 16 |
43884 |
Pin, GC Locator Price: Call Us |
| 16 |
5-3173 |
Spring Price: Call Us |
| 17 |
04041-11 |
Flatwasher, 3/8-.406 x 1-1-1/2 x 7 Gauge Price: Call Us |
| 17 |
5-3175 |
Foot Rest Price: Call Us |
| 18 |
04030-04 |
Lockwasher, 3/8” Spring, Kawasaki FX / FT & FT-EFI / B&S 32BV Price: Call Us |
| 18 |
5-3176 |
U Bolt Price: Call Us |
| 19 |
3243-6 |
SCREW-SET, SQH Price: $4.23 |
| 20 |
3218-3 |
NUT-JAM Price: $0.25 |
| 21 |
5-3167 |
Frame Extension Price: Call Us |
| 22 |
5-3126 |
PIN-LYNCH Price: $0.73 |
