| Ref | Part Number | Description |
|---|
| 1 |
323-9 |
SCREW-HH Price: $1.29 |
| 1 |
532423469 |
WHEEL STEERING Price: $32.99 |
| 2 |
532413591 |
AXLE.SVC.ASM CAST IRON.TEX This part replaces 532195968. Price: $119.99 |
| 2 |
56-3650 |
LOWER CABLE BRKT *B Price: Call Us |
| 3 |
3296-44 |
NUT-LOCK, NI Price: $2.46 |
| 4 |
56-3660 |
MT BRKT *B Price: Call Us |
| 4 |
596873601 |
SPINDLE.WELDED.LH.15"TEX.X431 This part replaces 532403087. Price: $14.99 |
| 5 |
538691201 |
SPINDLE.WLDMT.RH.15INTIRE.X431 This part replaces 532403088. Price: $19.99 |
| 5 |
56-3680 |
Brake Bracket Assembly (Incl. Ref. #26) Price: $232.77 |
| 6 |
532006266 |
WASHER THRUST This part replaces 532124931. Price: $4.99 |
| 6 |
56-3480 |
TENSION PIN Price: Call Us |
| 7 |
532121748 |
WASHER Price: $3.99 |
| 7 |
56-3520 |
NUT Price: Call Us |
| 8 |
56-3510 |
SPRING WASHER Price: Call Us |
| 8 |
812000029 |
RING CLIP Price: $3.99 |
| 9 |
532121232 |
CAP.SPINDLE.BLACK Price: $3.99 |
| 9 |
56-3401 |
REAR BRAKE ASM LH This part replaces 56-3420. Price: $340.76 |
| 10 |
56-3460 |
ADJUSTER Price: $24.93 |
| 11 |
56-3440 |
SHOE Price: $52.22 |
| 12 |
57-0830 |
TRAILING SHOE Price: Call Us |
| 13 |
532121749 |
WASHER Price: $2.99 |
| 13 |
56-3450 |
BRAKE SPRING Price: Call Us |
| 14 |
242-77 |
WHEEL BOLT Price: Call Us |
| 14 |
596238701 |
Washers This part replaces 810040600. Price: $3.99 |
| 15 |
53-4640 |
DRUM Price: $215.94 |
| 15 |
873540600 |
NUT CROWNLOCK 3/8-24 Price: $3.99 |
| 16 |
57-0820 |
BRAKE SPRING Price: $14.09 |
| 16 |
587738904 |
KIT.SRVC.STEERINGSHAFT.2HISHFT This part replaces 532408219. Price: $34.99 |
| 17 |
56-3470 |
SHOE CLAMP SPRING Price: Call Us |
| 18 |
322-4 |
SCREW-HH Price: $0.35 |
| 19 |
531169101 |
SERVICE KIT PLATE PLATE.STEER. This part replaces 532194729. Price: $19.99 |
| 19 |
57-0880 |
WASHER Price: Call Us |
| 20 |
57-0890 |
THRUST WASHER Price: Call Us |
| 21 |
57-0850 |
ADJ NUT Price: Call Us |
| 21 |
587738905 |
KIT.SRVC.STEERINGSHAFT.ADAPTER This part replaces 532186737. Price: $7.99 |
| 22 |
57-0870 |
ADJ BOLT Price: Call Us |
| 22 |
587738901 |
KIT.SRVC.STEERINGSHAFT.LWRBSHG This part replaces 532194845. Price: $14.99 |
| 23 |
57-0810 |
LH LEVER ASM Price: Call Us |
| 24 |
56-3490 |
DUST COVER Price: Call Us |
| 25 |
3296-29 |
NUT-LOCK, NI Price: $2.09 |
| 26 |
256-278 |
BUSHING #AA-1232 Price: Call Us |
| 26 |
532439743 |
INSERT.CAP.WHL.STRG.HUSQ.PREM This part replaces 532415987. Price: $8.99 |
| 28 |
817000612 |
SCREW, 3/8-16X3/4 Price: $3.99 |
| 35 |
532194732 |
GEAR.SECTOR.PLATE.DDL. Price: $27.99 |
| 45 |
819183812 |
WASHER 9/16"ID, 2 3/8"OD Price: $7.99 |
| 51 |
873940800 |
NUT.HEX.1/2-20 Price: $3.99 |
| 53 |
532188967 |
WASHER.HARDENED Price: $3.99 |
| 57 |
532407465 |
BRACKET.UPSTOP.TEX Price: $5.99 |
| 58 |
532194747 |
BOLT.SHOULDER.SECTOR.P Price: $7.99 |
| 59 |
532194748 |
WASHER.THURST.SECTOR.S Price: $4.99 |
| 60 |
583612801 |
NUT.FLANGE.LOCK.5/8-11 This part replaces 873971000. Price: $3.99 |
| 61 |
597047802 |
Links This part replaces 532194740. Price: $11.99 |
| 62 |
597047902 |
Links This part replaces 532194741. Price: $11.99 |
| 63 |
532428867 |
BOLT.HEX.HD.WASHER.5/16-18X.75 This part replaces 817000512. Price: $4.99 |
| 64 |
532199849 |
RETAINER.CLIP.SPRING.S Price: $4.99 |
| 66 |
871020748 |
BOLT HEX FGHD 7/16-14 X 3 SERR Price: $4.99 |
| 67 |
529496302 |
BUSHING, AXLE This part replaces 532194737. Price: $2.99 |
| 68 |
873900700 |
NUT.LOCK.FLANGE.7/16 Price: $3.99 |
| 69 |
532199162 |
WASHER.1.5X.505X.118 Price: $4.99 |
