| Ref | Part Number | Description |
|---|
| 1 |
120-8053 |
HOSE ASM Price: $126.14 |
| 1 |
532170551 |
CONTROL.THROTTLE/CHOKE.BLACK This part replaces 532140310. Price: $24.99 |
| 2 |
104-3789 |
FILTER HOSE ASM Price: $273.63 |
| 2 |
596582501 |
Bolts This part replaces 817720410. Price: $2.99 |
| 3 |
120-8079 |
TUBE ASM Price: $388.35 |
| 4 |
120-8080 |
TUBE ASM Price: $344.12 |
| 4 |
532137348 |
MUFFLER.SINGLE.B&S.10-12HP Price: $89.99 |
| 5 |
136-2925 |
HOSE ASM Price: $86.03 |
| 6 |
120-8047 |
TUBE ASM Price: $141.79 |
| 7 |
92-7595 |
HOSE-HYD Price: $102.70 |
| 8 |
136-2927 |
HOSE ASM Price: $498.70 |
| 9 |
136-2928 |
HOSE ASM Price: $361.14 |
| 10 |
340-126 |
NUT-BULKHEAD Price: $4.61 |
| 11 |
136-2882 |
HYD TUBE ASM Price: $194.81 |
| 12 |
340-127 |
NUT-BULKHEAD Price: $2.24 |
| 13 |
532272293 |
GASKET.ENG.1.313 ID.TIN PLATED This part replaces 532165291. Price: $8.99 |
| 13 |
92-2406 |
HOSE-HYD Price: $106.53 |
| 14 |
340-74 |
NUT-LOCK, BULKHEAD Price: $4.83 |
| 14 |
813280324 |
Nipple Pipe 3/8 Npt X 3-1/2 Price: $3.12 |
| 15 |
136-2911 |
HOSE ASM Price: $140.09 |
| 15 |
532428287 |
VALUE.OIL.DRAIN This part replaces 813200300. Price: $14.99 |
| 16 |
121-3055 |
TUBE ASM Price: $92.66 |
| 16 |
596238701 |
Washers This part replaces 811050600. Price: $3.99 |
| 17 |
121-3056 |
TUBE ASM Price: $86.92 |
| 18 |
121-3123 |
TUBE ASM Price: $151.27 |
| 19 |
125-4569 |
TUBE ASM Price: $345.90 |
| 20 |
121-3054 |
TUBE ASM Price: $273.56 |
| 21 |
59-7410 |
FITTING-DIAGNOSTIC Price: $36.39 |
| 22 |
354-79 |
CAP-DUST Price: $7.81 |
| 23 |
119-0011 |
PRESSURE TRANSDUCER ASM Price: $341.50 |
| 23 |
531150701 |
SERVICE KIT SHIELD SHIELD.BROW This part replaces 532169837. Price: $19.99 |
| 24 |
120-8052 |
TUBE ASM Price: $161.21 |
| 25 |
340-70 |
NUT-LOCK Price: $2.10 |
| 26 |
125-4563 |
TUBE ASM Price: $67.84 |
| 31 |
532184900 |
TANK.ASM.FUEL.FRONT.W/CAP This part replaces 532109202. Price: $39.99 |
| 32 |
581075501 |
CAP.2.25'.VENTED.RATCHET.EPA This part replaces 532140527. Price: $22.99 |
| 33 |
532123487 |
HOSE CLAMP Price: $3.99 |
| 37 |
587044820 |
HOSE 1/4" LOW PERMEATION FUEL This part replaces 532137040. Price: $9.99 |
| 40 |
532124028 |
BUSHING.SNAP.NYL.BLK. Price: $4.99 |
| 44 |
874760412 |
BOLT.HEX.1/4.X.3/4.DICHROMATE This part replaces 817490412. Price: $3.99 |
| 45 |
817000612 |
SCREW, 3/8-16X3/4 This part replaces 817060612. Price: $3.99 |
| 46 |
596135301 |
Washers This part replaces 819091416. Price: $2.99 |
| 62 |
596238801 |
WASHER SPRING LOCK WASHER WITH This part replaces 810040500. Price: $2.99 |
| 72 |
871070510 |
Screw, Hex.Hd. Cap 5/16 - 18 x 5/8 Price: $2.66 |
| 81 |
532050675 |
NUT.HEX..25-20.UNC This part replaces 532128861. Price: $2.99 |
