| Ref | Part Number | Description |
|---|
| 1 |
131-1821 |
MOUNT-ENGINE Price: $105.39 |
| 1 |
532124415 |
STEERING WHEEL Price: $58.99 |
| 2 |
117-0667-0P |
BRACKET ASM-LH [PRIMED] This part replaces 117-0667-03. Price: $86.10 |
| 2 |
531171101 |
SERVICE KIT AXLE HALF ASM This part replaces 532154427. Price: $59.99 |
| 3 |
117-0666-0P |
BRACKET ASM-RH [PRIMED] This part replaces 117-0666-03. Price: $86.10 |
| 3 |
532156483 |
SPINDLE ASM LH This part replaces 532154422. Price: $22.99 |
| 4 |
117-0669-0P |
BRACKET ASM-REAR MOUNT [PRIMED] This part replaces 117-0669-03. Price: $57.28 |
| 4 |
532157473 |
SPINDLE ASM RH This part replaces 532154423. Price: $22.99 |
| 5 |
3253-4 |
WASHER-LOCK Price: $0.25 |
| 5 |
532006266 |
WASHER THRUST This part replaces 532124931. Price: $4.99 |
| 6 |
139-9940 |
SCREW-HH This part replaces 99-5132. Price: $1.99 |
| 6 |
532121748 |
WASHER Price: $3.99 |
| 7 |
48-9590 |
WASHER-LOCK Price: $0.25 |
| 7 |
819272016 |
WASHER Price: $3.99 |
| 8 |
63-7790 |
SCREW-CAP Price: $1.46 |
| 8 |
812000029 |
RING CLIP Price: $3.99 |
| 9 |
3253-7 |
WASHER-LOCK Price: $0.27 |
| 9 |
532003366 |
BEARING.STEERING.COLUMN This part replaces 532124937. Price: $3.99 |
| 10 |
325-5 |
SCREW-HH Price: $1.20 |
| 10 |
532156438 |
DRAGLINK-STAMPED Price: $79.99 |
| 11 |
119-4162 |
SCREW-CARR This part replaces 323-13. Price: $1.73 |
| 11 |
596238701 |
Washers This part replaces 810040600. Price: $3.99 |
| 12 |
87-5100 |
WASHER-SNUBBING Price: $3.46 |
| 13 |
104-8301 |
NUT-HF, NI Price: $1.09 |
| 13 |
532154779 |
BEARING AXLE Price: $8.99 |
| 14 |
323-7 |
SCREW-HH Price: $0.65 |
| 15 |
119-6039 |
PLUG-PLASTIC Price: $1.31 |
| 15 |
583612401 |
LOCKNUT M This part replaces 873901000. Price: $2.99 |
| 16 |
33114-030 |
SCREW-HH Price: $0.50 |
| 17 |
33114-020 |
SCREW-HH Price: $0.28 |
| 17 |
531166901 |
SERVICE KIT SHAFT ASM ST This part replaces 532156546. Price: $42.99 |
| 18 |
532057079 |
THRUST WASHER Price: $1.99 |
| 18 |
56-2140 |
SCREW-HH Price: $4.17 |
| 19 |
532160395 |
STEERING SHAFT SUPPORT This part replaces 532124035. Price: $8.99 |
| 19 |
92-0285 |
COUPLING ASM Price: $481.76 |
| 20 |
596582301 |
Washers This part replaces 532126684. Price: $2.99 |
| 21 |
596029801 |
WASHER SPRING LOCK WASHER WITH This part replaces 810040400. Price: $2.99 |
| 22 |
532165857 |
SCREW.HX.WSH.HD This part replaces 871100410. Price: $3.99 |
| 23 |
532156365 |
PITMAN SHAFT ASSY This part replaces 532127501. Price: $29.99 |
| 25 |
532154406 |
BRACKET STEERING Price: $6.99 |
| 27 |
532136874 |
GEAR.SECTOR Price: $69.99 |
| 29 |
534200501 |
BOLT HEX PATCH 3/8-16X3/4 This part replaces 817490612. Price: $1.99 |
| 32 |
532171888 |
TIE ROD This part replaces 532139929. Price: $59.99 |
| 33 |
596204101 |
WASHER 11/32 X 11/16 X 14 GA T This part replaces 819111216. Price: $2.99 |
| 34 |
596029801 |
WASHER SPRING LOCK WASHER WITH This part replaces 810040400. Price: $2.99 |
| 36 |
532155106 |
KIT.BUSHING.STEERING This part replaces 532155099. Price: $8.99 |
| 37 |
532152927 |
SCREW.TT.#10-32X.5.3/8.FLANGE Price: $3.99 |
| 38 |
532124416 |
INSERT,STR WHEEL Price: $7.89 |
| 39 |
583789501 |
WASHER.13/32x2 3/8x12GA This part replaces 819133808. Price: $4.99 |
| 40 |
873610600 |
NUT This part replaces 532124701. Price: $2.99 |
| 41 |
587738905 |
KIT.SRVC.STEERINGSHAFT.ADAPTER This part replaces 532100711. Price: $7.99 |
| 42 |
532145054 |
STEERING BOOT, GRAY This part replaces 532155092. Price: $11.99 |
| 43 |
532121749 |
WASHER Price: $2.99 |
| 44 |
532153721 |
SHAFT EXT STEERING This part replaces 532153720. Price: $54.99 |
| 46 |
532121232 |
CAP.SPINDLE.BLACK Price: $3.99 |
| 47 |
532183226 |
FITTING.GREASE.TAPERED This part replaces 532124836. Price: $4.99 |
| 51 |
596040501 |
Hardware This part replaces 873800500. Price: $2.99 |
| 54 |
595305701 |
Screws This part replaces 874780520. Price: $3.99 |
| 62 |
584371701 |
KIT.STEER.ASM.P/L This part replaces 532156594. Price: $119.99 |
| 63 |
596564401 |
Bolts This part replaces 874780616. Price: $3.99 |
| 65 |
531152101 |
SERVICE KIT SPACER AXLE SPACER This part replaces 532145780. Price: $17.99 |
| 66 |
532154404 |
BEARING ARM Price: $3.99 |
| 67 |
874781044 |
Bolt, Hex 5/8 -11 x 2 - 3/4 Gr. 5 Price: $3.99 |
| 68 |
532154429 |
AXLE, BRACE Price: $11.99 |
