| Ref | Part Number | Description |
|---|
| 1 |
2411-32 |
JOINT-BALL RH Price: $28.17 |
| 2 |
3220-2 |
NUT-JAM Price: $0.50 |
| 2 |
532149723 |
MUFFLER.TWIN.CYL.LOW.TONE Price: $39.99 |
| 3 |
49-6320 |
DISCONTINUED Price: Call Us |
| 4 |
83-0540-01 |
TRACTION PEDAL ASM This part replaces 83-0540. Price: $70.97 |
| 5 |
49-6470 |
DISCONTINUED Price: Call Us |
| 6 |
49-6440-03 |
PEDAL-FORWARD This part replaces 49-6440. Price: $84.90 |
| 7 |
32121-45 |
PIN-SPRING Price: $0.27 |
| 8 |
49-6430 |
REVERSE PAD Price: $58.99 |
| 9 |
3234-1 |
SCREW-HHF Price: $1.62 |
| 9 |
532408667 |
KEEPER BELT ENGINE Price: $9.99 |
| 10 |
47-5320-01 |
LEVER This part replaces 47-5320. Price: $84.02 |
| 11 |
32121-6 |
PIN-ROLL, SLOTTED Price: $0.28 |
| 11 |
532179335 |
CLUTCH MZ ZTR GT.48/54"1.125" Price: $299.99 |
| 12 |
27-2320 |
BEARING Price: $15.22 |
| 12 |
532194343 |
PULLEY ENGINE Price: $39.99 |
| 13 |
44-0870 |
CAM SHAFT ASM Price: $213.32 |
| 14 |
283-57 |
PIN-CLEVIS Price: $1.15 |
| 15 |
49-6220 |
BRACKET-ARM, CONTROL Price: $28.06 |
| 15 |
532422804 |
TANK FUEL Price: $149.99 |
| 16 |
49-6260 |
PIVOT ASM Price: $79.73 |
| 17 |
12-3270 |
SCREW Price: $3.09 |
| 18 |
49-6290 |
PIVOT SHAFT ASM Price: $25.43 |
| 18 |
584248702 |
CAP.ASSY.FUEL.3".N-EPA.GRY.498 This part replaces 532439645. Price: $14.99 |
| 19 |
HY3225 |
DISCONTINUED This part replaces 322-5. Price: Call Us |
| 20 |
233-48 |
KNOB Price: $10.92 |
| 20 |
586219601 |
CONTROL.THROTTLE/CHOKE.PRO.45 This part replaces 532424340. Price: $54.99 |
| 21 |
596321701 |
Screws This part replaces 532416358. Price: $2.99 |
| 21 |
68-5930 |
TRACTION HANDLE WA Price: $79.71 |
| 22 |
256-251 |
BUSHING Price: $2.46 |
| 23 |
3272-4 |
PIN-COTTER Price: $0.25 |
| 25 |
302-5 |
FITTING-GREASE Price: $0.59 |
| 26 |
92-1193 |
MAIN FRAME ASM Price: $3,517.62 |
| 27 |
131-4307 |
PIN This part replaces 68-5560. Price: $15.61 |
| 28 |
322-3 |
SCREW-HH Price: $0.79 |
| 28 |
587044854 |
HOSE.1/4".LOW.PERM.FUEL.LN.54" This part replaces 532142158. Price: $14.99 |
| 29 |
532137180 |
KIT.SPARK ARRESTOR 794945 B&S Price: $109.99 |
| 29 |
58-5830 |
HOSE ASM Price: $114.66 |
| 30 |
340-103 |
FITTING-HYD, 45 DEG Price: $36.92 |
| 31 |
125-5196 |
BUSHING This part replaces 3-0348. Price: $6.00 |
| 32 |
68-5380 |
CENTER LIFT ARM ASM Price: $205.86 |
| 33 |
63-8750 |
PIN-PIVOT Price: $4.20 |
| 34 |
10-7820 |
PIVOT HINGE ASM Price: $504.57 |
| 35 |
10-8110 |
WASHER-THRUST Price: $1.09 |
| 36 |
302-60 |
FITTING-GREASE Price: $2.26 |
| 37 |
131-4295 |
PIN-PIVOT This part replaces 10-6090. Price: $51.39 |
| 37 |
532123487 |
HOSE CLAMP Price: $3.99 |
| 38 |
3253-4 |
WASHER-LOCK Price: $0.25 |
| 39 |
322-1 |
SCREW-HH Price: $0.22 |
| 40 |
57-7650 |
SPRING-TORSION Price: $11.81 |
| 41 |
532126197 |
WASHER Price: $6.99 |
| 41 |
62-2420-01 |
BAR ASM-LIFT, CTR ARM This part replaces 62-2420. Price: $70.22 |
| 42 |
3256-26 |
WASHER-FLAT Price: $0.39 |
| 42 |
596238901 |
Washers This part replaces 810040700. Price: $2.99 |
| 43 |
3272-11 |
PIN-COTTER Price: $0.99 |
| 44 |
302-2 |
FITTING-GREASE Price: $1.89 |
| 45 |
105-3823 |
HYD CYLINDER ASM This part replaces 83-7230. Price: $493.03 |
| 45 |
586668901 |
NUT HEX_LRG FLG_1_4-20_LOCK This part replaces 873510400. Price: $3.99 |
| 46 |
237-78 |
O-RING Price: $3.85 |
| 47 |
237-21 |
O-RING This part replaces 237-35. Price: $0.70 |
| 48 |
88-9700 |
HOSE-HYD Price: $64.30 |
| 49 |
3296-29 |
NUT-LOCK, NI Price: $2.09 |
| 50 |
121-4600 |
NUT-HEX This part replaces 3296-59. Price: $0.78 |
| 51 |
3256-24 |
WASHER-FLAT Price: $0.28 |
| 52 |
3256-3 |
WASHER-FLAT Price: $0.49 |
| 53 |
3211-1 |
SCREW-HH Price: $0.74 |
| 54 |
3254-6 |
WASHER-LOCK, INTERNAL Price: $0.31 |
| 55 |
49-6250 |
BRACKET-PIVOT Price: $22.09 |
| 56 |
HY2562 |
DISCONTINUED This part replaces 256-2. Price: Call Us |
| 57 |
115-3260 |
KIT-SERVICE, PIN This part replaces 27-2550. Price: $33.44 |
| 58 |
302-11 |
FITTING-LUBE, 45 DEG Price: $1.56 |
| 59 |
3256-23 |
WASHER-PLAIN Price: $0.28 |
| 60 |
62-5070 |
DECAL-WARNING Price: $5.59 |
| 61 |
136-8446 |
KIT, CENTER PULL FRAME This part replaces 86-9820. Price: $340.89 |
| 62 |
256-219 |
BUSHING Price: $7.59 |
| 62 |
531154901 |
SERVICE KIT HEAT SHIELD This part replaces 532434017. Price: $11.99 |
| 63 |
32128-20 |
NUT-HF Price: $0.99 |
| 64 |
17-9420 |
SCREW-HANDLE Price: $3.49 |
| 65 |
3296-4 |
NUT-LOCK Price: $0.25 |
| 66 |
92-1194 |
DISCONTINUED Price: Call Us |
| 69 |
321-3 |
SCREW-HH Price: $0.28 |
| 69 |
532165391 |
GASKET.MUFFLER Price: $9.99 |
| 70 |
2412-41 |
CLAMP-R Price: $4.82 |
| 70 |
581881101 |
EXHAUST.TUBE.LH.BS/TWIN This part replaces 532159955. Price: $27.99 |
| 71 |
3256-1 |
WASHER-FLAT Price: $0.39 |
| 71 |
581881001 |
EXHAUST.TUBE.RH.B&S.TWIN.INTEK This part replaces 532160589. Price: $22.99 |
| 72 |
3296-16 |
NUT-LOCK, NI Price: $1.39 |
| 73 |
88-6900 |
FOOTREST PLATE *R Price: $134.96 |
| 74 |
32144-14 |
SCREW-HWHTF Price: $4.29 |
| 75 |
5-1228 |
Washer-Shim Price: Call Us |
| 76 |
27-2540 |
EUB SPACER Price: $20.87 |
| 77 |
3256-22 |
WASHER-FLAT Price: $0.39 |
| 79 |
596134202 |
Screws This part replaces 532183906. Price: $2.99 |
| 81 |
532148456 |
TUBE, DRAIN OIL ASM. Price: $5.99 |
| 82 |
532428287 |
VALUE.OIL.DRAIN Price: $14.99 |
| 84 |
817060620 |
SCREW.3/8-16 Price: $5.99 |
| 85 |
501606601 |
BOLT.HEX.7/16-20X3.75.GR5.RED This part replaces 532179953. Price: $3.99 |
| 87 |
532198239 |
BOLT.5/16-18UNCX1.W/SEMS.BLK Price: $3.99 |
| 90 |
817000616 |
SCREW 3/8-16X1 Price: $5.99 |
| 91 |
532187495 |
BUSHING.1.375OD Price: $4.99 |
| 116 |
539132624 |
KNOB - SHIFT Price: $6.99 |
