| Ref | Part Number | Description |
|---|
| 1 |
06401015 |
WSHR,FLT .531X1.062X.095 ZCC This part replaces 06430200. Price: $0.95 |
| 2 |
09286251 |
WMT, MECHANICAL LIFT Price: $193.95 |
| 3 |
09215200 |
BUSHING, .516X1.000X1.050 LG Price: $31.95 |
| 4 |
05901905 |
BLT, HEX .50-13X5.00 GR5 ZCC This part replaces 05962200. Price: $4.95 |
| 5 |
07000031 |
BEARING, PEDESTAL Price: $74.45 |
| 6 |
06401118 |
WSHR, FLT .656X1.313X.095 ZCC This part replaces 06442800. Price: $2.45 |
| 7 |
05709200 |
RG-RTNG-EXT .625X.050 Price: $2.45 |
| 8 |
06500822 |
NUT-LK-TOP-FLG .38-16 ZC120 This part replaces 06542000. Price: $0.95 |
| 9 |
00586551 |
MECH DECK LIFT LOCK LEVER- BLK Price: Call Us |
| 10 |
09299451 |
WMT, MECH LIFT COVER Price: $40.45 |
| 11 |
09291500 |
WMT, MECH. LIFT SHAFT (.62) Price: $134.95 |
| 12 |
05901817 |
BLT, HEX .38-16X3.25 G5 ZCC This part replaces 05961100. Price: $3.95 |
| 13 |
01593500 |
PIN, SPRING BALL .375OD X 1.50 Price: $5.45 |
| 14 |
06500907 |
NUT-LK-TOP-FLG .500-13 GF ZCC This part replaces 06543600. Price: $1.45 |
| 15 |
05532100 |
BSHG-FLG .515X.750X.285X1.120 Price: $6.25 |
| 16 |
09291200 |
LATCH, FOOTBOARD Price: $11.45 |
| 17 |
09252000 |
WASHER-WAVE .760X1.120X.080 Price: $3.45 |
