Internal Power Unit
Parts (60)
| Ref | Part Number | Description |
|---|---|---|
| 1 | 137-6115 | TUBE ROLLER 3.0IN DIA X 20.5IN This part replaces 115-8296-03. Price: $139.68 |
| 1 | 530016282 | Bar Mounting Nut Price: $1.99 |
| 2 | 114-5410 | SHAFT-SHORT, REAR ROLLER Price: $128.74 |
| 2 | 952069320 | Chain Brake Ass'y. Price: Call Us |
| 3 | 114-3717 | SEAL-OIL Price: $2.77 |
| 3 | 530403094 | Nut This part replaces 534235901. Price: $1.99 |
| 4 | 112-5290 | BEARING-STEEL, STAINLESS Price: $12.64 |
| 4 | 530023064 | Bar Adjust Pin Price: $3.99 |
| 5 | 112-7494 | SEAL Price: $6.37 |
| 5 | 530016256 | Screw Price: $1.99 |
| 6 | 114-5411 | NUT-LOCK, BEARING Price: $24.46 |
| 6 | 530036450 | Oil Tank Vent Pin Price: $0.99 |
| 7 | 302-5 | FITTING-GREASE Price: $0.59 |
| 7 | 530015719 | Bar Mounting Stud Price: $1.99 |
| 9 | 530015623 | Screw Price: $1.99 |
| 11 | 530019059 | Crankshaft Seal Price: $4.99 |
| 12 | 530019089 | Check Valve Gasket Price: $3.99 |
| 13 | 530015476 | Screw Price: $1.99 |
| 14 | 530023802 | Oil Pump Cover Price: $1.99 |
| 15 | 530019091 | Oil Pump Gasket Price: $1.99 |
| 16 | 530023801 | Oil Filter Price: $1.99 |
| 17 | 530010195 | Oil Pump Body Ass'y. Price: Call Us |
| 18 | 530032029 | Crankshaft Bearing Price: $7.99 |
| 20 | 530022172 | Crankshaft Price: $44.99 |
| 21 | 530069216 | Oil Discharge Line Price: $3.99 |
| 22 | 530069193 | Clutch Ass'y. Kit Price: Call Us |
| 23 | 530069197 | Clutch Washer Kit Price: $7.99 |
| 24 | 530015169 | Screw Price: $1.99 |
| 25 | 530023795 | Muffler Cover Price: $10.99 |
| 26 | 530023843 | Piston Pin Retainer Price: $1.99 |
| 27 | 530023887 | Thrust Washer Price: $0.99 |
| 28 | 530010444 | Oil Cap Ass'y. Price: $3.92 |
| 29 | 530069166 | Clutch Drum & Brg. Kit Price: $11.99 |
| 30 | 530032079 | Clutch Bearing Price: $5.99 |
| 31 | 530023519 | Muffler Spacer Price: $1.99 |
| 32 | 530023535 | Spacer Price: $1.99 |
| 33 | 530023796 | Spark Arrestor Screen Price: $2.99 |
| 35 | 530001666 | Screw Price: $0.99 |
| 36 | 530069401 | Engine Gasket Kit This part replaces 530019237. Price: $11.99 |
| 37 | 530037603 | Piston Ring Price: $2.99 |
| 38 | 530023788 | Knob Switch Price: $2.99 |
| 39 | 530023786 | Ramp Switch Price: $1.99 |
| 40 | 530015986 | Screw Price: $0.99 |
| 41 | 530023797 | Muffler Baffle Price: $1.99 |
| 42 | 530038325 | Muffler Body Price: $3.99 |
| 43 | 530053688 | Switch Clamp Insulator Price: $1.99 |
| 44 | 530015235 | Screw Price: Call Us |
| 45 | 530030054 | Crankcase Sealant Price: $17.99 |
| 46 | 503235111 | BPMR7A NGK SPARK PLUG This part replaces 952030150. Price: $3.99 |
| 47 | 530012172 | Cylinder Price: $64.99 |
| 48 | 530015239 | Screw Price: $1.99 |
| 49 | 530015486 | Washer Price: $2.99 |
| 50 | 114-5430 | ROLLER REBUILD KIT Price: $99.53 |
| 50 | 530032075 | Bearing Rod Top Price: $5.99 |
| 52 | 530047952 | Kickback Decal Price: $1.99 |
| 53 | 530019255 | Gasket-Muffler Price: $2.99 |
| 54 | 530038643 | Muffler-Back Plate Price: $1.99 |
| 55 | 530037652 | Port-Insulator Price: $1.99 |
| 56 | 530053689 | On/Off Decal Warning Price: $1.99 |
| 57 | 530039116 | Switch Lead Wire Price: $3.99 |
