| Ref | Part Number | Description |
|---|
| 1 |
531151701 |
SERVICE KIT TUBE TUBE.HANDLE.B This part replaces 532428610. Price: $14.99 |
| 1 |
98-7417 |
PLATE-ELEMENT Price: $2.18 |
| 1 |
MA-10351805AG0 |
BRAKE SHAFT Not Available Price: |
| 2 |
583765001 |
APPLIQUE BAGGER This part replaces 532447572. Price: $34.99 |
| 2 |
98-7418 |
PLATE-ELEMENT Price: $3.79 |
| 2 |
MA-07961025200 |
BUSHING Not Available Price: |
| 3 |
98-7419 |
ELEMENT-BREATHER Price: $1.72 |
| 3 |
MA-07400002500 |
RING-"C" Not Available Price: |
| 4 |
98-7420 |
SHIELD-BREATHER, OIL Price: $5.59 |
| 4 |
MA-11931812000 |
COVER,PEDAL Not Available Price: |
| 5 |
583570401 |
TCRD.II.UPR.PIVOT TUBE.WLDMT This part replaces 532443762. Price: $109.99 |
| 5 |
98-7421 |
SCREW W/WASHER Price: $0.24 |
| 5 |
MA-10351815AG0 |
PEDAL (LH) BRAKE Not Available Price: |
| 6 |
98-7422 |
JOINT-PIPE, BREATHER Price: $11.13 |
| 6 |
MA-10351816AG0 |
PEDAL (RH) BRAKE Not Available Price: |
| 7 |
98-7423 |
PIPE-BREATHER Price: $8.51 |
| 8 |
583825901 |
BAGGER.TOP This part replaces 532447575. Price: $169.99 |
| 8 |
98-7424 |
CLAMP-PIPE Price: $6.82 |
| 9 |
98-7425 |
COVER-HEAD, CYLINDER Price: $373.42 |
| 9 |
MA-05500008045 |
Pin, Spring Price: $2.10 |
| 10 |
583825801 |
BAGGER.FRAME.LOW.UTUBE.TEX.CRD This part replaces 532443755. Price: $29.99 |
| 10 |
98-7426 |
GASKET-COVER, HEAD Price: $42.36 |
| 10 |
MA-07961025200 |
BUSHING Not Available Price: |
| 11 |
98-7427 |
NUT-CAP Price: $6.64 |
| 11 |
MA-07400002500 |
RING-"C" Not Available Price: |
| 12 |
98-7428 |
GASKET Price: $0.68 |
| 12 |
MA-27918569001 |
SPRING-PEDAL RETUR Not Available Price: |
| 13 |
107-9075 |
PLUG-FILLER, OIL This part replaces 98-7429. Price: $7.25 |
| 15 |
MA-10351831AG0 |
LEVER-PARK Not Available Price: |
| 16 |
MA-F1540108025 |
BOLT,W/SPRING WASH Not Available Price: |
| 17 |
MA-03500160826 |
WASHER Not Available Price: |
| 18 |
MA-67700-26000 |
COLLAR Not Available Price: |
| 19 |
532194208 |
PIN.COTTER.5/16.BOW TI Price: $2.99 |
| 19 |
MA-10351834000 |
RUBBER Not Available Price: |
| 20 |
MA-11352230000 |
SPRING Not Available Price: |
| 21 |
581337103 |
BAGGER.ASM.FABRIC.CRD.GII.HUSQ Price: $109.99 |
| 21 |
MA-14212284000 |
GRIP Not Available Price: |
| 22 |
MA-07310101204 |
LINER Not Available Price: |
| 24 |
MA-10351818000 |
BRAKE ROD CLEVIS A Not Available Price: |
| 25 |
MA-10351819AG0 |
BRAKE ROD CLEVIS B Not Available Price: |
| 26 |
MA-27870395000 |
JOINT-BRAKE ROD Not Available Price: |
| 27 |
583580401 |
RUBBER.GROMMET.DUMP.TUBE.CRDII This part replaces 532445529. Price: $4.99 |
| 27 |
MA-A3030110002 |
NUT Not Available Price: |
| 28 |
532165787 |
GRIP.HANDLE.BLACK Price: $5.99 |
| 28 |
MA-A3032110002 |
NUT Not Available Price: |
| 30 |
MA-10371814AG0 |
SHAFT (RH) L Not Available Price: |
| 31 |
MA-10351826AG0 |
LINK (RH) BR Not Available Price: |
| 32 |
MA-F1550110020 |
BOLT,W/SPRING WASH Not Available Price: |
| 33 |
MA-07400102200 |
RING, SNAP Not Available Price: |
| 34 |
MA-A6503100300 |
NIPPLE-GREASE Not Available This part replaces MA-A6513100300. Price: |
| 35 |
MA-A3010110002 |
NUT Not Available Price: |
| 36 |
MA-10351827000 |
BRAKE ROD Not Available Price: |
| 37 |
MA-10351828000 |
STOPPER-BO Not Available Price: |
| 38 |
MA-05620108025 |
PIN Not Available Price: |
| 42 |
583548101 |
CHRISTMAS.TREE.CLIP This part replaces 532440428. Price: $2.99 |
| 43 |
532126875 |
RIVET,DRILLED Price: $2.99 |
| 44 |
532199687 |
SCREW Price: $2.99 |
| 45 |
583570301 |
TCRD.-GEN2.UPPR.U.FRAME.WLDMT This part replaces 532443754. Price: $99.99 |
| 46 |
583580501 |
LH.BGGR.CRNER.CLOSE-OUT.TEXCRD This part replaces 532445541. Price: $7.99 |
| 48 |
583573101 |
TOP.BGGR.SIDE.CLOSE-OUT.TCRDII This part replaces 532444080. Price: $7.99 |
| 49 |
532171873 |
BOLT, SHOULDER 5/16-18 Price: $4.99 |
| 50 |
532171877 |
BOLT.5/16-18UNCX3/4 W/SEMS.BLK Price: $4.99 |
| 51 |
872110506 |
BOLT.CARR.SQNK.5/16-18UNC.X3/4 Price: $3.99 |
| 52 |
596040501 |
Hardware This part replaces 873800500. Price: $2.99 |
| 53 |
583573601 |
BRACKET.DUMP.HANDLE.TEX.CRD.G2 This part replaces 532444195. Price: $8.99 |
| 54 |
583827701 |
BAGGER TOP.FRONT.HANDLE This part replaces 532447218. Price: $12.99 |
| 55 |
596030801 |
Bolts This part replaces 872140512. Price: $3.99 |
| 56 |
532420306 |
PIN.CLEVIS.183 Price: $7.99 |
| 59 |
583826601 |
BAGGER SPRD.TUBE.TEX.CRD.GEN2 This part replaces 532444763. Price: $19.99 |
| 65 |
532004497 |
RETAINER M This part replaces 532124788. Price: $4.99 |
| 69 |
583392101 |
SCREW,#8.FLAT.HEAD.DRILL.TIP This part replaces 532421801. Price: $3.99 |
| 70 |
817000612 |
SCREW, 3/8-16X3/4 Price: $3.99 |
| 83 |
596322601 |
Nuts This part replaces 873800600. Price: $2.99 |
| 84 |
596728201 |
Bolts This part replaces 872110608. Price: $3.99 |
| 85 |
581314402 |
BRACKET.RH.PIVOT.MAN.DUMP.BLAC Price: $17.99 |
| 86 |
581314302 |
BRACKET.LH.PIVOT.MAN.DUMP.BLAC Price: $14.99 |
| 87 |
581314802 |
BRACKET.RH.MID.SUP.BAG.TEX.CRD Price: $22.99 |
| 88 |
581314702 |
BRACKET.LH.MID.SUP.BAG.TEX.CRD Price: $49.99 |
| 89 |
581315104 |
TUBE.WELD.OFSET.STRUT.BAG.X431 Price: $24.99 |
| 92 |
586052302 |
BRACKET.PNT.BAGGER.TOP.SUPPORT Price: $27.99 |
| 93 |
586052402 |
BRACKET.PNT.RH.SUPPORT.ATTACH Price: $8.99 |
| 94 |
586052502 |
BRACKET.PNT.LH.SUPPORT.ATTACH Price: $8.99 |
| 95 |
532428867 |
BOLT.HEX.HD.WASHER.5/16-18X.75 This part replaces 817000512. Price: $4.99 |
