| Ref | Part Number | Description |
|---|
| 1 |
98-9508 |
WASHER-SHAFT, R-ARM Price: $0.47 |
| 2 |
137352 |
Muffler Price: Call Us |
| 2 |
98-9385 |
WASHER-FLAT Price: $1.24 |
| 3 |
98-9393 |
NUT Price: $2.72 |
| 4 |
98-9501 |
ROCKER ARM ASM Price: $28.78 |
| 5 |
105-3790 |
R-ARM SHAFT ASM This part replaces 98-9612. Price: $28.61 |
| 6 |
98-9370 |
CLIP-CIRCULAR, EXTERNAL Price: $1.30 |
| 7 |
98-9507 |
WASHER-SHAFT, ROCKER ARM Price: $0.85 |
| 8 |
98-9505 |
BRACKET-ARM, ROCKER Price: $22.17 |
| 9 |
194319 |
Keeper Belt Engine Price: Call Us |
| 9 |
98-9504 |
SPRING-ARM, ROCKER Price: $0.66 |
| 10 |
98-9391 |
SCREW-SET, ROCKER ARM Price: $5.98 |
| 11 |
99-8385 |
SEAL-STEM, VALVE This part replaces 98-9496. Price: $7.29 |
| 12 |
401985 |
Pulley Engine Price: Call Us |
| 12 |
98-9626 |
SPRING-VALVE Price: $10.57 |
| 13 |
107-9092 |
RETAINER-SPRING This part replaces 98-9498. Price: $2.58 |
| 14 |
117-7572 |
COLLET-SPRING, VALVE This part replaces 98-9390. Price: $9.43 |
| 15 |
407545 |
Tank Fuel 1.50 Price: Call Us |
| 15 |
98-9497 |
CAP-VALVE Price: $8.36 |
| 16 |
98-9506 |
STUD Price: $5.98 |
| 17 |
112-7019 |
VALVE-EXHAUST This part replaces 98-9625. Price: $56.65 |
| 18 |
197725 |
Cap Asm Price: Call Us |
| 20 |
176636X421 |
Control Throttle/Choke Price: Call Us |
| 21 |
191611 |
Screw 10 x 3/4 Single Lead-Hex Price: Call Us |
| 28 |
401137 |
Fuel Line Price: Call Us |
| 29 |
137180 |
Spark Arrester Kit Price: Call Us |
| 37 |
123487X |
Clamp Hose Price: Call Us |
| 42 |
10040700 |
Washer Lock 7/16 Price: Call Us |
| 45 |
73510400 |
Nut Keps Hex 1/4-20 unc Price: Call Us |
| 69 |
165291 |
Gasket Price: Call Us |
| 79 |
192334 |
Screw Socket Hd 5/16-18 x .75 Price: Call Us |
| 81 |
148456 |
Tube Drain Oil Easy Price: Call Us |
| 82 |
181654 |
Plug Drain Oil Price: Call Us |
| 84 |
17060620 |
Screw 3/8-16 x 1-1/4 Price: Call Us |
| 85 |
173937 |
Bolt Hex 7/16-20 x 4 x Gr. 5-1.5 Price: Call Us |
| 90 |
17000616 |
Screw 3/8-16 x 1.0 Price: Call Us |
| 96 |
19091416 |
Washer 9/32 x 7/8 x 16 Price: Call Us |
