| Ref | Part Number | Description |
|---|
| 1 |
137-6120 |
LONG REAR ROLLER ASM (3IN DIA)(27IN) This part replaces 112-8915. Price: $448.76 |
| 1 |
873800500 |
Nut, Lock Hex w/Ins 5/16-18 (AYP part number) Price: $2.99 |
| 2 |
104-8300 |
NUT-HF, NI Price: $0.39 |
| 2 |
539976934 |
HCS 5/16C X 3/4 This part replaces 874760512. Price: $1.99 |
| 3 |
119-0626 |
SHIM-ROLLER Price: $3.23 |
| 3 |
532141341 |
Keeper, Mower Drive, R.H. (AYP part number) Price: $4.99 |
| 4 |
532138029 |
Pulley, Engine (AYP part number) Price: $49.99 |
| 5 |
106-3924 |
BRACKET-ROLLER, REAR Price: $23.58 |
| 5 |
539990247 |
WASHER 7/16 LOCK This part replaces 810040700. Price: $1.99 |
| 6 |
3230-26 |
SCREW-CARR Price: $3.99 |
| 6 |
871170744 |
Bolt, Hex Hd. 7/16-20 UNF Grade 5 (AYP part number) Price: $2.99 |
| 7 |
117-0960 |
PLASTIC WIEHLE ROLLER ASM Price: $482.64 |
| 7 |
532124525 |
Traction, V-Belt Drive (AYP part number) Price: $34.99 |
| 8 |
532164173 |
KEEPER.BELT.ENGINE This part replaces 532123405. Price: $4.99 |
| 9 |
32128-20 |
NUT-HF Price: $0.99 |
| 9 |
872140612 |
Bolt, Carriage 3/8-16 UNC x 1-1/2 (AYP part number) Price: $2.99 |
| 10 |
322-16 |
SCREW-HH Price: $3.39 |
| 10 |
532123396 |
Keeper, Ground Drive Belt Idler (AYP part number) Price: $4.99 |
| 11 |
3231-4 |
SCREW-CARR Price: $3.59 |
| 11 |
532140911 |
Arm, Ground Drive Clutch (AYP part number) Price: $4.35 |
| 12 |
120-0404 |
BRACKET-HIGH HOC (LH) Price: $71.73 |
| 12 |
120-0405 |
BRACKET-HIGH HOC (RH) Price: $71.73 |
| 12 |
532123674 |
Idler, Flat (AYP part number) Price: $17.99 |
| 13 |
104-8301 |
NUT-HF, NI Price: $1.09 |
| 13 |
819131316 |
Washer 13/32 x 13/16 x 16 Gauge (AYP part number) Price: $2.99 |
| 14 |
48-9220 |
WASHER-PLAIN Price: $0.87 |
| 14 |
873680600 |
LOCKNUT This part replaces 873930600. Price: $1.99 |
| 15 |
107-4026 |
SCREW-HH Price: $5.28 |
| 15 |
873680600 |
LOCKNUT This part replaces 873800600. Price: $1.99 |
| 16 |
532126472 |
Clip, Insulated (AYP part number) Price: $2.45 |
| 16 |
94-6936 |
WASHER-HARDENED Price: $0.58 |
| 17 |
532165723 |
SPACER.RETAINER.MOWER This part replaces 532122052. Price: $2.99 |
| 18 |
532131459 |
Spring, Extension (AYP part number) Price: $4.99 |
| 19 |
873510500 |
Nut, Hex, Keps 5/16-18 UNC (AYP part number) Price: $5.99 |
| 20 |
532139919 |
Keeper, T/A, Ground Drive Belt (AYP part number) Price: $2.99 |
| 21 |
819111016 |
Washer 11/32 x 5/8 x 16 Gauge (AYP part number) Price: $5.99 |
| 22 |
532123404 |
Keeper, Frame Ground Drive Belt (AYP part number) Price: $3.22 |
