Operator Platform Assembly
Parts (38)
| Ref | Part Number | Description |
|---|---|---|
| 1 | 5-0652 | SPACER Price: $5.35 |
| 2 | 94-2413 | NUT-U Price: $1.79 |
| 3 | 99-5107 | NUT-LOCK Price: $1.77 |
| 4 | 104-8300 | NUT-HF, NI Price: $0.39 |
| 5 | 104-8301 | NUT-HF, NI Price: $1.09 |
| 6 | 138-8134 | GROMMET-WEB Price: $3.05 |
| 7 | 110-5954 | MOUNT-CENTER, BONDED Price: $65.28 |
| 8 | 115-5519 | WASHER-PLAIN Price: $7.28 |
| 9 | 120-4654 | SCREW-HHF Price: $0.34 |
| 11 | 138-2982-03 | MOUNT-BEACON Price: $48.07 |
| 12 | 136-7176 | WASHER-FENDER Price: $0.73 |
| 13 | 136-9630-03 | STEP Price: $158.53 |
| 14 | 136-9791 | PLUG-PANEL Price: $3.37 |
| 15 | 136-9996-03 | FENDER-FRONT, RH Price: $86.28 |
| 16 | 136-9997-03 | FENDER-FRONT, LH Price: $80.54 |
| 17 | 138-1861-0P | BRACKET-SEAL Price: $104.47 |
| 18 | 138-2015 | FOAM-LH Price: $17.83 |
| 19 | 138-2016 | FOAM-RH Price: $12.66 |
| 20 | 104-7201 | NUT-HF Price: $0.69 |
| 21 | 138-2716 | ROOF-SHORT Price: $347.86 |
| 22 | 3234-17 | SCREW-HHF Price: $0.72 |
| 23 | 3234-40 | SCREW-HF Price: $3.38 |
| 24 | 3234-42 | SCREW-HHF Price: $1.10 |
| 25 | 107069 | CLIP Price: $1.79 |
| 26 | 108-8452 | DECAL-LOGO Price: $18.00 |
| 28 | 138-8046-0P | ROOF-INSERT [PRIMED] Price: $123.76 |
| 29 | 117-2382 | PLUG-PLASTIC Price: $0.69 |
| 30 | 107069 | CLIP Price: $1.79 |
| 31 | 3229-2 | SCREW-CARR Price: $2.89 |
| 32 | 138-2949-0P | PLATE-RETAINER Price: $4.63 |
| 33 | 139-2065-03 | MOUNT-LIGHT, WORK Price: $29.13 |
| 34 | 139-1926-03 | BRACKET-LIGHT, WORK Price: $12.74 |
| 35 | 119-8096 | BEACON ASM Price: $214.06 |
| 36 | 119-8095 | SOCKET-BEACON Price: $92.07 |
| 37 | 122-0371 | LIGHT-WORK, LED Price: $183.46 |
| 38 | 119-4036 | SCREW-HHF Price: $0.53 |
| 39 | 115-5103 | SCREW-HHF Price: $0.34 |
| 40 | 126-0699 | BOLT-CARR Price: $7.38 |
