| Ref | Part Number | Description |
|---|
| 1 |
27-6861 |
SHAFT-FLANGED AXLE, LH Price: $984.28 |
| 1 |
510261802 |
PLATE, OUTER BRAKE, BLACK Price: $34.99 |
| 2 |
510206703 |
PLATE, BRAKE LATCH, BLACK Price: $24.99 |
| 2 |
99-6969 |
SEAL-OIL, WHEEL END This part replaces 21-8330. Price: $14.71 |
| 3 |
21-8180 |
BEARING ASM Price: $65.11 |
| 3 |
580528002 |
PLATE.DECK HEIGHT.PNT.431.RZ Price: $11.99 |
| 4 |
21-9450 |
SHIELD-DUST Price: $45.14 |
| 4 |
510240502 |
PLATE, DECK HEIGHT, BLACK Price: $14.99 |
| 5 |
43-6810 |
SPIDER-TORQUE Price: $138.50 |
| 5 |
598712401 |
PLATES This part replaces 522842902. Price: $99.99 |
| 6 |
21-9390 |
SOCKET-SCREW, ADJUSTING Price: $5.56 |
| 6 |
522719504 |
FOOT.REST.MED.ORANGE Price: $89.99 |
| 7 |
21-9370 |
SCREW-ADJUSTING Price: $18.80 |
| 7 |
522443302 |
MOUNT, STRUT, RT, BLK Price: $19.99 |
| 8 |
21-9380 |
NUT-PIVOT Price: $26.77 |
| 8 |
522443304 |
MOUNT, STRUT, LT, BLK Price: $349.99 |
| 9 |
242-34 |
STUD-DRIVE Price: $11.61 |
| 9 |
510225902 |
SUPPORT, FENDER, BLACK Price: $54.99 |
| 10 |
21-8360 |
CLIP-RETAINING Price: $1.29 |
| 10 |
589283402 |
FRAME.TUBE.RZ.MAIN.WELD.RH.ORG This part replaces 510177503. Price: $79.99 |
| 11 |
28-0680-03 |
DRUM-BRAKE This part replaces 28-0680. Price: $358.84 |
| 11 |
589283302 |
FRAME.TUBE.RZ.MAIN.WELD.LH.ORG This part replaces 510177403. Price: $79.99 |
| 12 |
510177603 |
FRAME TUBE, REAR ORG Price: $110.99 |
| 12 |
99-5694 |
NUT W/WASHER This part replaces 43-6800. Price: $3.86 |
| 13 |
28-0670 |
SEAL-GREASE Price: $19.74 |
| 13 |
597783101 |
GSPW Knobs This part replaces 539104411. Price: $3.99 |
| 14 |
21-9440 |
SPRING-SCREW, ADJUSTING Price: $11.92 |
| 14 |
539114789 |
SWIVEL Price: $11.99 |
| 15 |
21-9460 |
RETAINER-LEVER, BRAKE Price: $2.18 |
| 15 |
521938102 |
Links This part replaces 521938101. Price: $12.99 |
| 16 |
43-2690 |
SEE PB #747 Price: Call Us |
| 16 |
580486102 |
Spacers This part replaces 580486101. Price: $3.99 |
| 17 |
21-9420 |
SPRING-RETURN, LH Price: $19.96 |
| 17 |
539102587 |
GROMMET, BUMPER Price: $4.99 |
| 18 |
21-9430 |
SPRING-RETURN, RH Price: $19.96 |
| 18 |
510016504 |
Pins This part replaces 510016503. Price: $4.99 |
| 19 |
24-9180 |
STRUT AND LEVER ASM Price: $86.76 |
| 19 |
596917002 |
Screws This part replaces 539110674. Price: $1.99 |
| 20 |
21-8320 |
REFER TO(PB#807 OR MISC COMM SB#50) Price: Call Us |
| 20 |
596218601 |
Bolts This part replaces 874780544. Price: $3.99 |
| 21 |
874780564 |
BOLT Price: $4.99 |
| 21 |
99-5691 |
SCREW W/WASHER This part replaces 28-0660. Price: $7.18 |
| 22 |
596434801 |
Bolts This part replaces 874780536. Price: $2.99 |
| 23 |
596230901 |
Screws This part replaces 874780416. Price: $2.99 |
| 24 |
596564405 |
Bolts This part replaces 874780648. Price: $2.99 |
| 25 |
872141608 |
Price: Call Us |
| 26 |
817490642 |
Price: Call Us |
| 27 |
596433701 |
GSPW Washers This part replaces 819141614. Price: $2.99 |
| 28 |
596204101 |
WASHER 11/32 X 11/16 X 14 GA T This part replaces 819111116. Price: $2.99 |
| 29 |
596582301 |
Washers This part replaces 819091016. Price: $2.99 |
| 30 |
596230801 |
Nuts This part replaces 539200282. Price: $2.99 |
| 31 |
594944401 |
NUT HEXAGON FLANGE 5/16-18 ST This part replaces 539112899. Price: $5.99 |
| 32 |
521996502 |
GSPW Nuts This part replaces 521996501. Price: $2.99 |
| 33 |
595901901 |
Nuts This part replaces 539119124. Price: $2.99 |
