| Ref | Part Number | Description |
|---|
| 1 |
163-3530 |
CYLINDER-HYDRAULIC This part replaces 119-6988. Price: $515.30 |
| 1 |
506985803 |
SPINDLE Price: $179.99 |
| 2 |
163-3534 |
CYLINDER-HYDRAULIC This part replaces 119-6987. Price: $558.76 |
| 3 |
105-7577 |
HYD LIFT BLOCK MANIFOLD ASM Price: $2,721.71 |
| 3 |
738211004 |
BALL BEARING 6010 2RS1 Price: $39.99 |
| 4 |
340-132 |
FITTING-ELBOW, 90 DEG Price: $24.64 |
| 4 |
735314010 |
CIRCLIP SGH 47 Price: $4.99 |
| 5 |
127-2498 |
HOSE ASM Price: $107.67 |
| 5 |
735312600 |
RETAINING RING SGA 25 Price: $2.99 |
| 6 |
127-2499 |
HOSE ASM Price: $99.95 |
| 6 |
506985901 |
SHAFT Price: $44.99 |
| 7 |
127-2497 |
HOSE ASM Price: $64.01 |
| 7 |
735312600 |
RETAINING RING SGA 25 Price: $2.99 |
| 8 |
127-2496 |
HOSE ASM Price: $124.39 |
| 8 |
506773401 |
WASHER Price: $3.99 |
| 9 |
2412-137 |
CLAMP-R, DOUBLE Price: $5.08 |
| 9 |
740681421 |
V-RING Price: $3.99 |
| 10 |
3230-23 |
SCREW-CARR Price: $0.89 |
| 10 |
535406001 |
BRACKET Price: $299.99 |
| 11 |
3234-38 |
SCREW-HHF Price: $3.33 |
| 11 |
506986102 |
BUSHING Price: $14.99 |
| 12 |
3256-6 |
WASHER-FLAT Price: $0.34 |
| 13 |
117-0148 |
PIN-CYLINDER Price: $52.54 |
| 14 |
32120-93 |
RING-RETAINING Price: $2.49 |
| 15 |
3-6498 |
WASHER-THRUST Price: $4.58 |
| 16 |
104-0046 |
PIN-SLIDE, CYLINDER Price: $10.19 |
| 17 |
3290-379 |
TIE-CABLE Price: $0.31 |
| 18 |
104-8300 |
NUT-HF, NI Price: $0.39 |
| 19 |
323-9 |
SCREW-HH Price: $1.29 |
| 20 |
121-4600 |
NUT-HEX This part replaces 3296-59. Price: $0.78 |
| 21 |
127-2477 |
TUBE ASM Price: $78.78 |
| 22 |
340-127 |
NUT-BULKHEAD Price: $2.24 |
| 24 |
340-98 |
FITTING-ELBOW, 90 DEG Price: $31.91 |
| 25 |
3234-14 |
SCREW-HHF Price: $0.61 |
| 26 |
544262101 |
BRACKET Price: $39.99 |
| 27 |
340-18 |
FITTING-HYD, 90 DEG Price: $38.93 |
| 27 |
506566501 |
CLAMP Price: $2.99 |
| 28 |
353-508 |
PLUG-HH Price: $7.96 |
| 28 |
725236461 |
SCREW Price: $2.99 |
| 46 |
506889901 |
DRAW RING Price: $17.99 |
| 47 |
725250071 |
SCREW This part replaces 725250051. Price: $2.99 |
| 48 |
953534901 |
WEIGHT/ REAR BUMPER KIT This part replaces 544039602. Price: $179.00 |
