| Ref | Part Number | Description |
|---|
| 1 |
130-7105 |
FUEL TANK ASM Price: $532.81 |
| 1 |
532123899 |
BATTERY.DRY.30.AMP This part replaces 532144927. Price: $149.99 |
| 2 |
127-8971-03 |
COVER-TANK, FUEL Price: $8.27 |
| 2 |
874760412 |
BOLT.HEX.1/4.X.3/4.DICHROMATE Price: $3.99 |
| 3 |
144-6210 |
PUMP-FUEL This part replaces 121-5641. Price: $157.52 |
| 4 |
131-9550-03 |
BRACKET-TANK, FUEL TANK Price: $279.64 |
| 5 |
108-1605 |
BUMPER-RECESS Price: $10.02 |
| 6 |
107-4543 |
CLAMP Price: $13.47 |
| 7 |
120-9738 |
SCREW-HH This part replaces 322-11. Price: $0.84 |
| 8 |
3256-3 |
WASHER-FLAT Price: $0.49 |
| 8 |
532186491 |
BOX.BATTERY.MOUNT.FRONT.LT Price: $14.99 |
| 9 |
104-8300 |
NUT-HF, NI Price: $0.39 |
| 10 |
3230-1 |
BOLT-CARR Price: $1.49 |
| 11 |
121-6321 |
HOSE-FUEL Price: $24.78 |
| 12 |
98-1375 |
SCREW-HWH Price: $1.45 |
| 13 |
2412-36 |
CLAMP-HOSE Price: $1.28 |
| 14 |
3230-2 |
BOLT-CARR Price: $0.47 |
| 15 |
125-2921 |
FITTING-FUEL Price: $13.96 |
| 16 |
32128-20 |
NUT-HF Price: $0.99 |
| 16 |
532176138 |
SWITCH INTERLOOK PUSH-IN Price: $19.99 |
| 17 |
32128-25 |
NUT-HF Price: $3.19 |
| 21 |
532183759 |
HARNESS ASSY LIGHT Price: $24.99 |
| 22 |
532004152 |
LIGHTBULB Price: $3.99 |
| 24 |
585555601 |
CABLE.FRBATT.W/WIRE.8GA.8 This part replaces 532400253. Price: $7.99 |
| 25 |
532198893 |
CABLE.START.RED.17.5". Price: $11.99 |
| 26 |
532175158 |
FUSE 20AMP Price: $4.99 |
| 27 |
586668901 |
NUT HEX_LRG FLG_1_4-20_LOCK This part replaces 873510400. Price: $3.99 |
| 28 |
532145491 |
CABLE GROUND 6 GA 21" 90T BLK Price: $6.99 |
| 29 |
532401545 |
SWITCH.SEAT.DELTA.OPC. Price: $34.99 |
| 30 |
532193350 |
SWITCH.IGN.DELTA.W.LGH.ROS Price: $19.99 |
| 34 |
532110712 |
SWITCH LT Price: $7.99 |
| 40 |
532401104 |
HARNESS.IGN.DASH.HUQ/P Price: $59.99 |
| 41 |
596437001 |
Screws This part replaces 817720408. Price: $2.99 |
| 42 |
532154336 |
COVER.TERMINAL.RED This part replaces 532131563. Price: $4.99 |
| 43 |
582042802 |
Solenoids This part replaces 532192507. Price: $22.99 |
| 46 |
594919101 |
GUAGE.SRVCMNDR.HRMTR. This part replaces 532401763. Price: $19.99 |
| 50 |
582107601 |
SWITCH.PTO.8TERMINAL.STD.BLK This part replaces 532174651. Price: $24.99 |
| 55 |
532171877 |
BOLT.5/16-18UNCX3/4 W/SEMS.BLK This part replaces 817060512. Price: $4.99 |
| 71 |
532194276 |
HARNESS-CHASSIS SUB Price: $27.99 |
| 90 |
532400724 |
COVER.TERMINAL.BATTERY Price: $3.99 |
| 91 |
532190270 |
STRAP.BATTERY.MOUNT.FRONT(2 2) Price: $7.99 |
| 99 |
817670412 |
SCREW HEXWSHR 1/4-20X3/4 Price: $3.99 |
| 100 |
596135301 |
Washers This part replaces 819091416. Price: $2.99 |
| 101 |
532198317 |
PIGTAIL.MATNLK.NEW.HAR Price: $6.99 |
