| Ref | Part Number | Description |
|---|
| 1 |
302-2 |
FITTING-GREASE Price: $1.89 |
| 2 |
3296-49 |
NUT-LOCK, NI Price: $4.93 |
| 3 |
86-1480 |
WASHER Price: $4.82 |
| 4 |
86-1700 |
SPINDLE PULLEY ASM *B Price: $105.86 |
| 5 |
253-154 |
SEAL-OIL Price: $5.48 |
| 6 |
3234-11 |
SCREW-HHF Price: $1.23 |
| 7 |
69-1530 |
HOUSING-SPINDLE Price: $227.62 |
| 8 |
3290-357 |
NUT-HHF, WHIZ Price: $0.61 |
| 9 |
95-4387 |
SPINDLE SHAFT ASM - CTR This part replaces 86-2340. Price: $155.61 |
| 10 |
138-6416 |
SPACER-SPINDLE, SHAFT This part replaces 92-9800. Price: $18.44 |
| 11 |
86-0010-03 |
BLADE-19" This part replaces 86-0010. Price: $32.86 |
| 12 |
72-9361 |
CUP-SCALP, ANTI Price: $39.78 |
| 14 |
92-5816 |
BOLT-BLADE Price: $4.93 |
| 506543501 |
506543501 |
BUSHING Price: $6.99 |
| 506563801 |
506563801 |
ROLLER Price: $29.99 |
| 506566501 |
506566501 |
CLAMP Price: $2.99 |
| 506576103 |
506576103 |
GUIDE PLATE Price: $30.64 |
| 506595001 |
506595001 |
LEVER Price: $44.99 |
| 506595101 |
535484401 |
TENSIONER This part replaces 506595101. Price: $54.99 |
| 506665601 |
506665601 |
SPRING Price: $24.99 |
| 506773401 |
506773401 |
WASHER Price: $3.99 |
| 506889901 |
506889901 |
DRAW RING Price: $17.99 |
| 506918702 |
584288604 |
Washers This part replaces 506918702. Price: $3.99 |
| 506946901 |
506946901 |
PULLEY Price: $34.99 |
| 506985801 |
506985801 |
Spindle Price: $250.21 |
| 506985901 |
506985901 |
SHAFT Price: $44.99 |
| 506986101 |
506986102 |
BUSHING This part replaces 506986101. Price: $14.99 |
| 506986102 |
506986102 |
BUSHING Price: $14.99 |
| 506987201 |
506987201 |
BRACKET Price: $19.99 |
| 506987401 |
506987401 |
Arm Price: $10.95 |
| 506987701 |
506987701 |
BRACKET Price: $11.99 |
| 506987801 |
535469002 |
MICRO SWITCH This part replaces 506987801. Price: $24.99 |
| 506987901 |
506987901 |
Bracket Price: $6.83 |
| 506988401 |
506988401 |
TENSIONER Price: $54.99 |
| 506988501 |
588740401 |
BELT TENSIONER ARM This part replaces 506988501. Price: $14.99 |
| 506988601 |
594924101 |
Springs This part replaces 506988601. Price: $3.99 |
| 506988801 |
506988801 |
SCREW Price: $4.96 |
| 535032501 |
535469201 |
SWITCH This part replaces 535032501. Price: $12.99 |
| 535406001 |
535406001 |
BRACKET Price: $299.99 |
| 723122801 |
723122801 |
Screw Price: $1.20 |
| 725236461 |
725236461 |
SCREW Price: $2.99 |
| 725236851 |
725236851 |
Screw Price: $1.32 |
| 725245151 |
725245151 |
SCREW 8X20 Price: $4.99 |
| 725245551 |
725245551 |
SCREW Price: $3.99 |
| 725245951 |
725245951 |
SCREW Price: $4.99 |
| 725246251 |
725246251 |
SCREW Price: $4.99 |
| 725246751 |
725246751 |
Hex Bolt Price: $4.99 |
| 725249371 |
725249371 |
Screw M10x25 Price: $1.82 |
| 725250051 |
725250071 |
SCREW This part replaces 725250051. Price: $2.99 |
| 731231001 |
731231001 |
NUT M6M M3 Price: $2.99 |
| 731231801 |
731231801 |
NUT Price: $3.99 |
| 731232001 |
731232001 |
Nut Price: $3.99 |
| 731232051 |
731232001 |
Nut This part replaces 731232051. Price: $3.99 |
| 732211401 |
732211401 |
LOCKNUT M5 Price: $2.99 |
| 732211801 |
732211801 |
LOCKNUT M8 Price: $3.99 |
| 734112401 |
734112401 |
WASHER BRB 3.2X7 Price: $2.99 |
| 734115341 |
734115341 |
Washer Price: $1.20 |
| 734116401 |
734116401 |
WASHER BRB 8.4X17 Price: $5.99 |
| 734116441 |
734116441 |
SPACER Price: $3.99 |
| 735312600 |
735312600 |
RETAINING RING SGA 25 Price: $2.99 |
| 735313810 |
735313810 |
RETAINING RING Price: $2.99 |
| 735314010 |
735314010 |
CIRCLIP SGH 47 Price: $4.99 |
| 738210404 |
738210404 |
BALL BEARING 6004-2RS1 Price: $9.99 |
| 738210504 |
738210504 |
Ball Bearing 6005-2rs Price: $28.99 |
| 738211004 |
738211004 |
BALL BEARING 6010 2RS1 Price: $39.99 |
| 738881001 |
738881001 |
GREASE NIPPLE Price: $6.99 |
