| Ref | Part Number | Description |
|---|
| 1 |
587653903 |
Nuts This part replaces 539101173. Price: $3.99 |
| 2 |
539104591 |
TIRE ASM GRAY REAR Price: $190.31 |
| 3 |
539101468 |
NUT 3/4-16 HEX SLTD GR5 ZD Price: $2.99 |
| 4 |
539990297 |
COTTER PIN Price: $2.99 |
| 5 |
539103244 |
HUB W/SPROCKET Price: $279.99 |
| 6 |
539101465 |
KEY, #808 WOODRUFF Price: $2.99 |
| 8 |
539101332 |
HCS 1/2C X 2 3/4 Price: $4.99 |
| 9 |
539103266 |
BRAKE WELDMENT, LEFT Price: $107.18 |
| 10 |
119-8049 |
GEAR CASE AND WATER PUMP ASM This part replaces 107-7825. Price: $935.31 |
| 10 |
596134901 |
GSPH This part replaces 539990692. Price: $2.99 |
| 11 |
596029501 |
Pins This part replaces 539990365. Price: $2.99 |
| 12 |
539103255 |
MOTOR STANDOFF Price: $36.99 |
| 13 |
539990622 |
HCS 1/2C X 1 1/4 SERRATED HEAD Price: $3.99 |
| 14 |
596135601 |
GSPW NUTS This part replaces 539101331. Price: $3.99 |
| 15 |
539103273 |
BRAKE LINKAGE Price: $7.69 |
| 16 |
539101983 |
TURNBUCKLE Price: $11.99 |
| 17 |
596582601 |
Nuts This part replaces 539990196. Price: $2.99 |
| 18 |
539102796 |
SPRING Price: $3.99 |
| 19 |
539103272 |
BRAKE SWIVEL Price: $7.99 |
| 20 |
127-0425 |
PLUG This part replaces 98-9598. Price: $4.34 |
| 20 |
539103304 |
HCS 5/16C, SPECIAL Price: $8.99 |
| 21 |
596433701 |
GSPW Washers This part replaces 539990517. Price: $2.99 |
| 22 |
539103574 |
PIVOT SHAFT WELDMENT Price: $148.99 |
| 23 |
539991030 |
BUSHING 1/2 MACH Price: $0.99 |
| 24 |
539102519 |
BUSHING Price: $2.99 |
| 25 |
596583901 |
Bolts This part replaces 539990730. Price: $2.99 |
| 26 |
596583501 |
Washers This part replaces 539990613. Price: $2.99 |
| 27 |
595305901 |
Nuts This part replaces 539990546. Price: $2.99 |
| 28 |
539976526 |
GRIP Price: $2.99 |
| 29 |
539103576 |
ARM, PARK BRAKE Price: $12.99 |
| 30 |
596564801 |
Washers This part replaces 539990052. Price: $1.99 |
| 30 |
99-3450 |
PLUG Price: $3.37 |
| 31 |
597338501 |
Washers This part replaces 539990598. Price: $12.99 |
| 32 |
596582501 |
Bolts This part replaces 539990072. Price: $2.99 |
| 40 |
98-9544 |
SPRING Price: $0.94 |
| 50 |
98-9543 |
SEAT-VALVE Price: $26.61 |
| 60 |
98-9380 |
BALL Price: $0.84 |
| 70 |
99-3451 |
PLUG-PACKING Price: $2.13 |
| 110 |
98-9540 |
OIL PUMP ROTOR ASM Price: $271.67 |
| 120 |
105-3708 |
COVER-PUMP, OIL Price: $18.70 |
| 130 |
98-9592 |
SCREW Price: $0.70 |
| 140 |
98-9633 |
GASKET-CASE, GEAR Price: $30.19 |
| 150 |
100-1765 |
BOLT Price: $1.59 |
| 160 |
105-3797 |
BOLT Price: $1.40 |
| 170 |
98-9356 |
BOLT Price: $2.06 |
| 180 |
98-9437 |
BOLT Price: $1.05 |
| 190 |
99-3510 |
BOLT This part replaces 98-9586. Price: $0.80 |
| 200 |
99-3511 |
BOLT Price: $5.29 |
| 210 |
105-3709 |
STUD Price: $1.13 |
| 220 |
98-7572 |
NUT Price: $0.32 |
| 230 |
98-7699 |
WASHER-SPRING Price: $0.44 |
| 240 |
119-8038 |
SEAL-OIL This part replaces 98-9482. Price: $40.16 |
| 270 |
105-3710 |
STUD Price: $1.16 |
| 280 |
107-9075 |
PLUG-FILLER, OIL Price: $7.25 |
| 290 |
99-3446 |
O-RING Price: $7.11 |
| 300 |
99-3515 |
PLUG-GEARCASE This part replaces 98-9641. Price: $9.00 |
| 310 |
108-3841 |
FILTER-OIL This part replaces 99-8384. Price: $10.81 |
| 320 |
104-5159 |
HOLDER ASM Price: $120.58 |
| 330 |
98-9727 |
COLLAR Price: $9.86 |
| 340 |
104-5155 |
SOLENOID-STOP Price: $244.96 |
| 539103265 |
539103265 |
BRAKE WELDMENT, RIGHT Price: $108.45 |
| 539103497 |
539103497 |
TIRE Price: $110.70 |
| 539104601 |
539103243 |
TIRE/WHEEL ASM WHITE-REAR 20" This part replaces 539104601. Price: $105.00 |
| 539912234 |
539912234 |
VALVE STEM TR-412 Price: $3.99 |
