| Ref | Part Number | Description |
|---|
| 1 |
119-8820 |
V-BELT Price: $48.15 |
| 2 |
323-9 |
SCREW-HH Price: $1.29 |
| 3 |
3256-24 |
WASHER-FLAT Price: $0.28 |
| 4 |
132-9420 |
PULLEY-IDLER, FLAT This part replaces 106-2175. Price: $25.16 |
| 5 |
104-8301 |
NUT-HF, NI Price: $1.09 |
| 6 |
114-8540 |
ARM-IDLER Price: $14.48 |
| 7 |
120-2229 |
WASHER Price: $1.27 |
| 8 |
114-0463 |
WASHER-FRICTION, COMPOSITE Price: $4.79 |
| 9 |
115-4986 |
SPACER Price: $1.39 |
| 10 |
110-9981 |
WASHER-PLAIN Price: $13.99 |
| 11 |
3219-6 |
NUT-HEX Price: $2.78 |
| 12 |
125-5575 |
PULLEY Price: $42.69 |
| 13 |
32144-41 |
SCREW-TAPTITE Price: $4.79 |
| 14 |
26-0671 |
SCREW-HH Price: $7.99 |
| 15 |
3290-465 |
WASHER-BELLEVILLE Price: $2.89 |
| 16 |
121-0751 |
SPINDLE ASM Price: $51.71 |
| 17 |
115-5062-03 |
BLADE-MULCH, 17.50 INCH Price: $24.06 |
| 18 |
1-603414 |
SPRING-EXTENSION Price: $13.37 |
| 19 |
138-7266 |
SPRING-RETURN, HOOK This part replaces 112-3973. Price: $2.95 |
