| Ref | Part Number | Description |
|---|
| 1 |
532421705 |
TUBE.LOWER.HANDLE.SNOW.GRAY Price: $159.99 |
| 1 |
93-8497 |
DISCONTINUED Price: Call Us |
| 2 |
3250-31 |
SCREW-PPH Price: $0.25 |
| 2 |
532443617 |
SUPPORT.WELDMENT.ROTATOR.BLACK This part replaces 532407643. Price: $24.99 |
| 2 |
921-3004 |
GASKET This part replaces 721-3004. Price: $9.36 |
| 3 |
532428867 |
BOLT.HEX.HD.WASHER.5/16-18X.75 Price: $4.99 |
| 3 |
923-3014 |
Filter, Oil This part replaces 723-3014. Price: $18.90 |
| 3 |
93-7484 |
CLUSTER-LAMP Price: $121.39 |
| 4 |
721-3005 |
O-RING Not Available Price: |
| 4 |
74-5950 |
LATCH-SWELL Price: $21.28 |
| 5 |
727-3009 |
CONNECTOR-37 DEGREE-7/8-14 Not Available Price: |
| 5 |
93-7483 |
LAMP-CLUSTER Price: $97.05 |
| 6 |
727-3027 |
TUBE ASSEMBLY Not Available Price: |
| 6 |
76-9060 |
GAUGE-TEMPERATURE Price: $110.89 |
| 7 |
710-3212 |
SCREW 1/4-20 x 2 Not Available Price: |
| 8 |
3258-166 |
SCREW-PRH Price: $0.28 |
| 8 |
936-0329 |
L-Wash. 1/4" I.D. This part replaces 736-0329. Price: $3.90 |
| 9 |
3256-1 |
WASHER-FLAT Price: $0.39 |
| 9 |
748-3038 |
ADAPTER-PUMP Not Available Price: |
| 10 |
736-0270 |
SPRING WASHER BELL Price: $3.63 |
| 10 |
99-8967 |
DECAL - CONSOLE Price: $61.13 |
| 11 |
710-3220 |
Screw, Hex Patch, 1/4-20 X 1.0 Lg GR5 Price: $3.21 |
| 11 |
94-1417-03 |
PANEL-CONTROL Price: $46.64 |
| 12 |
748-3030A |
DRIVE COUPLING Not Available Price: |
| 12 |
99-8352 |
SWITCH-BACKLAP, MASTER Price: $91.81 |
| 13 |
27-2360 |
SWITCH Price: $46.56 |
| 13 |
723-3022 |
BALL-5/8 DIA Not Available Price: |
| 14 |
32105-13 |
SCREW-HWH Price: $1.59 |
| 15 |
3296-42 |
NUT-LOCK, NI Price: $0.28 |
| 15 |
721-3025 |
O-RING 2.489 ID x .070 Not Available Price: |
| 16 |
735-3029 |
COUPLING BOOT Not Available Price: |
| 16 |
93-7587 |
BRACKET-FUSE BLOCK/PANEL Price: $19.16 |
| 17 |
32144-18 |
SCREW-HWH Price: $1.80 |
| 17 |
916-0171 |
RETAINING RING This part replaces 716-0171. Price: $5.04 |
| 18 |
120-2244 |
HOURMETER This part replaces 75-6820. Price: $48.06 |
| 18 |
736-0463 |
Washer, Flat, .25 X .62 X .052 Thk Price: $3.91 |
| 19 |
3296-2 |
NUT-LOCK, NI Price: $1.89 |
| 20 |
75-5740-03 |
BOX-CONTROL ASM Price: $261.87 |
| 21 |
321-39 |
SCREW-HH Price: $0.42 |
| 21 |
710-3221 |
SCREW 1/4-20X1.62 GR5 Not Available Price: |
| 22 |
748-3037 |
FAN NUT 1/4-20 Not Available Price: |
| 22 |
94-6349 |
DECAL-FUSES Price: $11.05 |
| 23 |
93-1268 |
DECAL-HOC SELECTOR Price: $31.62 |
| 23 |
937-3000 |
Grease Fitting This part replaces 7373000. Price: $4.04 |
| 24 |
104-4235 |
POTENTIOMETER ASM This part replaces 85-4470. Price: $260.80 |
| 24 |
703-1862 |
PLATE-COUPLING ADP Not Available Price: |
| 25 |
63-8360 |
KEY-IGNITION Price: $5.29 |
| 25 |
710-3141A |
SCREW M8 x 1.25 x 16 Not Available Price: |
| 29 |
3256-23 |
WASHER-PLAIN Price: $0.28 |
| 30 |
322-3 |
SCREW-HH Price: $0.79 |
| 31 |
98-2195 |
JOYSTICK Price: $520.10 |
| 35 |
100-8032 |
DISCONTINUED Price: Call Us |
| 39 |
2412-126 |
R-CLAMP Price: $2.51 |
| 40 |
HY3225 |
DISCONTINUED This part replaces 322-5. Price: Call Us |
| 41 |
32128-33 |
NUT-HF Price: $0.25 |
| 42 |
75-5780 |
HINGE-STEEL Price: $18.08 |
| 46 |
93-6689 |
DECAL-NO RIDERS Price: $9.75 |
| 47 |
93-8744 |
RIVET-BLIND Price: $0.75 |
| 49 |
3256-14 |
WASHER-FLAT Price: $0.39 |
| 50 |
3290-378 |
TIE-CABLE Price: $0.79 |
| 57 |
94-6343 |
DECAL-IDENTIFICATION, WIRE Price: $6.86 |
| 61 |
237-7 |
O-RING Price: $8.82 |
| 62 |
52-2900 |
WASHER-PLASTIC Price: $0.75 |
