| Ref | Part Number | Description |
|---|
| 1 |
5-1828 |
DISCONTINUED Price: Call Us |
| 1 |
532401225 |
DECK.WELDMENT.42".2GWB.GREY This part replaces 532439817. Price: $229.99 |
| 2 |
5-1530 |
DISCONTINUED Price: Call Us |
| 3 |
3296-4 |
NUT-LOCK Price: $0.25 |
| 4 |
5-1932 |
DISCONTINUED Price: Call Us |
| 5 |
11-3600 |
DISCONTINUED Price: Call Us |
| 6 |
5-3612 |
DISCONTINUED Price: Call Us |
| 6 |
532195186 |
ARM.SUSPENSION.MOWER.R Price: $8.99 |
| 7 |
3211-25 |
Screw Price: Call Us |
| 7 |
532416358 |
SCREW.#10 X 0.750.BOS (2 2) Price: $2.99 |
| 8 |
5-1787 |
DISCONTINUED Price: Call Us |
| 8 |
532193003 |
BOLT.WASHER.ASM.7/16-2 Price: $5.99 |
| 9 |
5-1788 |
DISCONTINUED Price: Call Us |
| 10 |
242-14 |
DISCONTINUED Price: Call Us |
| 11 |
5-1994 |
DISCONTINUED Price: Call Us |
| 12 |
6-8730 |
Seat Price: Call Us |
| 13 |
3-6885 |
DISCONTINUED Price: Call Us |
| 13 |
587253301 |
MANDREL.NONGREASEABLE.TALL This part replaces 532192872. Price: $32.99 |
| 14 |
32136-4 |
NUT-HEX,SLOTTED Price: $1.56 |
| 14 |
532187281 |
HOUSING.MANDREL.4PT. Price: $22.99 |
| 15 |
3272-4 |
PIN-COTTER Price: $0.25 |
| 15 |
532110485 |
BEARING Price: $7.99 |
| 16 |
3-4685 |
WASHER-TOP THRUST Price: $3.60 |
| 17 |
251-167 |
DISCONTINUED Price: Call Us |
| 18 |
302-14 |
VENT Price: $8.03 |
| 19 |
302-2 |
FITTING-GREASE Price: $1.89 |
| 19 |
532196539 |
BOLT.SHOULDER Price: $4.99 |
| 20 |
3-6886 |
DISCONTINUED Price: Call Us |
| 20 |
532159770 |
BAFFLE.VORTEX Price: $12.99 |
| 21 |
3220-6 |
NUT-JAM Price: $1.25 |
| 21 |
873800500 |
NUT.71038.31-18.HEX.NYLOCK This part replaces 873680500. Price: $2.99 |
| 22 |
329-8 |
DISCONTINUED Price: $14.39 |
| 23 |
222-1 |
DISCONTINUED Price: Call Us |
| 23 |
532192557 |
BRKT.DEFLECTOR.38"2005+ Price: $3.99 |
| 24 |
5-1830 |
DISCONTINUED Price: Call Us |
| 24 |
532105304 |
CAP-SLEEVE LT Price: $2.99 |
| 25 |
2-8569 |
DISCONTINUED Price: Call Us |
| 25 |
532197026 |
SPRING.TORSION.DEFLECT Price: $5.99 |
| 26 |
3219-1 |
NUT-HEX Price: $0.47 |
| 26 |
532110452 |
NUT PUSH M Price: $1.99 |
| 27 |
289-4 |
DISCONTINUED Price: Call Us |
| 27 |
532403004 |
SHIELD.DEFLECTOR.MOWER.42"BLAC Price: $27.99 |
| 28 |
224-1 |
DISCONTINUED Price: Call Us |
| 29 |
304-73 |
FITTING-STRAIGHT Price: $12.59 |
| 29 |
532131491 |
ROD.HINGE Price: $1.99 |
| 30 |
107-9297 |
HOSE-FUEL This part replaces 6-1190. Price: $7.29 |
| 30 |
584953901 |
BOLT.HEX.WASHR.HED.313-18X1.19 This part replaces 532173984. Price: $1.99 |
| 31 |
5-1781 |
DISCONTINUED Price: Call Us |
| 31 |
532187690 |
WASHER.SPACER.MANDREL Price: $1.99 |
| 32 |
3220-5 |
NUT-JAM Price: $0.65 |
| 32 |
532195945 |
PULLEY.MANDREL.5.438.P This part replaces 532197473. Price: $7.99 |
| 33 |
3254-4 |
WASHER-LOCK/INT Price: $0.34 |
| 33 |
532400234 |
NUT.FLANGE.LOCK.TOP Price: $3.99 |
| 34 |
283-82 |
PIN-CLEVIS This part replaces 283-23. Price: $3.94 |
| 34 |
872110612 |
BOLT.3/8-16X1.50 Price: $3.99 |
| 35 |
3-4684 |
DISCONTINUED Price: Call Us |
| 36 |
3-4683 |
DISCONTINUED Price: Call Us |
| 36 |
532196106 |
PULLEY.IDLER.2006 This part replaces 532197379. Price: $14.99 |
| 37 |
302-5 |
FITTING-GREASE Price: $0.59 |
| 37 |
819131316 |
WASHER Price: $2.99 |
| 38 |
5-1786 |
DISCONTINUED Price: Call Us |
| 38 |
532432520 |
KEEPER.BELT.MANDREL.PULLEY Price: $5.99 |
| 39 |
3-5198 |
DISCONTINUED Price: Call Us |
| 40 |
5-1785 |
DISCONTINUED Price: Call Us |
| 40 |
532409148 |
NUT.HEX.FLANGE.3/8-16.LOCKNUT This part replaces 873900600. Price: $2.99 |
| 41 |
5-1784 |
DISCONTINUED Price: Call Us |
| 42 |
3-7761 |
DISCONTINUED Price: Call Us |
| 42 |
532198410 |
SPRING.TORSION.BRAKE Price: $2.99 |
| 43 |
3211-5 |
SCREW-HH Price: $0.88 |
| 43 |
532197256 |
SRPING.TORSION.RETAINE Price: $2.99 |
| 44 |
282-4 |
SHACKLE Price: $32.98 |
| 45 |
3253-5 |
WASHER-LOCK Price: $0.29 |
| 46 |
283-14 |
PIN-CLEVIS Price: $2.92 |
| 46 |
532137729 |
SCREW.1/4-20X5/8 Price: $2.99 |
| 47 |
3219-3 |
NUT-HEX Price: $0.34 |
| 47 |
532197250 |
BRKT.CLUTCH.CABLE Price: $2.99 |
| 48 |
3211-13 |
DISCONTINUED Price: Call Us |
| 49 |
3-6750 |
DISCONTINUED Price: Call Us |
| 51 |
3253-2 |
WASHER-LOCK Price: $0.25 |
| 52 |
5-1748 |
DISCONTINUED Price: Call Us |
| 53 |
5-1783 |
DISCONTINUED Price: Call Us |
| 54 |
252-6 |
BEARING-NEEDLE Price: $10.72 |
| 55 |
5-1782 |
DISCONTINUED Price: Call Us |
| 55 |
532197249 |
IDLER.ARM Price: $3.99 |
| 56 |
532199092 |
SPACER.RETAINER Price: $3.99 |
| 57 |
3272-10 |
PIN-COTTER Price: $0.25 |
| 57 |
817000616 |
SCREW 3/8-16X1 Price: $3.99 |
| 58 |
5-1738 |
DISCONTINUED Price: Call Us |
| 59 |
5-1791 |
DISCONTINUED Price: Call Us |
| 59 |
532141043 |
GUARD, BELT Price: $3.99 |
| 60 |
3211-4 |
SCREW-HH Price: $1.02 |
| 60 |
532197402 |
ARM BRAKE MOWER This part replaces 532197261. Price: $11.99 |
| 61 |
3254-6 |
WASHER-LOCK, INTERNAL Price: $0.31 |
| 62 |
5-1801 |
DISCONTINUED Price: Call Us |
| 62 |
872110616 |
BOLT Price: $3.99 |
| 63 |
532199478 |
ARM.BRAKE.ZINC This part replaces 532199477. Price: $12.99 |
| 64 |
532199918 |
LINKAGE.BRAKE.ASM.ZINC This part replaces 532199790. Price: $12.99 |
| 67 |
532403012 |
HANDLE.CLUTCH.CABLE.LT Price: $7.99 |
| 68 |
532429636 |
BELT.DECK.DRIVE.42" Price: $32.99 |
| 69 |
872140505 |
BOLT Price: $2.99 |
| 70 |
532198332 |
CLUTCH.ASM.MANUAL.LT.TEX Price: $54.99 |
| 113 |
817000510 |
BOLT.5/16HEX.WHS.HD Price: $3.99 |
| 116 |
532004898 |
BOLT This part replaces 532124842. Price: $1.99 |
| 117 |
589527401 |
WHEEL.GAUGE.RALLY.NARROW This part replaces 532188606. Price: $2.99 |
| 118 |
873680600 |
LOCKNUT This part replaces 873930600. Price: $1.99 |
| 119 |
734117201 |
WASHER This part replaces 819121414. Price: $1.99 |
| 122 |
532197258 |
KEEPER BELT ENGINE LH Price: $9.99 |
| 123 |
532197259 |
KEEPER BELT RH Price: $9.99 |
| 144 |
532199204 |
KEEPER.BELT.MOWER Price: $3.99 |
| 145 |
532177968 |
PULLEY.IDLER.FLAT This part replaces 532193197. Price: $14.99 |
| 147 |
532401971 |
RETURN SPRING Price: $3.99 |
| 152 |
532435111 |
CABLE.CLUTCH.MANUAL. Price: $19.99 |
| 188 |
532195161 |
STUD.FASTNER.W/ANTI-ROTATE Price: $3.99 |
| 189 |
583612701 |
NUT HEX,LOCK,FLAN This part replaces 873900500. Price: $3.99 |
| 192 |
532197260 |
BRKT.BRAKE.STAND.LH. Price: $8.99 |
| 195 |
817000612 |
SCREW, 3/8-16X3/4 Price: $2.99 |
| 241 |
532152927 |
SCREW.TT.#10-32X.5.3/8.FLANGE Price: $3.99 |
| 242 |
532415598 |
PORT.WASHOUT Price: $5.99 |
| 587253301 |
MANDREL.NONGREASEABLE.TALL |
This part replaces 532192870. Price: $32.99 587253301 |
