| Ref | Part Number | Description |
|---|
| 1 |
130-2682-0P |
CHAMBER-OUTER This part replaces 130-2682-01. Price: $277.06 |
| 2 |
130-2683-0P |
CHAMBER-INNER This part replaces 130-2683-01. Price: $249.02 |
| 2 |
529845601 |
SERVICE KIT SHAFT ASM RH HANDL This part replaces 532159471. Price: $49.99 |
| 3 |
3230-18 |
SCREW-CARR Price: $4.09 |
| 3 |
532105767 |
PIN GROOVE. Price: $4.99 |
| 4 |
104-8300 |
NUT-HF, NI Price: $0.39 |
| 4 |
812000002 |
RETAINING RING LT Price: $3.99 |
| 5 |
3296-45 |
NUT-HEX Price: $3.79 |
| 5 |
819211621 |
WASHER Price: $4.99 |
| 6 |
29-4820 |
ROLLER Price: $14.88 |
| 6 |
532120183 |
BEARING.NYLON Price: $5.99 |
| 7 |
325-17 |
SCREW-HH Price: $2.90 |
| 7 |
532125631 |
GRIP HANDLE Price: $6.99 |
| 8 |
107-3154 |
NUT-PUSH Price: $0.99 |
| 8 |
532125925 |
PLUNGER BUTTON KIT This part replaces 532124526. Price: $5.99 |
| 9 |
74-5950 |
LATCH-SWELL Price: $21.28 |
| 10 |
100-5669 |
COVER-MOTOR, LH DECK Price: $139.21 |
| 11 |
100-5664-03 |
PLATE-COVER, LH Price: $73.07 |
| 11 |
532145537 |
LIFT LINK LH This part replaces 532139865. Price: $22.99 |
| 12 |
100-5667-03 |
PLATE-COVER, LH SIDE Price: $77.06 |
| 12 |
532145536 |
LIFT LINK RH This part replaces 532139866. Price: $22.99 |
| 13 |
3234-1 |
SCREW-HHF Price: $1.62 |
| 13 |
532124670 |
RETAINER-SPRNG RB Price: $5.99 |
| 14 |
1-804254 |
NUT-LOCK, HH Price: $1.29 |
| 15 |
532173288 |
LINK.SUSPENSION.FRONT Price: $11.99 |
| 16 |
596433401 |
Nuts This part replaces 873350800. Price: $2.99 |
| 17 |
3234-42 |
SCREW-HHF Price: $1.10 |
| 17 |
532175689 |
TRUNNION Price: $3.99 |
| 18 |
596135601 |
GSPW NUTS This part replaces 873800800. Price: $3.99 |
| 19 |
531165801 |
SERVICE KIT ARM ARM.REAR.SUSPE This part replaces 532139868. Price: $11.99 |
| 20 |
532003146 |
SPRING RETAINER This part replaces 532163552. Price: $2.99 |
| 23 |
532110807 |
NUT T Price: $3.99 |
| 24 |
819131016 |
WASHER Price: $2.99 |
| 25 |
532002876 |
SPRING This part replaces 532124874. Price: $3.99 |
| 26 |
596029401 |
GSPW Retainers This part replaces 532169484. Price: $3.99 |
| 27 |
532126971 |
ROD ADJ LIFT Price: $5.99 |
| 28 |
873220600 |
NUT.HEX.3/8-16UNC This part replaces 873350600. Price: $4.99 |
| 29 |
532138057 |
KNOB INF 3/8-16 Price: $6.99 |
| 30 |
532150233 |
TRUNNION Price: $9.99 |
| 31 |
532169865 |
BEARING.PIVOT.LIFT Price: $5.99 |
| 32 |
873540600 |
NUT CROWNLOCK 3/8-24 Price: $3.99 |
| 36 |
532155097 |
POINTER, HEIGHT INDICATOR(2 2) Price: $4.99 |
| 37 |
532123935 |
PLUG,HOLE Price: $4.99 |
| 38 |
593337601 |
Screws This part replaces 817060516. Price: $3.99 |
| 40 |
819112410 |
WASHER Price: $3.99 |
| 41 |
532155098 |
IND. HEIGHT STLT Price: $4.99 |
| 49 |
532409149 |
NUT.HEX.FLANGE.3/8-16.LOCKNUT This part replaces 532145212. Price: $3.99 |
| 50 |
532110452 |
NUT PUSH M Price: $2.99 |
