| Ref | Part Number | Description |
|---|
| 1 |
107-1477-01 |
ANGLE-SCRAPER Price: $185.10 |
| 1 |
532170865 |
THROTTLE.CONTROL.CABLE.BLACK This part replaces 532141359. Price: $22.99 |
| 2 |
596582501 |
Bolts This part replaces 817720410. Price: $2.99 |
| 3 |
107-1294-03 |
ROLLER ASM Price: $1,012.92 |
| 4 |
532137348 |
MUFFLER.SINGLE.B&S.10-12HP Price: $89.99 |
| 6 |
107-1358 |
BEARING-FLANGE Price: $55.67 |
| 9 |
107-1438 |
KEY-ADJUSTER, BENT Price: $12.08 |
| 10 |
107-1437-01 |
PLATE-ADJUSTER Price: $52.92 |
| 12 |
104-8301 |
NUT-HF, NI Price: $1.09 |
| 13 |
532272293 |
GASKET.ENG.1.313 ID.TIN PLATED This part replaces 532165291. Price: $8.99 |
| 14 |
119-4162 |
SCREW-CARR This part replaces 3231-25. Price: $1.73 |
| 14 |
813280324 |
Nipple Pipe 3/8 Npt X 3-1/2 Price: $3.12 |
| 15 |
3231-4 |
SCREW-CARR Price: $3.59 |
| 15 |
532428287 |
VALUE.OIL.DRAIN This part replaces 813200300. Price: $14.99 |
| 16 |
596238701 |
Washers This part replaces 811050600. Price: $3.99 |
| 23 |
531150701 |
SERVICE KIT SHIELD SHIELD.BROW This part replaces 532169837. Price: $19.99 |
| 29 |
532137180 |
KIT.SPARK ARRESTOR 794945 B&S Price: $109.99 |
| 31 |
532180645 |
GAS TANK 2GAL This part replaces 532161911. Price: $59.99 |
| 32 |
581075501 |
CAP.2.25'.VENTED.RATCHET.EPA This part replaces 532140527. Price: $22.99 |
| 33 |
532123487 |
HOSE CLAMP Price: $3.99 |
| 37 |
587044820 |
HOSE 1/4" LOW PERMEATION FUEL This part replaces 532137040. Price: $9.99 |
| 40 |
532124028 |
BUSHING.SNAP.NYL.BLK. Price: $4.99 |
| 44 |
874760412 |
BOLT.HEX.1/4.X.3/4.DICHROMATE This part replaces 817490412. Price: $3.99 |
| 45 |
817000612 |
SCREW, 3/8-16X3/4 This part replaces 817060612. Price: $3.99 |
| 62 |
596238801 |
WASHER SPRING LOCK WASHER WITH This part replaces 810040500. Price: $2.99 |
| 66 |
532127951 |
STOP THROTTLE Price: $2.52 |
| 72 |
871070510 |
Screw, Hex.Hd. Cap 5/16 - 18 x 5/8 Price: $2.66 |
| 78 |
817060620 |
SCREW.3/8-16 Price: $5.99 |
| 81 |
532050675 |
NUT.HEX..25-20.UNC This part replaces 532128861. Price: $2.99 |
