| Ref | Part Number | Description |
|---|
| 1 |
47-3560-01 |
FRONT CROSS CHANNEL ASM Price: $1,253.08 |
| 1 |
872050411 |
Bolt Rdhd. Sht. Nk 1/4-20 x 1-3/8 Price: $3.99 |
| 2 |
47-3570-01 |
REAR CROSS CHANNEL ASM Price: $1,179.36 |
| 2 |
532401042 |
SEAT.XG090.BLK.KB/BLT.NO-LOG This part replaces 532130875. Price: $149.99 |
| 3 |
3-2196-01 |
SHEAVE Price: $141.72 |
| 3 |
532195530 |
PAN.ASM.SEAT.1SLOT This part replaces 532155925. Price: $17.99 |
| 4 |
325-14 |
SCREW-HH Price: $2.64 |
| 4 |
596040501 |
Hardware This part replaces 873800500. Price: $2.99 |
| 5 |
32153-5 |
NUT-HEX Price: $1.59 |
| 5 |
587907801 |
BOLT.5/16-18X5/8.SHOULDER This part replaces 532153236. Price: $2.99 |
| 6 |
32128-23 |
NUT-HF Price: $1.51 |
| 6 |
532145006 |
PUSH CLIP Price: $2.99 |
| 7 |
3290-216 |
WASHER Price: $3.83 |
| 8 |
47-3990 |
DECAL Price: $19.68 |
| 8 |
596564401 |
Bolts This part replaces 874760616. Price: $3.99 |
| 9 |
49-8170 |
SPACER Price: $27.34 |
| 9 |
531152401 |
SERVICE KIT BRACKET SEAT PIVOT This part replaces 532140551. Price: $8.99 |
| 10 |
47-3760 |
HYD HOSE ASM Price: $146.45 |
| 10 |
532126471 |
CLIP,INSULATOR Price: $3.99 |
| 11 |
353-537 |
FITTING-ELBOW, 90 DEG Price: $12.91 |
| 11 |
596135501 |
Washers This part replaces 819133210. Price: $4.99 |
| 12 |
38-5540 |
FITTING-HYD Price: $80.14 |
| 12 |
596322601 |
Nuts This part replaces 873800600. Price: $2.99 |
| 13 |
322-13 |
SCREW-HH Price: $2.73 |
| 14 |
353-426 |
FITTING-90 DEG Price: $29.88 |
| 14 |
810040800 |
LOCKWASHER Price: $5.99 |
| 15 |
119-2859 |
FITTING-UNION Price: $31.23 |
| 15 |
819171912 |
WASHER Price: $3.99 |
| 16 |
119-2858 |
VALVE-CHECK Price: $103.69 |
| 16 |
532127018 |
BOLT,SHOULD Price: $4.99 |
| 17 |
32153-3 |
NUT-HEX, SIDE DEFORM Price: $5.59 |
| 17 |
532174648 |
BRKT.MNTNG.SWITCH.SEAT.BLACK This part replaces 532121246. Price: $8.99 |
| 18 |
47-3470-03 |
SUPPORT-VALVE Price: $79.97 |
| 18 |
586668901 |
NUT HEX_LRG FLG_1_4-20_LOCK This part replaces 532123976. Price: $3.99 |
| 19 |
104-7048 |
CAP-HOUSING Price: $5.21 |
| 19 |
532121248 |
BUSHING Price: $4.99 |
| 20 |
2412-133 |
CLAMP-R Price: $3.19 |
| 20 |
532121250 |
SPRING Price: $3.99 |
| 21 |
3256-2 |
WASHER-FLAT Price: $0.39 |
| 21 |
532134300 |
SPACER SPLIT 28X.96 Price: $3.99 |
| 22 |
322-3 |
SCREW-HH Price: $0.79 |
| 23 |
104-7050 |
TUBE-MANUAL Price: $8.76 |
| 24 |
3290-274 |
RIVET-POP Price: $0.25 |
| 25 |
47-3900 |
PLATE-INFORMATION Price: $68.97 |
| 26 |
63-8510 |
CONTROL VALVE ASM This part replaces 63-8510-03. Price: $3,602.51 |
| 27 |
52-5670 |
DISCONTINUED X-REF Price: Call Us |
| 28 |
63-8760 |
LINK PIN KIT Price: $62.78 |
| 29 |
353-988 |
PLUG-HEX Price: $10.61 |
| 30 |
3272-10 |
PIN-COTTER Price: $0.25 |
