| Ref | Part Number | Description |
|---|
| 1 |
532429203 |
FRAME.WELD.PNT.GEAR.ORANGE Price: $82.99 |
| 1 |
98-9508 |
WASHER-SHAFT, R-ARM Price: $0.47 |
| 1 |
BS-491026 |
CARBURETOR Not Available Price: |
| 2 |
532150406 |
BOLT 3/8-16X1-1/8 Price: $4.99 |
| 2 |
98-9385 |
WASHER-FLAT Price: $1.24 |
| 2 |
BS-272554S |
INTAKE GASKET Not Available This part replaces BS-270872. Price: |
| 3 |
98-9393 |
NUT Price: $2.72 |
| 3 |
BS-292681 |
VALVE Not Available Price: |
| 4 |
98-9503 |
NUT Price: $1.33 |
| 4 |
BS-691437 |
SCREW Not Available This part replaces BS-93499. Price: |
| 5 |
98-9501 |
ROCKER ARM ASM Price: $28.78 |
| 5 |
BS-91920 |
Screw, Machine Throttle Stop Price: Call Us |
| 6 |
98-9502 |
SCREW-ADJUSTING Price: $2.78 |
| 6 |
BS-93043 |
PIN-THROTTLE STOP Not Available Price: |
| 7 |
BS-230896 |
FLOAT PIN Not Available Price: |
| 8 |
105-3790 |
R-ARM SHAFT ASM This part replaces 98-9612. Price: $28.61 |
| 8 |
BS-222010 |
VALVE CHOKE Not Available Price: |
| 9 |
98-9370 |
CLIP-CIRCULAR, EXTERNAL Price: $1.30 |
| 9 |
BS-396795 |
Valve, Needle Price: Call Us |
| 10 |
98-9507 |
WASHER-SHAFT, ROCKER ARM Price: $0.85 |
| 10 |
BS-221997 |
PLUG Not Available Price: |
| 11 |
98-9505 |
BRACKET-ARM, ROCKER Price: $22.17 |
| 11 |
BS-211960 |
Venturi, Carburetor Price: Call Us |
| 12 |
98-9504 |
SPRING-ARM, ROCKER Price: $0.66 |
| 12 |
BS-222858 |
THROTTLE VALVE Not Available Price: |
| 13 |
98-9391 |
SCREW-SET, ROCKER ARM Price: $5.98 |
| 13 |
BS-491006 |
THROTTLE SHAFT Not Available Price: |
| 14 |
99-8385 |
SEAL-STEM, VALVE This part replaces 98-9496. Price: $7.29 |
| 14 |
BS-691708 |
THROTTLE STOP Not Available This part replaces BS-211712. Price: |
| 15 |
98-9648 |
SPRING-VALVE Price: $13.49 |
| 15 |
BS-299707 |
FLOAT Not Available Price: |
| 16 |
107-9092 |
RETAINER-SPRING This part replaces 98-9498. Price: $2.58 |
| 16 |
BS-394681 |
VALVE Not Available Price: |
| 17 |
117-7572 |
COLLET-SPRING, VALVE This part replaces 98-9390. Price: $9.43 |
| 17 |
BS-270511 |
GASKET Not Available Price: |
| 18 |
98-9497 |
CAP-VALVE Price: $8.36 |
| 18 |
BS-690618 |
WASHER Not Available This part replaces BS-222014. Price: |
| 19 |
98-9506 |
STUD Price: $5.98 |
| 19 |
IH-77631-C1 |
SHAFT, CHOKE LEVER Not Available Price: |
| 20 |
120-2564 |
VALVE-EXHAUST This part replaces 98-9495. Price: $34.21 |
| 20 |
BS-299740 |
NOZZLE Not Available Price: |
| 22 |
IH-77634-C1 |
CONNECTOR, FUEL PIPE Not Available Price: |
| 23 |
IH-77636-C1 |
LINK Not Available Price: |
| 24 |
BS-261116 |
SPRING Not Available Price: |
| 25 |
BS-691869 |
WASHER Not Available This part replaces BS-270382. Price: |
| 26 |
IH-77662-C1 |
Bracket, Carburetor Price: Call Us |
| 27 |
BS-26157 |
FRICTION SPRING Not Available Price: |
