| Ref | Part Number | Description |
|---|
| 1 |
583544801 |
SEAT.TH110.HUSQ.TEX.GREY This part replaces 532439709. Price: $129.99 |
| 1 |
779-3599 |
LABEL-STEERING CAPLARGE Not Available Price: |
| 1 |
80-4860 |
PIN-CLEVIS Price: $6.13 |
| 2 |
532180166 |
BRKT.PIVOT.FENDER Price: $11.99 |
| 2 |
731-3104 |
CAP-STEERI Not Available Price: |
| 2 |
75-3580 |
PLATE-SEAT Price: $213.06 |
| 3 |
712-3056 |
Nut, Hex Jam, 5/8-18 Price: $4.21 |
| 3 |
75-3530 |
SPRING-COMPRESSION Price: $31.98 |
| 4 |
3256-5 |
WASHER-FLAT Price: $0.27 |
| 4 |
736-0187 |
Washer, Flat, .640 X 1.24 X.06 Thk HDN Price: $4.02 |
| 5 |
3256-24 |
WASHER-FLAT Price: $0.28 |
| 5 |
731-3103 |
STEERING WHEEL Not Available Price: |
| 6 |
3285-19 |
PIN-GROOVE This part replaces 75-3540. Price: $1.79 |
| 6 |
596322601 |
Nuts This part replaces 873800600. Price: $2.99 |
| 6 |
936-3094 |
FLAT WASHER .755X2.0X.0 Not Available This part replaces 736-3094. Price: |
| 7 |
587613301 |
SPRING.COMPRESSION.SEAT.BLACK This part replaces 532124181. Price: $5.99 |
| 7 |
735-3028 |
STEERING SHAFT BOOT Not Available Price: |
| 7 |
75-3550 |
BUMPER-SEAT Price: $18.48 |
| 8 |
532171877 |
BOLT.5/16-18UNCX3/4 W/SEMS.BLK Price: $4.99 |
| 8 |
741-0338 |
FLANGE BEARING Price: $8.37 |
| 8 |
76-2940 |
BUMPER Price: $9.73 |
| 9 |
716-0101 |
Ring, Snap Price: $3.37 |
| 9 |
76-1920 |
SLEEVE-BEARING Price: $22.50 |
| 10 |
596768801 |
KIT.PLATE.SEAT This part replaces 532196977. Price: $49.99 |
| 10 |
66-8610 |
DISCONTINUED Price: Call Us |
| 10 |
731-3093 |
GUIDE Not Available Price: |
| 11 |
66-8560 |
NUT-PUSH Price: $5.97 |
| 11 |
731-3094 |
BUSHING-SHAFT GUIDE Not Available Price: |
| 12 |
732-3064 |
TORSION SPRING Not Available Price: |
| 12 |
76-1910 |
DISCONTINUED Price: Call Us |
| 13 |
714-0104 |
Pin, Internal Cotter Price: $3.90 |
| 13 |
82-9060 |
DISCONTINUED Price: Call Us |
| 14 |
76-1940 |
SPRING-EXTENSION Price: $66.03 |
| 14 |
911-3295 |
CLEVIS PIN Not Available This part replaces 711-3295. Price: |
| 15 |
66-9290 |
SPACER-SUSPENSION Price: $3.60 |
| 15 |
710-3013 |
Screw., Hex Cap, 1/4-20 X.50 Lg GR5 Price: $4.02 |
| 16 |
108-6703 |
ADJUSTER-SEAT This part replaces 66-8530. Price: $183.47 |
| 16 |
731-3107 |
TILT CONTROL BUTTON Not Available Price: |
| 17 |
66-8520 |
BUMPER-DOWNSTOP Price: $37.56 |
| 17 |
703-1805 |
PLATE-TILT CONTROL Not Available Price: |
| 18 |
76-1960 |
KNOB KIT This part replaces 77-2870. Price: $357.33 |
| 18 |
912-0107 |
Hex L-Nut 1/4-20 Thd This part replaces 712-0107. Price: $4.06 |
| 19 |
106-1031 |
TENSION ADJUSTER KNOB ASM This part replaces 76-1930. Price: $68.93 |
| 19 |
738-3080 |
SHAFT-UPPER STEER 16.75 LG Not Available Price: |
| 20 |
3256-46 |
WASHER-FLAT Price: $5.77 |
| 20 |
725-0157 |
Strap, Tie 1 Price: $3.46 |
| 21 |
32128-26 |
NUT-FLANGE Price: $5.89 |
| 21 |
587907801 |
BOLT.5/16-18X5/8.SHOULDER This part replaces 532171852. Price: $2.99 |
| 21 |
735-3029 |
COUPLING BOOT Not Available Price: |
| 22 |
3296-44 |
NUT-LOCK, NI Price: $2.46 |
| 22 |
748-3030A |
DRIVE COUPLING Not Available Price: |
| 23 |
723-3022 |
BALL-5/8 DIA Not Available Price: |
| 23 |
75-3480 |
FRAME-UPPER Price: $323.32 |
| 24 |
3256-26 |
WASHER-FLAT Price: $0.39 |
| 24 |
748-3029 |
HUB-DRIVE Not Available Price: |
| 25 |
3253-6 |
WASHER-LOCK Price: $0.39 |
| 25 |
721-3025 |
O-RING 2.489 ID x .070 Not Available Price: |
| 26 |
736-3092 |
Washer, Flat, .265 X 1.0 X .030 Thk HDN Price: $3.68 |
| 26 |
75-3510 |
BOLT-SHOULDER Price: $14.55 |
| 27 |
748-3033 |
ADAPTER-STEERING Not Available Price: |
| 27 |
93-3164 |
CAP Price: $11.64 |
| 28 |
710-3213 |
SCREW 1/4-20X1.12 Not Available Price: |
| 28 |
93-3163 |
SPRING Price: $26.01 |
| 29 |
93-3165 |
BRACKET Price: $37.47 |
| 30 |
322-6 |
SCREW-HH Price: $0.45 |
| 31 |
3253-33 |
WASHER-LOCK Price: $1.19 |
| 37 |
596040501 |
Hardware This part replaces 873800500. Price: $2.99 |
| 40 |
595088102 |
Handles This part replaces 532197661. Price: $4.99 |
| 41 |
532198200 |
SPRING.LATCH.SEAT.TEX Price: $3.99 |
| 43 |
874760612 |
BOLT Price: $3.99 |
| 44 |
583789501 |
WASHER.13/32x2 3/8x12GA This part replaces 819133812. Price: $4.99 |
