| Ref | Part Number | Description |
|---|
| 1 |
725-0157 |
Cable Tie This part replaces 726-3049. Price: $3.46 |
| 2 |
532149723 |
MUFFLER.TWIN.CYL.LOW.TONE Price: $39.99 |
| 2 |
727-3065A |
PICK UP LINE Not Available This part replaces 727-3065. Price: |
| 3 |
SU-2510028 |
FITTING ASSEMBLY Not Available Price: |
| 4 |
937-3022 |
Filter Nipple Fitting This part replaces 737-3022. Price: $13.32 |
| 5 |
923-3014 |
Filter, Oil This part replaces 723-3014. Price: $18.90 |
| 6 |
747-3155 |
LOWER DUMP VALVE ROD Not Available Price: |
| 7 |
732-3068 |
TORSION SPRING Not Available Price: |
| 8 |
703-2055 |
PLATE-RETAINING Not Available Price: |
| 9 |
596501502 |
Keepers This part replaces 532194320. Price: $9.99 |
| 9 |
936-0329 |
L-Wash. 1/4" I.D. This part replaces 736-0329. Price: $3.90 |
| 10 |
710-3013 |
Screw, Hex Cap, 1/4-20 x .50 Lg GR5 Price: $4.02 |
| 11 |
532414336 |
KIT.SVC.CLUTCH.ELECTRIC. This part replaces 532400008. Price: $329.99 |
| 11 |
712-0324 |
Nut, Hex Top Lock, 1/4-20 Price: $3.38 |
| 12 |
532405097 |
PULLEY.ENGINE.TUFFTORQ Price: $49.99 |
| 12 |
747-3154 |
UPPER DUMP VALVE ROD Not Available Price: |
| 13 |
720-3017 |
Knob, Ball Price: $12.87 |
| 14 |
532148456 |
TUBE, DRAIN OIL ASM. Price: $5.99 |
| 15 |
532193499 |
TANK.FUEL.4GAL Price: $69.99 |
| 15 |
936-0329 |
L-Wash. 1/4" I.D. This part replaces 736-0329. Price: $3.90 |
| 18 |
584248702 |
CAP.ASSY.FUEL.3".N-EPA.GRY.498 This part replaces 532439645. Price: $14.99 |
| 20 |
532175437 |
CONTROL.THROTTLE.BLACK This part replaces 532178385. Price: $24.99 |
| 21 |
596321701 |
Screws This part replaces 532416358. Price: $2.99 |
| 22 |
532191596 |
CONTROL.CHOKE.ERGO.PUSH-IN.BLA Price: $32.99 |
| 28 |
587044854 |
HOSE.1/4".LOW.PERM.FUEL.LN.54" This part replaces 532142158. Price: $14.99 |
| 29 |
532137180 |
KIT.SPARK ARRESTOR 794945 B&S Price: $109.99 |
| 37 |
532123487 |
HOSE CLAMP Price: $3.99 |
| 41 |
532126197 |
WASHER Price: $6.99 |
| 42 |
596238901 |
Washers This part replaces 810040700. Price: $2.99 |
| 45 |
586668901 |
NUT HEX_LRG FLG_1_4-20_LOCK This part replaces 873510400. Price: $3.99 |
| 62 |
531154901 |
SERVICE KIT HEAT SHIELD This part replaces 532434017. Price: $11.99 |
| 69 |
532178151 |
GASKET Price: $4.99 |
| 85 |
501606501 |
BOLT.HEX.7/16-20X4.GR5.1.5BLUE This part replaces 532173937. Price: $2.99 |
| 86 |
532184362 |
NUT.HEX.FLANGE.TOPLOCK Price: $3.99 |
| 87 |
537171877 |
BOLT 5/1618UNC X 3/4 W/ SEMS Price: $1.99 |
| 90 |
817000616 |
SCREW 3/8-16X1 Price: $5.99 |
| 91 |
532187495 |
BUSHING.1.375OD Price: $4.99 |
