| Ref | Part Number | Description |
|---|
| 1 |
111-4783 |
RH LIFT ARM ASM This part replaces 111-4784-01. Price: $679.09 |
| 2 |
532445962 |
MUFFLER.ASM.TWN.EXTNDED.DFLCTR Price: $54.99 |
| 4 |
119-2200 |
PAD-RUBBER, REAR HOC Price: $10.33 |
| 5 |
119-2230 |
PAD-PLASTIC, REAR HOC Price: $7.14 |
| 6 |
110-0606 |
RIVET-BLIND Price: $1.15 |
| 7 |
105-7441 |
BEARING-SPHERICAL Price: $56.85 |
| 8 |
32151-34 |
RING-RETAINING Price: $0.67 |
| 9 |
3269-26 |
WASHER-PLAIN Price: $0.99 |
| 9 |
582540302 |
KEEPER.BELT.ENG.3.25"2BOLT.PNT Price: $3.99 |
| 10 |
302-5 |
FITTING-GREASE Price: $0.59 |
| 11 |
587241601 |
CLUTCH.OGURA.5.0PD.GT1.5A-EH07 Price: $199.99 |
| 12 |
532402980 |
PULLEY.ENGINE.ENX Price: $54.99 |
| 15 |
532433007 |
TANK.ASM.FRT.2.5 GAL.W/CAP.EPA Price: $119.99 |
| 18 |
581176101 |
CAP.FUEL.2 WAY VENT Price: $34.99 |
| 20 |
587242501 |
THROTTLE.COBRA.38"READSTART.BK Price: $17.99 |
| 21 |
532416358 |
SCREW.#10 X 0.750.BOS (2 2) Price: $2.99 |
| 28 |
532401137 |
LINE.FUEL.20"FRONT.EMI Price: $9.99 |
| 29 |
532131780 |
Kit Spark Arrestor 1 25 Price: Call Us |
| 37 |
532123487 |
HOSE CLAMP Price: $3.99 |
| 41 |
532126197 |
WASHER Price: $4.99 |
| 42 |
539990247 |
WASHER 7/16 LOCK This part replaces 810040700. Price: $1.99 |
| 45 |
873680400 |
NUT.CROWNLOCK.1/4 This part replaces 873510400. Price: $2.99 |
| 62 |
532434017 |
SHIELD.HEAT.MUFFLER Price: $11.99 |
| 69 |
532165391 |
GASKET.MUFFLER Price: $9.99 |
| 70 |
532159955 |
RP.EXHAUST.TUBE.LH.BS/TWIN This part replaces 581881101. Price: $27.99 |
| 71 |
532160589 |
RP.EXHAUST.TUBE.RH.BS/TWIN This part replaces 581881001. Price: $39.99 |
| 79 |
532183906 |
SCREW.SOCKET.HEAD.5/16-18 Price: $3.99 |
| 81 |
532148456 |
TUBE, DRAIN OIL ASM. Price: $2.99 |
| 82 |
532428287 |
VALUE.OIL.DRAIN Price: $11.99 |
| 84 |
817060620 |
SCREW.3/8-16 Price: $3.99 |
| 85 |
501606601 |
BOLT.HEX.7/16-20X3.75.GR5.RED Price: $1.99 |
| 90 |
817000616 |
SCREW 3/8-16X1 Price: $3.99 |
| 96 |
819091416 |
WASHER Price: $3.99 |
| 97 |
817670412 |
SCREW HEXWSHR 1/4-20X3/4 Price: $2.99 |
| 102 |
532428867 |
BOLT.HEX.HD.WASHER.5/16-18X.75 This part replaces 817000512. Price: $2.99 |
