| Ref | Part Number | Description |
|---|
| 1 |
3220-12 |
NUT-HEX JAM LH Price: $1.83 |
| 1 |
525594701 |
FENDER, RZ 30/38 RT Price: $22.99 |
| 2 |
21-0141 |
RH BALL JOINT ASM Price: $109.12 |
| 2 |
525594702 |
FENDER, RZ 30/38 LT Price: $32.99 |
| 3 |
3255-2 |
WASHER-LOCK, EXT Price: $0.95 |
| 3 |
539101080 |
SWITCH, INTERLOCK This part replaces 532109553. Price: $14.99 |
| 4 |
532175566 |
IGNITION SWITCH This part replaces 539107541. Price: $22.99 |
| 4 |
75-7730 |
WASHER-THRUST Price: $2.88 |
| 5 |
325-6 |
SCREW-HH Price: $1.42 |
| 5 |
532176138 |
SWITCH INTERLOOK PUSH-IN Price: $19.99 |
| 6 |
302-5 |
FITTING-GREASE Price: $0.59 |
| 6 |
582042802 |
Solenoids This part replaces 532192507. Price: $22.99 |
| 7 |
539107628 |
BATTERY HOLD DOWN Price: $4.99 |
| 7 |
94-3675-01 |
FORK This part replaces 94-3675. Price: $599.80 |
| 8 |
3296-50 |
NUT-LOCK, NI Price: $2.68 |
| 8 |
532140401 |
KEY MLD GEN DELTA Price: $5.99 |
| 9 |
3256-28 |
WASHER-FLAT Price: $0.48 |
| 9 |
525598601 |
MOUNT, CONTROLS, BLK Price: $44.99 |
| 10 |
585974901 |
CABLE.THROTTLE.20" Price: $27.99 |
| 11 |
532193235 |
CABLE.CLUTCH.38".SERVICE Price: $44.99 |
| 11 |
94-5028 |
SEE PB #941 Price: Call Us |
| 12 |
3220-3 |
NUT-HJ Price: $0.28 |
| 12 |
575661501 |
ASM, CLUTCH ENGAGE W/CABLE Price: $44.99 |
| 13 |
539132624 |
KNOB - SHIFT Price: $6.99 |
| 13 |
94-5111 |
DISCONTINUED Price: Call Us |
| 14 |
539116400 |
TERMINAL COVER-SM Price: $2.99 |
| 14 |
61-2070-03 |
TUBE-STEERING This part replaces 61-2070. Price: $89.00 |
| 15 |
251-321 |
BEARING-BALL, FLANGED Price: $22.10 |
| 15 |
576646403 |
FUEL TANK ASM SMALL Price: $169.99 |
| 16 |
302-55 |
FITTING-GREASE Price: $3.09 |
| 16 |
575018103 |
CAP 3.5IN SEALED This part replaces 575018101. Price: $27.99 |
| 17 |
532139277 |
STEM FUEL TANK This part replaces 539110432. Price: $6.99 |
| 17 |
94-5952 |
DISCONTINUED Price: Call Us |
| 18 |
579411601 |
BATTERY, 12 V 300 AMP DRY This part replaces 539102436. Price: $129.99 |
| 18 |
94-5970 |
SPACER Price: $19.14 |
| 19 |
539105245 |
RUBBER GROMMET Price: $3.99 |
| 20 |
584648201 |
GROMMET.CHECK.FUEL This part replaces 576618201. Price: $3.99 |
| 21 |
539105974 |
RUBBER GROMMET Price: $2.99 |
| 22 |
539916325 |
FUEL VALVE Price: $9.99 |
| 23 |
576618101 |
VALVE.FUEL.CHECK Price: $14.99 |
| 24 |
539912222 |
HOSE CLAMP Price: $2.99 |
| 25 |
575436501 |
CLAMP, HOSE Price: $2.99 |
| 26 |
539115736 |
HOSE 1/4 X 8 Price: $5.99 |
| 27 |
539121486 |
HOSE 1/4 X 2" Price: $2.99 |
| 28 |
574521305 |
HOSE, FUEL, 3/16" X 20" Price: $9.99 |
| 29 |
505280001 |
TIE WRAP, 8-3/8", W/CLIP Price: $2.99 |
| 30 |
539104974 |
POST.CABLE LONG Price: $27.99 |
| 31 |
586108201 |
CABLE BATTERY POS RZ This part replaces 539103306. Price: $8.99 |
| 32 |
539110068 |
BATTERY CABLE, NEGATIVE Price: $7.99 |
| 33 |
596230901 |
Screws This part replaces 539990580. Price: $2.99 |
| 34 |
596039001 |
Screws This part replaces 539976952. Price: $2.99 |
| 35 |
595901601 |
GSPW Bolts This part replaces 872140506. Price: $2.99 |
| 36 |
582735501 |
BOLT.CARRIAGE.1/4-20X3/4 This part replaces 872110406. Price: $6.99 |
| 37 |
532150177 |
BATTERY TIEDOWN KIT This part replaces 532145211. Price: $8.99 |
| 38 |
539990362 |
SCREW 1/4 X 5/8 Price: $3.99 |
| 39 |
596582301 |
Washers This part replaces 819091016. Price: $2.99 |
| 40 |
594944401 |
NUT HEXAGON FLANGE 5/16-18 ST This part replaces 539112899. Price: $5.99 |
| 41 |
539107629 |
PUSH NUT-NYLON Price: $2.99 |
| 42 |
596040801 |
Hardware This part replaces 539976977. Price: $2.99 |
