TRANSMISSION 4
Parts (58)
| Ref | Part Number | Description |
|---|---|---|
| 1 | 95-8960-0P | BRACKET-NEUTRAL This part replaces 95-8960-03. Price: $47.94 |
| 2 | 32128-43 | NUT-FLANGE Price: $0.94 |
| 3 | 3234-1 | SCREW-HHF Price: $1.62 |
| 4 | 140-6168 | NEUTRAL ARM ASM This part replaces 104-0422. Price: $115.71 |
| 5 | 3-6498 | WASHER-THRUST Price: $4.58 |
| 6 | 302-60 | FITTING-GREASE Price: $2.26 |
| 7 | 3296-29 | NUT-LOCK, NI Price: $2.09 |
| 8 | 100-4817 | SPACER-BEARING Price: $4.03 |
| 9 | 76-8640 | STUD-TRACTION Price: $23.60 |
| 10 | 33093-00 | WASHER-FLAT Price: $0.70 |
| 11 | 94-1369 | SPRING-EXTENSION Price: $12.72 |
| 12 | 3210-6 | SCREW-HH Price: $1.76 |
| 13 | 725246751 | Hex Bolt Price: $4.99 |
| 13 | 88-7200 | WASHER-FLAT Price: $2.51 |
| 14 | 120-5566 | HUB Price: $49.38 |
| 14 | 734116401 | WASHER BRB 8.4X17 Price: $5.99 |
| 15 | 32128-44 | NUT Price: $2.69 |
| 15 | 731231801 | NUT Price: $3.99 |
| 16 | 3234-5 | SCREW-HHF Price: $0.42 |
| 16 | 506987201 | BRACKET Price: $19.99 |
| 17 | 104-0464-03 | BRACKET-SUPPORT, CABLE Price: $35.63 |
| 17 | 725245951 | SCREW Price: $4.99 |
| 18 | 251-259 | BEARING-BALL Price: $13.67 |
| 18 | 725246251 | SCREW Price: $4.99 |
| 19 | 2411-41 | ROD END-BALL JOINT Price: $40.28 |
| 19 | 506599301 | CONNECTOR Price: $5.99 |
| 20 | 3296-42 | NUT-LOCK, NI Price: $0.28 |
| 20 | 731231801 | NUT Price: $3.99 |
| 21 | 3274-104 | SCREW-HSBH Price: $0.54 |
| 21 | 506987403 | ARM Price: $12.99 |
| 22 | 584288604 | Washers This part replaces 506918702. Price: $3.99 |
| 22 | 99-3556 | HOSE Price: $12.50 |
| 23 | 725245151 | SCREW 8X20 Price: $4.99 |
| 23 | 99-3594-0P | LEVER-PUMP This part replaces 99-3594-03. Price: $53.70 |
| 24 | 321-8 | SCREW-HH Price: $0.34 |
| 24 | 506987501 | ROD Price: $32.99 |
| 25 | 2844 | WASHER Price: $2.69 |
| 25 | 732211401 | LOCKNUT M5 Price: $2.99 |
| 26 | 95-3857 | SCREW-HSBH Price: $4.09 |
| 27 | 63-9750 | MOUNT Price: $18.92 |
| 28 | 3296-39 | NUT-LOCK, NI Price: $2.29 |
| 29 | 3256-22 | WASHER-FLAT Price: $0.39 |
| 29 | 506988201 | Rod Price: $12.71 |
| 30 | 506834301 | SPRING Price: $3.99 |
| 31 | 506988401 | TENSIONER Price: $54.99 |
| 32 | 588740401 | BELT TENSIONER ARM This part replaces 506988501. Price: $14.99 |
| 33 | 506946901 | PULLEY Price: $34.99 |
| 34 | 725245551 | SCREW Price: $3.99 |
| 35 | 734116441 | SPACER Price: $3.99 |
| 36 | 732211801 | LOCKNUT M8 Price: $3.99 |
| 37 | 584288604 | Washers This part replaces 506918702. Price: $3.99 |
| 38 | 725245151 | SCREW 8X20 Price: $4.99 |
| 39 | 594924101 | Springs This part replaces 506988601. Price: $3.99 |
| 40 | 725246451 | SCREW Price: $5.99 |
| 41 | 544100102 | EXPANSION TANK RIDER EXTENDED This part replaces 544100101. Price: $54.99 |
| 42 | 544121701 | BRACKET Price: $6.99 |
| 43 | 725236461 | SCREW Price: $2.99 |
| 44 | 506673301 | FUEL CAP Price: $27.99 |
