| Ref | Part Number | Description |
|---|
| 1 |
104-3554 |
SHAFT-SPINDLE Price: $67.98 |
| 1 |
31834 |
SHAFT & LEV Price: $6.54 |
| 1 |
534790302 |
Screw Price: $1.99 |
| 2 |
138-6416 |
SPACER-SPINDLE, SHAFT This part replaces 69-6950. Price: $18.44 |
| 2 |
534790300 |
Screw Price: $3.33 |
| 2 |
631767 |
SPRING This part replaces 632016. Price: $1.25 |
| 3 |
119-4775 |
SPINDLE HOUSING ASM Price: $244.67 |
| 3 |
534891302 |
Gear Box Cover Price: $1.99 |
| 3 |
631036 |
SHUTTER Price: $1.20 |
| 4 |
106-7159 |
O-RING Price: $0.99 |
| 4 |
534878402 |
Housing Set Price: $17.99 |
| 4 |
650506 |
SCREW Price: $0.87 |
| 5 |
104-3548 |
PULLEY-DRIVEN, HIGH Price: $157.35 |
| 5 |
534908801 |
Blade Ass'y.-14" Price: $3.33 |
| 5 |
534908802 |
Blade Ass'y.-17" Price: $3.33 |
| 5 |
534908803 |
Blade Ass'y.-19" Price: $3.33 |
| 5 |
534908804 |
Blade Ass'y.-22" Price: $3.33 |
| 5 |
630766 |
SPRING Price: $1.25 |
| 6 |
120-5576 |
WASHER-HARDENED Price: $3.91 |
| 6 |
534136401 |
Screw Price: $1.99 |
| 6 |
651025 |
SCREW This part replaces 650417. Price: $1.18 |
| 7 |
534812100 |
Washer Price: $1.99 |
| 7D |
31836 |
SHAFT & LEV Price: $5.21 |
| 8 |
534930201 |
Gear Box Ass'y. Price: $49.99 |
| 8 |
632042 |
SPRING Price: $3.00 |
| 9 |
31837 |
SHUTTER Price: $1.18 |
| 9 |
534934900 |
Plate Price: $0.99 |
| 10 |
534810300 |
Drive Shaft Price: $1.99 |
| 10 |
630748 |
WELCH PLUG Price: $1.17 |
| 11 |
534808400 |
Bearing Price: $1.99 |
| 11 |
631027 |
WELCH PLUG Price: $1.17 |
| 12 |
534811501 |
Impeller Fan Price: $3.33 |
| 12 |
631021B |
INLET NEEDLE KIT This part replaces 631021. Price: $4.82 |
| 13 |
534946800 |
Armature/Fan Ass'y. Price: $22.99 |
| 13 |
631022 |
CLIP Price: $1.25 |
| 14 |
534494606 |
Washer Price: $1.99 |
| 14 |
632019A |
FLOAT This part replaces 632019. Price: $5.85 |
| 15 |
534246701 |
Retaining Ring Price: $0.99 |
| 15 |
631024 |
FLOAT SHAFT Price: $1.17 |
| 16 |
534294702 |
Field Ass'y. Price: $19.99 |
| 16 |
631867 |
FLOAT BOWL Price: $2.34 |
| 17 |
534935502 |
Brush Holder/Wire Ass'y. Price: $2.20 |
| 18 |
534935501 |
Brush Holder/Wire Ass'y. Price: $2.99 |
| 19 |
534200018 |
Brush Price: $1.99 |
| 20 |
534866301 |
Lead Wire Ass'y. Price: $1.99 |
| 21 |
27110A |
GASKET This part replaces 27110. Price: $1.45 |
| 22 |
31839 |
POWER SCREW Price: $10.89 |
| 23 |
534935301 |
Switch/Wire Terminal Ass'y. Price: $3.99 |
| 23 |
630740 |
O RING Price: $1.49 |
| 24 |
534826801 |
Screw Price: $1.99 |
| 24 |
631838 |
ADJ SCREW This part replaces 631078. Price: $2.71 |
| 25 |
534811700 |
Switch Cap Price: $0.99 |
| 25 |
631028A |
GASKET This part replaces 631028. Price: $1.95 |
| 26 |
534814200 |
Groove Pin Price: $0.99 |
| 26 |
632164 |
FUEL FITTING This part replaces 631803. Price: $5.95 |
| 27 |
534817900 |
Screw Price: $3.33 |
| 27 |
631183 |
WASHER This part replaces 631971. Price: $1.25 |
| 27A |
631183 |
WASHER Price: $1.25 |
| 28 |
534805901 |
Retaining Plate-14" Price: $3.33 |
| 28 |
534805902 |
Retaining Plate-17" Price: $7.99 |
| 28 |
534805903 |
Retaining Plate-19" Price: $3.33 |
| 28 |
534805904 |
Retaining Plate-22" Price: $3.33 |
| 28 |
631184 |
WASHER Price: $1.25 |
| 29 |
534812202 |
Spacer Price: $14.99 |
| 29 |
631972 |
WASHER Price: $1.25 |
| 30 |
534805801 |
Cutting Blade-14" Price: $3.33 |
| 30 |
534805802 |
Cutting Blade-17" Price: $17.99 |
| 30 |
534805803 |
Cutting Blade-19" Price: $3.33 |
| 30 |
534805804 |
Cutting Blade-22" Price: $3.33 |
| 30 |
630738 |
SPRING Price: $1.25 |
| 31 |
534805701 |
Stationary Blade-14" Price: $17.99 |
| 31 |
534805702 |
Stationary Blade-17" Price: $19.99 |
| 31 |
534805703 |
Stationary Blade-19" Price: $3.33 |
| 31 |
534805704 |
Stationary Blade-22" Price: $3.33 |
| 31 |
630735 |
SPRING Price: $1.25 |
| 32 |
630739 |
WASHER Price: $1.25 |
