| Ref | Part Number | Description |
|---|
| 1 |
32152-10 |
LOCKNUT Price: $0.81 |
| 1 |
HG-52224 |
Shaft, Pump Input Price: $208.59 |
| 2 |
603000379 |
BLIND RIVET, PUSH TYPE Price: $2.99 |
| 2 |
HG-2000022 |
Ring, Wire Retaining Price: $3.90 |
| 3 |
603000869 |
SCREW-M8 X 1.25 30, TRI, HX F Price: $1.99 |
| 3 |
HG-2000038 |
RETAINING RING Not Available Price: |
| 4 |
603003559 |
M8-1.25X20 TAPTITE Price: $3.99 |
| 4 |
HG-2000023 |
Spacer Price: $7.16 |
| 5 |
HG-2000032 |
BALL BEARING Not Available Price: |
| 6 |
603003432 |
BOLT, M10 X 1.50 X 110 BLACK Price: $5.99 |
| 6 |
HG-51092 |
Seal, Lip Price: $14.01 |
| 7 |
603001174 |
WASHER HARD, M10 Price: $2.99 |
| 7 |
HG-2000037 |
LIP SEAL Not Available Price: |
| 8 |
603001300 |
NUT FLG M10 X 1.5 MECH DEF Price: $2.99 |
| 8 |
HG-2000014 |
ARM-TRUNNION Not Available Price: |
| 9 |
603003433 |
WELDMENT, DASH, FRONT Price: $999.99 |
| 9 |
HG-2000015 |
Guide, Slot Price: $19.97 |
| 10 |
603003434 |
BKT, COLUMN, STEERING Price: $99.99 |
| 10 |
HG-2510096 |
HOUSING ASSEMBLY Not Available Price: |
| 11 |
531308405 |
WELDMENT, FRT, BASE, ROPS, RH Price: $129.99 |
| 11 |
HG-50552P |
THRUST BEARING Not Available This part replaces HG-50552. Price: |
| 12 |
531308404 |
WELDMENT, FRT, BASE, ROPS, LH Price: $129.99 |
| 12 |
HG-2000024 |
WASHER-BLOCK THRUS Not Available Price: |
| 13 |
603004407 |
GUARD, SPLASH, GAS INJECTION Price: $219.99 |
| 13 |
HG-2000025 |
Spring, Block Price: $3.53 |
| 14 |
HG-2510014 |
KIT-CYLINDER BLOCK Not Available Price: |
| 15 |
HG-2000007 |
MOTOR SHAFT Not Available Price: |
| 16 |
HG-70973 |
SECTION-CENTER Not Available Price: |
| 17 |
HG-50641 |
Pin Price: $5.78 |
| 18 |
HG-2000061 |
GASKET-CENTER Not Available Price: |
| 19 |
HG-50203 |
SWASHPLATE-VARIABL Not Available Price: |
| 20 |
HG-2510013 |
KIT-CYLINDER BLOCK Not Available Price: |
| 21 |
HG-70743 |
Shock Valve Price: $73.11 |
| 22 |
HG-9007314-0808 |
SCREW-SOCKET HD Not Available Price: |
