| Ref | Part Number | Description |
|---|
| 1 |
131-7784-03 |
BRACKET-COLUMN Price: $70.72 |
| 1 |
583239201 |
SEAT.TP110.BLK.PPRO.MILSCO This part replaces 532197514. Price: $129.99 |
| 2 |
131-7786 |
MOUNT-BRACKET, COLUMN Price: $42.52 |
| 2 |
532180166 |
BRKT.PIVOT.FENDER Price: $5.99 |
| 3 |
3231-21 |
SCREW-CARR Price: $0.76 |
| 3 |
532140675 |
STRAP Price: $3.99 |
| 4 |
104-8301 |
NUT-HF, NI Price: $1.09 |
| 5 |
120-3953 |
SWITCH-PADDLE, ON/OFF/ON Price: $64.08 |
| 5 |
532145006 |
PUSH CLIP Price: $2.99 |
| 6 |
873680600 |
LOCKNUT This part replaces 873800600. Price: $1.99 |
| 6 |
99-7420 |
PLUG-HOLE Price: $7.64 |
| 7 |
587613301 |
SPRING.COMPRESSION.SEAT.BLACK Price: $2.99 |
| 7 |
94-5627 |
PLUG Price: $1.22 |
| 8 |
532171877 |
BOLT, 5/16-18 X 1 3/4 Price: $3.99 |
| 8 |
701493 |
NUT-SPEED Price: $4.49 |
| 9 |
131-7785 |
COVER-COLUMN Price: $124.82 |
| 10 |
115-9830 |
SCREW-HSBH Price: $0.42 |
| 10 |
532441805 |
PAN.ASM.SEAT.SHORT.SLD.ADJ.TEX Price: $29.99 |
| 11 |
32128-17 |
NUT-LOCK, FLANGE Price: $0.25 |
| 12 |
122-0971 |
HARNESS-WIRE Price: $245.55 |
| 12 |
532199370 |
BRKT.MNT.OPC.SW.SEAT. Price: $2.99 |
| 13 |
3290-379 |
TIE-CABLE Price: $0.31 |
| 13 |
532121248 |
BUSHING Price: $3.99 |
| 14 |
122-0979 |
HARNESS-WIRE, REAR LIGHT (RH) Price: $139.59 |
| 14 |
872050412 |
BOLT.ROUND.HEAD.SQUARE.NECK Price: $3.99 |
| 15 |
122-0980 |
HARNESS-WIRE, REAR LIGHT (LH) Price: $103.07 |
| 15 |
532134300 |
SPACER SPLIT 28X.96 Price: $3.99 |
| 16 |
873680400 |
NUT.CROWNLOCK.1/4 This part replaces 532123976. Price: $2.99 |
| 16 |
99-7435 |
RELAY Price: $32.43 |
| 17 |
106-9169 |
SCREW-HWH Price: $5.20 |
| 17 |
873680400 |
NUT.CROWNLOCK.1/4 This part replaces 532123976. Price: $2.99 |
| 19 |
532199372 |
KNOB.SEAT.ADJ. Price: $4.99 |
| 21 |
587907801 |
BOLT.5/16-18X5/8.SHOULDER Price: $1.99 |
| 37 |
873800500 |
NUT.71038.31-18.HEX.NYLOCK Price: $2.99 |
