| Ref | Part Number | Description |
|---|
| 1 |
32151-46 |
RING-RETAINING Price: $8.38 |
| 1 |
521991102 |
NUT 1/2-13 HEX FLANGE NYLOK CL This part replaces 521991101. Price: $3.99 |
| 2 |
25-2500 |
SHAFT-TRUNNION Price: $191.66 |
| 2 |
581446903 |
PLATE SWING FRICTION PULL_MS Price: $9.99 |
| 3 |
25-2510 |
WASHER-FLAT Price: $2.41 |
| 3 |
581123002 |
ROD ROD,PIVOT, SWING PLATE ROD This part replaces 581123001. Price: $7.99 |
| 4 |
28-3300 |
BEARING-ROLLER Price: $137.87 |
| 4 |
581732701 |
SPACER YOKE, TORSION SPRING Price: $3.99 |
| 5 |
252-82 |
BEARING-NEEDLE This part replaces 28-3310. Price: $51.31 |
| 5 |
532193885 |
SPRING LATCH Price: $3.99 |
| 6 |
595841101 |
RETAINER RING E-RING CLEAR ZI This part replaces 812000007. Price: $1.99 |
| 6 |
92-5709 |
HOUSING-TRANSMISSION Price: $1,947.60 |
| 7 |
25-3210 |
SEAL-LIP Price: $23.14 |
| 7 |
581328401 |
PULLEY.FRICTION.DISC.COMBO Price: $24.99 |
| 8 |
28-3670 |
SHAFT-TRUNNION Price: $149.64 |
| 8 |
581454203 |
BRACKET YOKE WELDMENT_MS 479 Price: $5.99 |
| 9 |
581315301 |
SPRING TORSION DRIVE Price: $3.99 |
| 9 |
93-4133 |
SEAL-LIP Price: $37.43 |
| 10 |
251-8 |
BEARING-BALL This part replaces 28-3650. Price: $30.06 |
| 10 |
585263801 |
SPRING EXTENSION PS Price: $4.99 |
| 11 |
3257-5 |
KEY-WOODRUFF Price: $5.13 |
| 11 |
585691501 |
NUT.HEX.FLANGE.LOCK.5/16-18 Price: $2.99 |
| 12 |
28-3640 |
SHAFT-PUMP Price: $1,171.13 |
| 12 |
580756201 |
BEARING 9/16 ID. SNR Price: $5.99 |
| 13 |
25-2450 |
PLATE-SWASH, VARIABLE This part replaces 49-7820. Price: $896.81 |
| 13 |
580756102 |
RING.RETAINING.1622-2RSNR.CLER This part replaces 580756101. Price: $2.99 |
| 14 |
32121-91 |
PIN-SPRING Price: $0.81 |
| 14 |
580751301 |
WASHER FLAT.637IDX1.00ODX21GA Price: $2.99 |
| 15 |
25-2380 |
PLATE-THRUST Price: $32.89 |
| 15 |
580756601 |
PAWL.ASM.RH.SNOW Price: $14.99 |
| 16 |
48-1800 |
CYLINDER BLOCK KIT Price: $1,923.22 |
| 16 |
580756001 |
GEAR.ASM.PLANETARY Price: $64.99 |
| 17 |
46-7320 |
PLATE-VALVE, PUMP Price: $418.46 |
| 17 |
580756301 |
WASHER FLAT.59IDX1.065ODX25GA Price: $2.99 |
| 18 |
25-3300 |
BEARING-NEEDLE Price: $107.05 |
| 18 |
597412801 |
BEARING HOUSING ASSY TRUNNION This part replaces 532175344. Price: $29.99 |
| 19 |
28-3590 |
O-RING Price: $4.60 |
| 19 |
588069201 |
HUB.ASM.RUBBER WHEEL.SNO This part replaces 581090901. Price: $32.99 |
| 20 |
28-3580 |
RING-BACK UP Price: $20.88 |
| 20 |
872110506 |
BOLT.CARR.SQNK.5/16-18UNC.X3/4 Price: $3.99 |
| 21 |
28-3570 |
O-RING Price: $6.06 |
| 21 |
581091002 |
PLATE.RUBBER.WHEEL.BLACK Price: $9.99 |
| 22 |
49-7830 |
CHECK VALVE KIT Price: $311.16 |
| 22 |
597362801 |
Friction Drive This part replaces 581091101. Price: $11.99 |
| 23 |
25-2460 |
PLUG-HH Price: $37.38 |
| 23 |
586644301 |
CLIP E-RING_.500 SHAFT Price: $2.99 |
| 24 |
28-3400 |
O-RING Price: $6.67 |
| 24 |
580755101 |
ROD ROD, PAWL ROD Price: $8.99 |
| 25 |
25-2470 |
PACK-SHIM Price: $47.36 |
| 25 |
812000022 |
E-RING Price: $3.99 |
| 26 |
46-7310 |
SPRING Price: $18.78 |
| 26 |
599265201 |
HEX SHAFT SERVICE KIT This part replaces 580752401. Price: $84.99 |
| 27 |
532751153 |
NUT.LOCK.5/16-18 Price: $2.99 |
| 27 |
83-7260 |
CONE-RELIEF, CHARGE This part replaces 28-3420. Price: $50.57 |
| 28 |
285-17 |
PLUG-PIPE Price: $2.59 |
| 29 |
323-8 |
SCREW-HH Price: $1.20 |
| 30 |
28-3530 |
CAPSCREW Price: $4.00 |
| 31 |
28-3520 |
O-RING Price: $8.44 |
| 32 |
38-2680 |
PIN Price: $23.93 |
| 33 |
28-3480 |
BEARING Price: $74.83 |
| 35 |
92-1773 |
SCREW-HHF This part replaces 324-23. Price: $3.05 |
| 36 |
28-3450 |
WASHER Price: $0.25 |
| 37 |
117-6988 |
CHARGE PUMP KIT This part replaces 38-2670. Price: $1,753.04 |
| 39 |
92-5716 |
SECTION-CENTER Price: $2,472.04 |
| 40 |
125-5303 |
PLUG ASM This part replaces 92-5717. Price: $29.84 |
| 42 |
136-3219 |
PLUG ASM This part replaces 28-3440. Price: $21.54 |
| 43 |
323-10 |
SCREW-HH Price: $0.89 |
| 44 |
25-2480 |
SPRING-VALVE Price: $4.93 |
| 45 |
28-3380 |
PLATE-VALVE, MOTOR Price: $468.61 |
| 46 |
25-2430 |
PIN-DOWEL Price: $0.95 |
| 47 |
49-8200 |
SHAFT-MOTOR Price: $1,051.65 |
| 48 |
353-599 |
PIN-DOWEL This part replaces 28-3350. Price: $2.65 |
| 49 |
28-3340 |
GASKET Price: $16.81 |
