| Ref | Part Number | Description |
|---|
| 1 |
165892 |
Mower Deck Assembly, 42" Price: Call Us |
| 1 |
603-04121-0716 |
CASTER AXLE ASSEMBLY (LH) (CUB YELLOW-99) Not Available Price: |
| 2 |
603-04119-0716 |
CASTER AXLE ASSEMBLY (RH) Not Available Price: |
| 2 |
72140506 |
Bolt Price: Call Us |
| 3 |
138017 |
Bracket Asm Fr. Sway Bar 3/42 Price: Call Us |
| 3 |
603-0783-0637 |
RIGHT REAR CASTER YOKE This part replaces 603-0783-0716. Price: $145.24 |
| 4 |
165460 |
Bracket Asm Deck 42" Sway Bar Price: Call Us |
| 4 |
603-04129-0716 |
MOUNTING PLATE ASSEMBLY (CUB YELLOW-99) Not Available Price: |
| 5 |
4939M |
Retainer Spring Price: Call Us |
| 5 |
703-05192-0716 |
Bracket, Gear Box Price: Call Us |
| 6 |
178024 |
Bar Sway Deck Price: Call Us |
| 6 |
703-05180-0716 |
BRACKET (LH) CATR OUT C(CUB YELLOW-99) Not Available Price: |
| 7 |
603-04118-0716 |
Wheel Yoke, Front Price: Call Us |
| 8 |
703-3247-0716 |
Guard, Finger Price: Call Us |
| 8 |
850857 |
Bolt 3/8-24 x 1.25 Gr. 8 patched Price: Call Us |
| 9 |
10030600 |
Washer, Lock Price: Call Us |
| 9 |
703-3248-0637 |
REAR INNER BAFFLE This part replaces 703-3248-0716. Price: $138.73 |
| 10 |
140296 |
Washer, Hardened (The following Blades are available) Price: Call Us |
| 10 |
703-3272-0716 |
BELT GUARD (RH) (CUB YELLOW-99) Not Available Price: |
| 10 |
98-9621 |
OVERFLOW PIPE ASM Price: $73.29 |
| 11 |
703-3273-0716 |
BELT GUARD (LH) (CUB YELLOW-99) Not Available Price: |
| 12 |
703-3274-0716 |
COVER BRACKET (RH) (CUB YELLOW-99) Not Available Price: |
| 13 |
137645 |
Shaft Assembly, Mandrel, Vented Price: Call Us |
| 13 |
703-3275-4021 |
COVER BRACKET (RH) (CUB YELLOW 2) Not Available This part replaces 703-3275-0716. Price: |
| 14 |
128774 |
Housing, Mandrel, Vented Price: Call Us |
| 14 |
703-3276-0716 |
COVER BRACKET (LH) (CUB YELLOW-99) Not Available Price: |
| 15 |
110485X |
Bearing, Ball, Mandrel Price: Call Us |
| 15 |
703-05182-0716 |
OUTER CASTER BRACKET (RH)(CUB YELLOW-99) Not Available Price: |
| 16 |
174493 |
Stripper, Mandrel Deck Price: Call Us |
| 16 |
703-3596-0716 |
FRONT ROLLER BRACKET Not Available Price: |
| 18 |
72140505 |
Bolt, Carriage 5/16-18 x 5/8 Price: Call Us |
| 19 |
132827 |
Bolt, Shoulder Price: Call Us |
| 19 |
710-04191 |
Screw, Carriage 1/2-13 x 2.0 GR5 Price: $2.72 |
| 20 |
159770 |
Baffle, Vortex Price: Call Us |
| 20 |
710-1638 |
Screw, Carriage 1/2-13 x 4.5 GR5 Price: $10.13 |
| 20 |
98-9431 |
SCREW-BLEEDER, AIR Price: $15.04 |
| 21 |
710-1649 |
Screw, Carriage 3/8-16 x 4.50 GR5 Price: $15.07 |
| 21 |
73680500 |
Nut Price: Call Us |
| 22 |
710-3001 |
Screw, Hex Cap Lock 3/8-16 x .88 GR5 Price: $6.20 |
| 23 |
177563 |
Bracket, Deflector Mower 42" Price: Call Us |
| 23 |
710-3168 |
Carriage, Bolt 3/8-16 x 1.0 Price: $3.61 |
| 24 |
105304X |
Cap, Sleeve 80 x 112 Blk Mower Price: Call Us |
| 24 |
710-3178 |
CARRIAGE BOLT 3/8-16 x .75 Price: $3.93 |
| 25 |
123713X |
Spring, Torsion, Deflector 2 52 Price: Call Us |
| 25 |
710-3232 |
Screw, Thumb Adjust 5/16-18 x 1 Price: $8.99 |
| 26 |
110452X |
Nut, Push Phos & Oil Price: Call Us |
| 26 |
711-0415 |
Pin, Clevis, 3/8 x 1.75 Price: $4.04 |
| 27 |
130968X428 |
Shield, Defl ector 42" Blk Price: Call Us |
| 27 |
711-3314A |
Roller Pin, 1/2 x 7.31 This part replaces 711-3314. Price: $22.55 |
| 28 |
19111016 |
Washer 11/32 x 5/8 x 16 Ga. Price: Call Us |
| 28 |
912-0431 |
Nut, Hex Flange Lock, 3/8-16 This part replaces 7120431. Price: $4.29 |
| 29 |
131491 |
Rod, Hinge 42" 6 75 W/G Price: Call Us |
| 29 |
712-3083 |
Nut, Hex Nylon Lock 1/2-13 GR8 Price: $4.05 |
| 30 |
173984 |
Screw Thdrol Price: Call Us |
| 30 |
714-0115 |
Pin, Cotter 1/8 x 1.0 Price: $3.48 |
| 30 |
98-7654 |
GASKET Price: $8.84 |
| 31 |
187690 |
Washer, Spacer Mower Vented Price: Call Us |
| 31 |
714-0145 |
Pin, Internal Cotter Price: $4.42 |
| 32 |
173436 |
Pulley, Mandrel Price: Call Us |
| 32 |
726-0211 |
Nut, "U" 5/16-18 Price: $3.90 |
| 33 |
400234 |
Nut, Toplock Price: Call Us |
| 33 |
726-3045A |
Button Plug This part replaces 726-3045. Price: $4.09 |
| 34 |
72110612 |
Bolt Carr SH 3/8-16 x 1-1/2 Gr.5 Price: Call Us |
| 34 |
731-3005 |
Roller, Front Price: $26.47 |
| 35 |
731-3257 |
Deflector, Chute Price: $73.17 |
| 36 |
173438 |
Pulley, Idler, Flat Price: Call Us |
| 36 |
732-0939 |
TORSION SPRING 0.4 ID x 2.16 LG Not Available Price: |
| 37 |
734-3195A |
CASTER WHEEL ASSEMBLY This part replaces 734-3195. Price: $110.62 |
| 38 |
703-05181 |
INNER CASTER BRACKET (RH) Not Available Price: |
| 39 |
736-0208 |
Washer, Flat, .51 x 1.5 x .07 Price: $4.02 |
| 40 |
73900600 |
Nut Lock 3/8-16 Price: Call Us |
| 40 |
937-3000 |
Grease Fitting This part replaces 7373000. Price: $4.04 |
| 40 |
98-9624 |
OVERFLOW PIPE ASM Price: $5.18 |
| 41 |
941-0339 |
Flange Bearing, .754id x 1.00od x.925 This part replaces 741-0339. Price: $11.83 |
| 42 |
747-3384 |
Rod, Deflector Chute Price: $24.57 |
| 43 |
750-3222 |
Axle, Caster Wheel Price: $25.80 |
| 44 |
140088 |
Guard, Mandrel, LH Price: Call Us |
| 45 |
4497H |
Retainer Price: Call Us |
| 46 |
137729 |
Screw, Thdrol 1/4-20 x 5/8 T Price: Call Us |
| 48 |
133944 |
Washer, Hardened Price: Call Us |
| 50 |
98-7672 |
CLIP-PIPE Price: $2.58 |
| 52 |
139888 |
Bolt, Shoulder 5/16-18 unc Price: Call Us |
| 53 |
184907 |
Arm Assembly, Pad, Brake Price: Call Us |
| 54 |
178515 |
Washer, Hardened Price: Call Us |
| 55 |
108-2866 |
NOZZLE HOLDER KIT Price: $438.88 |
| 55 |
155046 |
Arm, Idler Price: Call Us |
| 56 |
122052X |
Spacer, Retainer Price: Call Us |
| 59 |
141043 |
Guard TUV Idler Price: Call Us |
| 67 |
106932X |
Knob Round Price: Call Us |
| 68 |
144959 |
V-Belt, 42" Mower Price: Call Us |
| 70 |
98-7676 |
GASKET Price: $2.73 |
| 75 |
98-7677 |
SEAL-HEAT Price: $10.17 |
| 80 |
98-9622 |
PIPE-INJECTION Price: $74.03 |
| 90 |
98-9654 |
PIPE-INJECTION Price: $76.86 |
| 100 |
98-9655 |
PIPE-INJECTION Price: $82.26 |
| 110 |
98-7682 |
CLAMP-PIPE Price: $6.37 |
| 111 |
179292 |
Bracket Asm. Whl Ga. LH Price: Call Us |
| 112 |
179293 |
Bracket Asm Whl Ga. RH Price: Call Us |
| 113 |
17000510 |
Screw 5/16-18 Price: Call Us |
| 116 |
4898H |
Bolt, Shoulder Price: Call Us |
| 117 |
188606 |
Wheel, Gauge Price: Call Us |
| 118 |
73930600 |
Nut Centerlock 3/8-16 Price: Call Us |
| 119 |
19121414 |
Washer 3/8 x 7/8 x 14 Ga. Price: Call Us |
| 120 |
98-7683 |
CLAMP-PIPE Price: $3.66 |
| 130 |
98-9364 |
SCREW (WITH WASHER) Price: $0.32 |
| 140 |
98-9623 |
PLUG-GLOW Price: $93.76 |
| 142 |
165890 |
Arm Spring Brake Mower Price: Call Us |
| 143 |
157109 |
Bracket Arm Idler 42" Price: Call Us |
| 144 |
173441 |
Keeper Belt 42" Clutch Cable Price: Call Us |
| 145 |
173437 |
Pulley Idler Flat Price: Call Us |
| 146 |
173443 |
Bolt Carriage Idler Price: Call Us |
| 147 |
131335 |
Spring Extension Price: Call Us |
| 148 |
169022 |
Spring Return Idler Price: Call Us |
| 149 |
165898 |
Retainer Spring Yellow Price: Call Us |
| 150 |
19091210 |
Washer 9/32 x 3/4 x 10 Ga. Price: Call Us |
| 150 |
98-9631 |
CORD-PLUG, GLOW Price: $12.41 |
| 152 |
169676 |
Clutch Cable 42" Price: Call Us |
| 158 |
17720408 |
Screw Hex Thd Cut 1/4-20 x 1/2 Price: Call Us |
| 159 |
72140614 |
Bolt Rdhd Sqn 3/8-16 unc x 1-3/4 Price: Call Us |
| 184 |
19131410 |
Washer 13/32 x 7/8 x 10 Ga. Price: Call Us |
| 185 |
188234 |
Head Asm Cable Clutch Price: Call Us |
