| Ref | Part Number | Description |
|---|
| 1 |
302-2 |
FITTING-GREASE Price: $1.89 |
| 2 |
3213-1 |
SCREW-HH Price: $1.42 |
| 2 |
530036577 |
Muffler Cover Price: $2.99 |
| 3 |
3253-27 |
WASHER-LOCK Price: $2.24 |
| 3 |
530053500 |
Muffler Baffle-Exit Price: $0.99 |
| 4 |
3272-11 |
PIN-COTTER Price: $0.99 |
| 4 |
530053499 |
Muffler Baffle-First Price: $1.99 |
| 5 |
32-0700 |
DISCONTINUED Price: Call Us |
| 5 |
530036578 |
Muffler Body Price: $2.99 |
| 6 |
32-2940 |
DISCONTINUED Price: Call Us |
| 6 |
530016386 |
SCREW This part replaces 530015810. Price: $5.99 |
| 7 |
31-7710 |
DISCONTINUED Price: Call Us |
| 7 |
530015934 |
Screw Price: $1.99 |
| 8 |
3290-355 |
PIN-HAIR Price: $2.09 |
| 8 |
530016197 |
Muffler Spring Old Style Price: $1.99 |
| 8 |
530042088 |
Muffler Spring New Style Price: $1.99 |
| 9 |
31-3470 |
DISCONTINUED Price: Call Us |
| 9 |
530032125 |
Inner Bearing Price: $11.99 |
| 10 |
32-0390 |
DISCONTINUED Price: Call Us |
| 10 |
530015945 |
Retaining Ring-C'case Price: $1.99 |
| 11 |
283-5 |
PIN-CLEVIS Price: $11.99 |
| 11 |
530019179 |
C'case Seal Price: $2.99 |
| 12 |
32-0980 |
DISCONTINUED Price: Call Us |
| 12 |
530032124 |
Outer Bearing Price: $4.99 |
| 13 |
30-3450 |
DISCONTINUED Price: Call Us |
| 13 |
530012416 |
Cylinder This part replaces 530069757. Price: $17.99 |
| 14 |
353-679 |
DISCONTINUED Price: Call Us |
| 14 |
503235112 |
Spark Plug This part replaces 952030201. Price: $5.99 |
| 15 |
31-1020 |
DISCONTINUED Price: Call Us |
| 15 |
530015953 |
Screw Price: $1.99 |
| 16 |
30-3440 |
DISCONTINUED Price: Call Us |
| 16 |
530019243 |
Gasket-Cyl/Carb Adpt Price: $1.99 |
| 17 |
253-77 |
DISCONTINUED This part replaces 30-8390. Price: Call Us |
| 17 |
530071250 |
Kit-Carb. Adaptor Price: $5.99 |
| 18 |
32-8230 |
DISCONTINUED Price: Call Us |
| 18 |
530016014 |
Screw Price: $1.99 |
| 19 |
30-8720 |
DISCONTINUED Price: Call Us |
| 19 |
530037326 |
Choke Plate Price: $1.99 |
| 20 |
30-9870 |
DISCONTINUED Price: Call Us |
| 20 |
530038102 |
Choke Shutter Price: $1.99 |
| 21 |
3256-8 |
WASHER-FLAT Price: $1.09 |
| 21 |
530038874 |
Assy-Purge Bulb Price: $5.99 |
| 22 |
3221-6 |
Hex Nut Price: Call Us |
| 22 |
530015780 |
Screw Price: $1.99 |
| 23 |
3272-21 |
PIN-COTTER Price: $3.09 |
| 23 |
530015254 |
Washer Price: $1.99 |
| 24 |
30-8430 |
DISCONTINUED Price: Call Us |
| 24 |
530015849 |
Screw Price: $1.99 |
| 25 |
530037331 |
Air Filter Foam Price: $1.99 |
| 26 |
530037292 |
Air Filter Cover Price: $1.99 |
| 27 |
530015957 |
Screw Price: $1.99 |
| 28 |
530015887 |
Screw Price: $1.99 |
| 29 |
530015852 |
Choke Spacer Price: $1.99 |
| 30 |
53007413 |
Filter Plate Price: Call Us |
| 31 |
530037969 |
Air Box Price: $3.99 |
| 33 |
530035421 |
Gasket-Carburetor Price: $1.99 |
| 35 |
545154009 |
PISTON RING This part replaces 530012472. Price: $1.99 |
| 36 |
530015162 |
Piston Pin Retainer Price: $1.99 |
| 38 |
530019223 |
Gasket-Cylinder Price: $1.99 |
| 39 |
530036145 |
Spacer-Ign. Module Price: $1.99 |
| 40 |
530039163 |
Ignition Module Price: $34.99 |
| 41 |
530015954 |
Screw Price: $1.99 |
| 42 |
530014663 |
Assy-Lead Wire Old Style (type 1) Price: $5.99 |
| 42 |
530047278 |
Assy-Lead Wire New Style (type 2) Price: $4.99 |
| 43 |
581425901 |
SWITCH, GROUND WIRE This part replaces 530014662. Price: $1.99 |
| 44 |
530015149 |
Washer Price: $1.99 |
| 45 |
530037705 |
Spacer-Flywheel Price: $5.99 |
| 46 |
530016080 |
Screw Price: $1.99 |
| 47 |
530071786 |
STARTER PULLEY KIT This part replaces 530069400. Price: $3.99 |
| 48 |
530069232 |
Rope Kit Price: $3.99 |
| 49 |
545008010 |
STARTER SPRING This part replaces 530042085. Price: $3.99 |
| 50 |
530027569 |
Handle-Starter Price: $1.99 |
| 51 |
530049857 |
Fan Housing Old Style (type 1) Price: $12.99 |
| 51 |
530071392 |
Fan Housing New Style (type 2) Price: $14.99 |
| 52 |
530015814 |
Screw Price: $1.99 |
| 53 |
530037415 |
Assy-Throttle Cable Price: $4.99 |
| 54 |
530069572 |
Kit-Switch Price: $4.99 |
| 55 |
530027523 |
Retainer Price: $2.99 |
| 56 |
530015775 |
Screw Price: $1.99 |
| 57 |
530023817 |
Starter Spring Price: $1.99 |
| 58 |
545221701 |
FLYWHEEL ASSY This part replaces 530069886. Price: $8.99 |
| 59 |
530015941 |
Retainer (C'shaft) Price: $1.99 |
| 61 |
530014861 |
Assy-Crankcase Old Style Price: $37.77 |
| 61 |
530071627 |
Assy-Crankcase This part replaces 530012414. Price: $17.99 |
| 62 |
530036792 |
Isolator-Crankcase Price: $4.99 |
| 63 |
530014864 |
Assy-Crankshaft Price: $14.99 |
| 64 |
530019181 |
Gasket-C'case/Shroud Old Style Price: $1.99 |
| 64 |
530054624 |
Gasket-C'case/Shroud New Style Price: $1.99 |
| 65 |
530036793 |
Isolator-Shroud Price: $5.99 |
| 66 |
530049233 |
Shroud Price: $3.33 |
| 67 |
530054536 |
Guard-Muffler Price: $1.99 |
| 68 |
530049413 |
Assy-Fuel Tank Price: $14.99 |
| 69 |
530069599 |
Kit-Fuel Line Price: $4.99 |
| 70 |
530095646 |
Assy-Fuel Pickup Price: $2.99 |
| 72 |
530014347 |
Assy-Fuel Cap Price: $4.99 |
| 73 |
530069380 |
Kit-Spark Arrestor Old Style Price: $3.99 |
| 73 |
530071391 |
Kit-Spark Arrestor New Style Price: $7.99 |
| 74 |
530015611 |
Washer-Clutch Price: $1.99 |
| 75 |
530069491 |
Assy-Clutch Price: $7.99 |
| 76 |
530626605 |
Nut Price: $1.99 |
| 77 |
530014923 |
Assy-Clutch Hsg. Price: $22.99 |
| 78 |
530015768 |
Locknut Price: $1.99 |
| 79 |
530015886 |
Screw Price: $1.99 |
| 80 |
530015767 |
Screw Price: $1.99 |
