| Ref | Part Number | Description |
|---|
| 1 |
321-10 |
SCREW-HH Price: $1.29 |
| 2 |
321-4 |
SCREW-HH Price: $0.99 |
| 3 |
3253-3 |
WASHER-LOCK Price: $0.31 |
| 3 |
532444481 |
APPLIQUE.SUBASM.GT.HUSQ.II This part replaces 532439752. Price: $22.99 |
| 4 |
13-3710 |
WASHER Price: $3.05 |
| 5 |
3247-8 |
SCREW-SET, HSH Price: $2.78 |
| 5 |
590748811 |
DASH.UPR.GT2.SM.PTO.MC.HR.498 This part replaces 532437480. Price: $44.99 |
| 6 |
3218-3 |
NUT-JAM Price: $0.25 |
| 7 |
13-7700 |
HUB-ASM *R Price: $595.54 |
| 8 |
3296-8 |
NUT-HEX Price: $1.29 |
| 9 |
56-6230 |
BEARING-ROLLER This part replaces 251-244. Price: $72.34 |
| 10 |
13-2840 |
KEY-SQUARE Price: $1.40 |
| 12 |
13-7560 |
SHAFT WA Price: $2,466.14 |
| 13 |
13-7520 |
PLATE-END Price: $166.67 |
| 14 |
3246-2 |
SCREW-SET, HSH Price: $0.54 |
| 14 |
587483301 |
KIT.HOOD.ASM.HUSQ.GT.TEX.668 This part replaces 532441177. Price: $74.99 |
| 15 |
251-234 |
COLLAR-LOCKING Price: $17.04 |
| 16 |
3218-17 |
NUT-JAM Price: $22.60 |
| 17 |
13-7530 |
END SPACER Price: $88.31 |
| 18 |
13-7550 |
SPACER WA Price: $95.87 |
| 18 |
597247201 |
Grilles This part replaces 532440653. Price: $84.99 |
| 19 |
2710-29 |
LINK Price: $21.76 |
| 20 |
13-4580 |
CHAIN Price: $580.55 |
| 23 |
13-7740 |
SPROCKET ASSEMBLY *R Price: $484.56 |
| 24 |
13-4570-01 |
IDLER SPROCKET This part replaces 13-4570. Price: $102.29 |
| 25 |
13-7640 |
WASHER Price: $1.03 |
| 34 |
580910801 |
PLATE.ENGINE.WELDED.CHASSIS Price: $59.99 |
| 36 |
532171877 |
BOLT.5/16-18UNCX3/4 W/SEMS.BLK This part replaces 817060512. Price: $4.99 |
| 37 |
532441208 |
FENDER.PNT.TX.GT.CH/FW/DL.HUSQ Price: $219.99 |
| 52 |
596040501 |
Hardware This part replaces 873680500. Price: $2.99 |
| 58 |
532194314 |
BRKT.SUPPORT.FNDR/TANK Price: $17.99 |
| 68 |
596030701 |
Screws This part replaces 817490508. Price: $2.99 |
| 125 |
581684801 |
CLIP.FUEL.LINE Price: $2.99 |
| 130 |
596321701 |
Screws This part replaces 532416358. Price: $2.99 |
| 146 |
581857901 |
BOLT.RDHD.SHT.SQNK.3/8-16X5/8 Price: $3.99 |
| 150 |
532439774 |
AIR.DUCT.GTV.BLACK Price: $39.99 |
| 151 |
531077401 |
SERVICE KIT PIVOT BRACKET BRAC This part replaces 532436670. Price: $37.99 |
| 152 |
532439870 |
SHIELD.BROWNING.PNT.GT.V2 Price: $14.99 |
| 159 |
817000612 |
SCREW, 3/8-16X3/4 Price: $3.99 |
| 161 |
532401801 |
FUEL WINDOW This part replaces 532439929. Price: $5.99 |
| 162 |
596134101 |
Screws This part replaces 532142432. Price: $2.99 |
| 165 |
532196826 |
SUPPORT.TANK.REAR.W/TEX Price: $22.99 |
| 175 |
590607702 |
PLATE.PNT.CROSSMEMBER.HUSQ/PRE This part replaces 532196304. Price: $32.99 |
| 176 |
532400776 |
SCREW.#10-24X5/8.RN.QU Price: $4.99 |
| 177 |
532195227 |
BUSHING, STEERING Price: $5.99 |
| 180 |
582033001 |
KITS.WELD.CHASSIS.195477X431 This part replaces 532195477. Price: $249.99 |
| 182 |
532406859 |
DASH.LOWER.COMMON.12V.ADAPTOR Price: $84.99 |
| 183 |
595305701 |
Screws This part replaces 874520520. Price: $3.99 |
| 189 |
532428867 |
BOLT.HEX.HD.WASHER.5/16-18X.75 This part replaces 817000512. Price: $4.99 |
| 191 |
532437455 |
INSERT.REFLECTIVE.RH.HUSQ.GTII Price: $14.99 |
| 194 |
596135701 |
GSPW Nuts This part replaces 873900500. Price: $2.99 |
| 196 |
532439716 |
SUBASM.CONSOLE.HUSQ.GT.DECKLFT Price: $69.99 |
| 199 |
532198259 |
PLATE.DECK.LIFT.HUSQVARNA.GT Price: $17.99 |
| 213 |
596030501 |
SCREW HEXAGON HEAD SCREW 5/16- This part replaces 874760512. Price: $3.99 |
| 214 |
532199145 |
CLIP.RETAINER.TINNER. Price: $2.99 |
| 217 |
532409167 |
ROD.PIVOT.HOOD Price: $9.99 |
| 218 |
532196395 |
X-PIECE.HOOD.STOP.NON/ Price: $6.99 |
| 228 |
593824001 |
STUD.W/"D"ANTI-ROTATION This part replaces 532195161. Price: $3.99 |
| 234 |
532404742 |
BUMPER.HOOD.TEX.HUSQVARNA Price: $5.99 |
| 235 |
596564201 |
Spacers This part replaces 532406129. Price: $4.99 |
| 236 |
873930500 |
NUT.CENTERLOCK.5/16- Price: $3.99 |
| 289 |
532403571 |
PLUG.N/CRUISE.COMMON.YT/GT.BLK Price: $3.99 |
| 297 |
532437456 |
INSERT.REFLECTIVE.LH.HUSQ.GTII Price: $14.99 |
| 306 |
532409149 |
NUT.HEX.FLANGE.3/8-16.LOCKNUT This part replaces 873900600. Price: $3.99 |
| 335 |
532448204 |
COVER.LOWER.DASH.RH.BLACK Price: $24.99 |
| 336 |
532445309 |
COVER-LH.LOWER.DASH.GT2.BLACK Price: $24.99 |
| 350 |
532445143 |
CLIP.X-MAS.TREE Price: $3.99 |
