| Ref | Part Number | Description |
|---|
| 1 |
73490400 |
SUB= 146525 Price: Call Us |
| 1 |
92-8562 |
HOOK-RESTRAINT, BOOM Price: $68.40 |
| 1 |
IH-54001-DX |
Guard Assy, PTO Shaft Price: Call Us |
| 2 |
19091016 |
WASHER Price: Call Us |
| 2 |
92-8561 |
HOSE-HOLD IN Price: $18.31 |
| 3 |
102476X |
SUB= 150109 Price: Call Us |
| 3 |
92-8563 |
SPRING Price: $19.69 |
| 3 |
IH-126107-C2 |
SEAL Not Available This part replaces IH-126107-C1. Price: |
| 4 |
72240460 |
BOLT Price: Call Us |
| 4 |
92-8564 |
KNOB Price: $11.17 |
| 4 |
IH-387302-R1 |
Retainer, PTO Shaft Oil Seal & Brg Price: Call Us |
| 5 |
None |
Pin, Cover Lower Dowel |
| 5 |
227J |
SUB= 123899X Price: Call Us |
| 5 |
32153-5 |
NUT-HEX This part replaces 22-15-AJFD. Price: $1.59 |
| 6 |
92-8534 |
DISCONTINUED Price: Call Us |
| 6 |
IH-273359 |
FITTING Not Available Price: |
| 7 |
110858X |
HARNESS YTH Price: Call Us |
| 7 |
3256-6 |
WASHER-FLAT This part replaces 24-13-AD. Price: $0.34 |
| 8 |
42223-03 |
WEDGE TUBE ASM This part replaces 42223. Price: $99.98 |
| 8 |
IH-357215-R1 |
Pin, Cover Upper Dowel Price: Call Us |
| 9 |
4171R |
CLIP T Price: Call Us |
| 9 |
92-3672 |
ANGLE-UPPER CROSS Price: $58.08 |
| 9 |
IH-387301-R11 |
Plate Assy, Transmission Rear Cover Price: Call Us |
| 10 |
110859X |
HARNESS T Price: Call Us |
| 10 |
325-6 |
SCREW-HH This part replaces 20-87-AGD. Price: $1.42 |
| 10 |
IH-350837-R3 |
GASKET This part replaces IH-350837-R2. Price: $25.86 |
| 11 |
325-5 |
SCREW-HH This part replaces 20-86-AGD. Price: $1.20 |
| 11 |
7662J |
SUB= 4152J Price: Call Us |
| 11 |
IH-368433-R91 |
SHAFT W/RING Not Available Price: |
| 12 |
100541K |
SUB= 7697J Price: Call Us |
| 12 |
42217-03 |
RH BOOM MOUNT ASM This part replaces 42217. Price: $209.28 |
| 12 |
941-3037 |
Bearing, Ball This part replaces 741-0360. Price: $38.73 |
| 13 |
42222-03 |
LH BOOM MOUNT ASM This part replaces 42222. Price: $368.05 |
| 13 |
7192 |
J WIRE TIE Price: Call Us 7192 J |
| 13 |
IH-122791-R1 |
RING Not Available Price: |
| 14 |
104445X |
SWITCH-INTER. GT Price: Call Us |
| 14 |
92-8533-03 |
BRACKET-MOUNTING, BOOM This part replaces 92-8533. Price: $51.71 |
| 14 |
IH-351272-R2 |
RETAINER Not Available Price: |
| 15 |
3217-6 |
NUT-HEX This part replaces 22-12-AJD. Price: $1.19 |
| 15 |
4206J |
CABLE-BATTERY T Price: Call Us |
| 15 |
IH-69696D |
Ring, PTO Shaft Brg Snap Price: Call Us |
| 16 |
3256-3 |
WASHER-FLAT This part replaces 24-10-AD. Price: $0.49 |
| 16 |
4406R |
SUB= STD365402 Price: Call Us |
| 16 |
IH-351286-R2 |
CLUTCH, POWER TAKE-OFF SHIFTER Not Available Price: |
| 17 |
322-7 |
SCREW-HH This part replaces 20-28-AGD. Price: $0.89 |
| 17 |
IH-351291-R1 |
Seal, PTO Shifter Shaft Price: Call Us |
| 18 |
109788X |
SUB= 124211X Price: Call Us |
| 18 |
42711-03 |
LH BOOM SUPPORT ASM This part replaces 42711. Price: $244.45 |
| 18 |
IH-387305-R1 |
Spacer, PTO Shifter Lever Price: Call Us |
| 19 |
109434X |
KEY MOLDED Price: Call Us |
| 19 |
IH-394244-R1 |
Guide, PTO Shifter Arm Price: Call Us |
| 20 |
109081X |
SUB= 146154 Price: Call Us |
| 20 |
42707-03 |
SUPPORT BRACKET ASM This part replaces 42707. Price: $88.27 |
| 20 |
IH-394245-R91 |
Lever Assy, PTO Shifter Price: Call Us |
| 21 |
110712X |
SWITCH LT Price: Call Us |
| 21 |
3256-23 |
WASHER-PLAIN This part replaces 24-10-BD. Price: $0.28 |
| 21 |
IH-394246-R11 |
Arm Assy, PTO Shifter Price: Call Us |
| 22 |
3230-2 |
BOLT-CARR This part replaces 25-25-AGD. Price: $0.47 |
| 22 |
73680400 |
SUB= 73690400 Price: Call Us |
| 22 |
IH-617057-R1 |
Pin, 1/4 X 1 Hv Coiled Spring Price: Call Us |
| 23 |
3296-42 |
NUT-LOCK, NI This part replaces 32146-17. Price: $0.28 |
| 23 |
IH-394249-R1 |
Washer, PTO Shifter Arm Ball Price: Call Us |
| 24 |
4208J |
SUB= 4799J Price: Call Us |
| 24 |
IH-43650-D |
Spring, PTO Shifter Arm Price: Call Us |
| 25 |
None |
Washer, 11/32 X 11/16 X .065 |
| 26 |
None |
Rod, PTO Control Lever Link |
| 26 |
42282 |
EXTENSION BOOM PIPE ASSY Price: $152.55 |
| 26 |
719J |
SUB= 154336 Price: Call Us |
| 27 |
3256-4 |
WASHER-FLAT This part replaces 24-11-AD. Price: $0.28 |
| 27 |
4207J |
CABLE T Price: Call Us |
| 27 |
IH-394251-R11 |
Lever Assy, PTO Control Price: Call Us |
| 28 |
92-3749 |
FREEZE PLUG Price: $5.92 |
| 28 |
IH-394253-R1 |
BAR Not Available Price: |
| 29 |
None |
Handle Assy, Pto Control |
| 29 |
321-10 |
SCREW-HH This part replaces 20-8-AGD. Price: $1.29 |
| 30 |
17021008 |
SCREW Price: Call Us |
| 30 |
IH-382805-R1 |
Knob, PTO Shifter Handle Price: Call Us |
| 30A |
109748X |
RELAY ASSY T Price: Call Us |
| 31 |
None |
Pin, 1/8 X 7/8 Hv Coiled Spring |
| 31 |
2751R |
CLIP T Price: Call Us |
| 32 |
109596X |
HOSE CLAMP T Price: Call Us |
| 32 |
42257 |
SPACER-TUBULAR Price: $11.54 |
| 33 |
10090400 |
SUB= 10040400 Price: Call Us |
| 33 |
42199 |
BOLT Price: $36.91 |
| 34 |
106-5085-03 |
PLATE-BOOM, CENTER This part replaces 42234. Price: $19.41 |
| 34 |
73350400 |
NUT Price: Call Us |
| 35 |
74780408 |
BOLT Price: Call Us |
| 35 |
92-8420 |
CAP-BOOM Price: $1.92 |
| 36 |
40493-03 |
PIPE-BOOM, CENTER This part replaces 40493. Price: $70.39 |
| 36 |
73510400 |
NUT Price: Call Us |
| 37 |
325-10 |
SCREW-HH This part replaces 20-91-AGD. Price: $1.82 |
| 37 |
74760412 |
BOLT LT Price: Call Us |
| 38 |
603773 |
LOCKNUT This part replaces 22-13-AJFD. Price: $2.09 |
| 39 |
40494 |
CLAMP ASM Price: $26.94 |
| 39 |
73220400 |
SUB= 50675 Price: Call Us |
| 40 |
11050400 |
LOCKWASHER Price: Call Us |
| 40 |
323-6 |
SCREW-HH This part replaces 20-47-AGD. Price: $0.66 |
| 41 |
42710-03 |
RH BOOM SUPPORT ASM This part replaces 42710. Price: $244.45 |
| 42 |
3272-11 |
PIN-COTTER This part replaces 28-18-D. Price: $0.99 |
| 43 |
10040400 |
LOCKWASHER Price: Call Us |
| 43 |
42195 |
PIN-CLEVIS Price: $6.11 |
| 45 |
108824X |
FUSE HYT Price: Call Us |
| 45 |
283-83 |
PIN-CLEVIS This part replaces 42194. Price: $9.52 |
| 46 |
42240-03 |
STRUT ASM This part replaces 42240. Price: $54.18 |
| 46 |
9433R |
AMMETER T Price: Call Us |
| 47 |
301950 |
U-BOLT-SQUARE Price: $9.77 |
| 47 |
6009J |
SUB= 532131708 Price: Call Us |
| 48 |
10101000 |
SUB= 10071000 Price: Call Us |
| 48 |
3217-30 |
NUT-HEX,HEAVY This part replaces 22-17-AJD. Price: $0.98 |
| 49 |
42237 |
ADJUSTABLE CLEVIS ASM Price: $69.25 |
| 49 |
73911000 |
NUT Price: Call Us |
| 50 |
19070818 |
WASHER Price: Call Us |
| 50 |
92-0010 |
U-BOLT Price: $10.65 |
| 51 |
102501X |
SUB= 141940 Price: Call Us |
| 51 |
3256-2 |
WASHER-FLAT This part replaces 24-9-AD. Price: $0.39 |
| 52 |
235R |
CLIPT Price: Call Us |
| 53 |
11030400 |
LOCKWASHER GT Price: Call Us |
| 54 |
106315X |
SUB= 135665 Price: Call Us |
| 55 |
4021J |
SWITCH.PTO.T Price: Call Us |
| 56 |
4022J |
HEX NUT T Price: Call Us |
| 57 |
109787X |
SUB= 147626 Price: Call Us |
| 58 |
121064X |
SWITCH T Price: Call Us |
| 59 |
74641008 |
SUB= 71031008 Price: Call Us |
| 101539X |
SHEET |
INSTR LT Price: Call Us 101539X |
| 110837X |
MANUAL |
YT Price: Call Us 110837X |
