| Ref | Part Number | Description |
|---|
| 1 |
3296-29 |
NUT-LOCK, NI Price: $2.09 |
| 1 |
603000142 |
NUT, M8-1.25 HEX Price: $1.99 |
| 2 |
302-5 |
FITTING-GREASE Price: $0.59 |
| 2 |
603000579 |
SCREW, M8-125 X 22 HEX GR.8.8 Price: $2.99 |
| 3 |
131-4293 |
PIN PIVOT This part replaces 84-1350. Price: $27.48 |
| 3 |
603000184 |
LOCKWASH Price: $1.99 |
| 4 |
53-6380 |
WASHER-FLAT Price: $8.62 |
| 4 |
603000270 |
BRACKET, MUFFLER MOUNTING Price: $24.99 |
| 5 |
323-4 |
SCREW-HH Price: $1.02 |
| 5 |
603002993 |
GASKET, FE350 EXHAUST Price: $8.99 |
| 6 |
106-1007 |
PIVOT ARM KIT This part replaces 84-0800. Price: $473.97 |
| 6 |
603000431 |
CLAMP, 5" MUFFLER HOSE Price: $12.99 |
| 7 |
3218-18 |
NUT-JAM Price: $0.57 |
| 7 |
603003198 |
EXHAUST SYSTEM, FE350 Price: $499.99 |
| 8 |
60-9870 |
SCREW-HH Price: $13.81 |
| 8 |
603000065 |
WASHER, 5/16 TYPE A FLAT Price: $1.99 |
| 9 |
603000054 |
WASHER 1/4 FLAT Price: $1.99 |
| 9 |
86-2070 |
NUT Price: $17.70 |
| 10 |
603000058 |
LOCKWASHER, 1/4 HELICAL SPLIT Price: $1.99 |
| 10 |
86-2080-01 |
JOINT-BALL This part replaces 86-2080. Price: $115.96 |
| 11 |
603000072 |
LOCKWASHER, 5/16 SPLIT Price: $1.99 |
| 11 |
86-1440 |
WASHER-FLAT Price: $2.10 |
| 12 |
32128-54 |
NUT-HF Price: $5.25 |
| 13 |
86-2560-03 |
SPRING-COMP This part replaces 86-2560. Price: $48.73 |
| 14 |
86-2650 |
SPRING-SUPPORT Price: $181.88 |
| 15 |
3272-9 |
PIN-COTTER Price: $0.20 |
| 16 |
3272-5 |
PIN-COTTER Price: $1.39 |
| 17 |
86-2150 |
LOCK Price: $117.80 |
| 18 |
86-2090 |
BUSHING Price: $2.17 |
| 19 |
86-2120 |
ROLLER-LOCK Price: $25.12 |
| 20 |
283-61 |
PIN-YOKE Price: $1.56 |
| 21 |
138-8239 |
PIN-CLEVIS This part replaces 86-2130. Price: $4.34 |
| 22 |
86-2180 |
BUSHING-FLANGE Price: $0.61 |
| 23 |
94-8031 |
BOOT-SWITCH Price: $12.90 |
| 24 |
94-8029 |
NUT-SPECIAL Price: $16.56 |
| 25 |
237-7 |
O-RING Price: $8.82 |
| 26 |
94-8023 |
GUIDE-PIN, SWITCH Price: $76.87 |
| 27 |
94-8024 |
PLUNGER-SWITCH Price: $27.07 |
| 28 |
43-8600 |
SPRING-COMPRESSION Price: $3.03 |
| 29 |
92-4036 |
CAP-ROD Price: $42.90 |
| 30 |
92-4037 |
SCREW-HSH Price: $39.56 |
| 31 |
43-8610 |
GUIDE Price: $23.35 |
| 32 |
237-42 |
O-RING Price: $2.78 |
