| Ref | Part Number | Description |
|---|
| 1 |
21-0230 |
PULLEY-PTO Price: $409.71 |
| 1 |
581075501 |
CAP.FUEL.TANK.SS/SNO.EPA.DOME This part replaces 532141523. Price: $14.99 |
| 2 |
43-5630 |
YOKE-PTO Price: $80.75 |
| 2 |
532138393 |
Assembly, Dash & Fuel Tank Price: $124.58 |
| 3 |
3219-3 |
NUT-HEX Price: $0.34 |
| 3 |
532123487 |
Clamp, Hose Price: $3.99 |
| 4 |
27-7900 |
SCREW-ADJUSTING Price: $21.70 |
| 4 |
532000295 |
FUEL LINE This part replaces 532008544. Price: $5.74 |
| 5 |
3256-41 |
WASHER Price: $1.18 |
| 5 |
532008548 |
Line, Fuel Price: $2.99 |
| 6 |
43-5540 |
SHAFT-PTO Price: $846.33 |
| 6 |
873680400 |
Nut Crownlock 1/4-20 unc This part replaces 873510400. Price: $2.69 |
| 7 |
532002751 |
Clip Line Fuel 13/32 Mtg Hole This part replaces 532124996. Price: $2.42 |
| 8 |
734115201 |
WASHER - M6 This part replaces 819091216. Price: $1.99 |
| 9 |
3296-6 |
NUT-LOCK Price: $1.49 |
| 9 |
874760432 |
Bolt, Fin. Hex 1/4-20 x 1 1/2 This part replaces 874760428. Price: $3.99 |
| 10 |
21-0400-01 |
SPRING-COMPRESSION This part replaces 21-0400. Price: $20.88 |
| 10 |
819091416 |
Washer 9/32 X 7/8 X 16ga This part replaces 819091413. Price: $3.99 |
| 11 |
100-6599 |
PTO PIVOT ASM Price: $780.32 |
| 11 |
532121249 |
Spacer, Split Price: $3.99 |
| 12 |
3257-5 |
KEY-WOODRUFF Price: $5.13 |
| 12 |
532003720 |
Spring Price: $3.99 |
| 13 |
3254-7 |
WASHER-LOCK, INT Price: $4.82 |
| 13 |
532126450 |
Clip, Height Adjustment Price: $2.99 |
| 14 |
3219-7 |
NUT-HEX Price: $1.53 |
| 14 |
532126115 |
Knob, Height Stop Price: $3.99 |
| 15 |
3256-28 |
WASHER-FLAT Price: $0.48 |
| 15 |
532122023 |
Adjustment, Quadrant Height Price: $9.99 |
| 16 |
532124346 |
Nut, Self-Threading 3/16-18 Price: $3.99 |
| 16 |
92-4058-01 |
ARM PTO This part replaces 92-4058. Price: $136.94 |
| 17 |
3246-3 |
SCREW-HSH Price: $12.70 |
| 17 |
872110404 |
Bolt, Carriage 1/4-20 x 1/2 Gr. 5 Price: $3.99 |
| 18 |
43-5550 |
SHAFT-ACTUATOR, PTO Price: $143.65 |
| 18 |
532130745 |
Support Assembly, Dash Price: $23.04 |
| 19 |
43-5570-01 |
ARM-ACTUATOR This part replaces 43-5570. Price: $164.96 |
| 19 |
532134744 |
Brace, Cross Price: $9.17 |
| 20 |
251-252 |
BEARING Price: $98.35 |
| 20 |
817060408 |
Screw, Self-Tapping 1/4-20 x 1/2 Price: $3.99 |
| 21 |
32120-22 |
RING-SNAP, INTERNAL Price: $2.29 |
| 22 |
3272-22 |
PIN-COTTER Price: $0.61 |
