| Ref | Part Number | Description |
|---|
| 1 |
09290600 |
BLADE,MOWER-72"MULCH(24.5"LG) This part replaces 09254700. Price: $32.95 |
| 2 |
06400829 |
WSHR-FLT .640X1.75X.250 This part replaces 06435200. Price: $3.95 |
| 3 |
06445700 |
WSHR-BLVL .669X1.535X.138 Price: $4.45 |
| 4 |
07053400 |
BLT-HEX .50-13X1.90 GR8 BLADE Price: $37.45 |
| 5 |
06602200 |
KEY-SQ .25X1.0X.25 SAE 8630 Price: $3.45 |
| 8 |
06401110 |
WSHR, FLT .406X1.50X.245 ZCC This part replaces 00597000. Price: $3.95 |
| 9 |
415543 |
WSHR-FL-STL.50X1.25X.083 YWZC Price: Call Us |
| 10 |
05901721 |
BLT- HEX .38-16X1.00 G8ZCCEP30 This part replaces 05974500. Price: $1.95 |
| 13 |
08905900 |
ARM,IDLER PIVOT This part replaces 034120. Price: $74.45 |
| 14 |
05518400 |
BSHG-FLG .762X1.0X.580X1.48 NY This part replaces 010174. Price: $4.45 |
| 15 |
05901611 |
BLT, HEX .38-16X2.75 G5 ZCC This part replaces 05961400. Price: $3.95 |
| 16 |
07327600 |
V-IDLER, 4.00X.38 This part replaces 07325200. Price: $34.95 |
| 17 |
08329100 |
SG-COMP .085X.80X1.00 WLD36 This part replaces 020444. Price: $12.45 |
| 18 |
05901640 |
BLT,HEX .38-16X2.25 G5 ZCC This part replaces 05962900. Price: $3.95 |
| 20 |
06200317 |
BLT, RHSN .50-13X3.50 G5 ZCC This part replaces 06223000. Price: $5.45 |
| 21 |
08820500 |
SPACER .560X.750X2.437 ST This part replaces 034119. Price: $16.95 |
| 22 |
08300512 |
SPRING, EXTENSION This part replaces 08334700. Price: $15.45 |
| 23 |
06500827 |
NUT,LK-CTR .50-13 GA ZCC This part replaces 06536300. Price: $3.95 |
| 25 |
09286451 |
WMT - IDLER PIVOT ARM This part replaces 09248500. Price: $134.95 |
| 26 |
05435800 |
BRG, 1.00 X 1.12 X .75 Price: $8.45 |
| 27 |
07000031 |
BEARING, PEDESTAL This part replaces 07053100. Price: $74.45 |
| 29 |
03488200 |
BUSHING .406 X .750 X .188 This part replaces 014672. Price: $5.45 |
| 30 |
08300513 |
SPRING, EXTENSION 1.0 X 6.65 This part replaces 08335100. Price: $30.95 |
| 31 |
06200313 |
BLT, RHSN .38-16X1.00 G5 ZCC This part replaces 06223600. Price: $2.45 |
| 32 |
09248353 |
BRACKET, SPRING Price: $31.95 |
| 33 |
06500831 |
NUT-NYL .38-16 G5 ZCC This part replaces 06535800. Price: $2.95 |
| 34 |
06401139 |
WSHR- FLT .375X1.125X.065 ZCC This part replaces 06425500. Price: $2.45 |
| 36 |
03233100 |
SPACER .513X.748X.620 Price: $13.95 |
| 37 |
09217000 |
WMT, IDLER ARM GROUND DRIVE This part replaces 09217051. Price: $88.45 |
| 38 |
06200317 |
BLT, RHSN .50-13X3.50 G5 ZCC This part replaces 06225000. Price: $5.45 |
| 39 |
05901712 |
BLT, HEX .50-13X2.50 G5 ZCC This part replaces 05966600. Price: $3.45 |
| 40 |
07316700 |
IDLER-FLAT-PLY 6.75X.510 This part replaces 022063. Price: $57.45 |
| 41 |
05901724 |
BLT- HEX .38-16X1.25 G5 ZCC This part replaces 05958000. Price: $1.45 |
| 42 |
06500831 |
NUT-NYL .38-16 G5 ZCC This part replaces 06535800. Price: $2.95 |
| 43 |
06401013 |
WSHR-FLT .406X.812X.065 ZCC This part replaces 06436200. Price: $0.95 |
| 44 |
09054100 |
SPACER .380 X .625 X 1.500 Price: $17.20 |
| 08899100 |
BLADE, |
TUNG MULCH MOWER 60" Price: $39.95 08899100 |
| 09081200 |
BLADE, |
MOWER (20.50") This part replaces 09246600. Price: $25.95 09081200 |
| 09290500 |
BLADE, |
MOWER-72" (24.50" LG) This part replaces 09097100. Price: $32.95 09290500 |
| 09290600 |
BLADE,MOWER-72"MULCH(24.5"LG) |
This part replaces 09254700. Price: $32.95 09290600 |
