| Ref | Part Number | Description |
|---|
| 1 |
630983 |
Shaft Lever Assy. Price: Call Us |
| 2 |
04050-10 |
RETAINING RING, 1/2" EXT. "E" Price: Call Us |
| 2 |
630731 |
Spring, Return Price: Call Us |
| 3 |
631036 |
Shutter-Throttle Price: Call Us |
| 4 |
650506 |
Screw-Shutter Price: Call Us |
| 5 |
421239 |
STRAP, FUEL TANK Price: Call Us |
| 5 |
630766 |
Spring-Tension Price: Call Us |
| 5A |
630738 |
Spring Price: Call Us |
| 6 |
481603 |
Fuel Tank Cap This part replaces 48311. Price: Call Us |
| 6 |
650417 |
Screw-Throttle Crack Screw / Idle Speed Price: Call Us |
| 7 |
31859 |
Shaft Lever Assy., Choke Price: Call Us |
| 7 |
48292 |
PAD, RUBBER-FUEL TANK - UPPER Price: Call Us |
| 8 |
46846 |
Fuel Tank Assy. This part replaces 46174. Price: Call Us |
| 8 |
630735 |
Spring-Positioning, Choke Price: Call Us |
| 9 |
31837 |
DISCONTINUED Price: Call Us |
| 9 |
482571 |
Bushing This part replaces 48309. Price: Call Us |
| 10 |
483747 |
Ball Valve w/Screen This part replaces 48308. Price: Call Us |
| 10 |
630748 |
Plug-Welch, Idle Mixture Well Price: Call Us |
| 11 |
48059-01 |
CLAMP, FUEL HOSE Price: Call Us |
| 11 |
631027 |
Plug-Welch, Atmospheric Vent Price: Call Us |
| 12 |
483617 |
Fuel Hose, 1/4" I.D. Non-Perm (791DFI Fuel Return) This part replaces 48058. Price: Call Us |
| 13 |
48028-05 |
CABLE TIE Price: Call Us |
| 13 |
631022 |
Clip-Spring Price: Call Us |
| 14 |
631023 |
Float,Carburetor Price: Call Us |
| 16 |
04015-06 |
CAPSCREW, #10-32 X 1 SOC. HD. Price: Call Us |
| 16 |
631025 |
Bowl Drain Assy., Float (Incl. No.17) Price: Call Us |
| 17 |
27136 |
Plunger Assy., Drain (Incl. No. 18) Price: Call Us |
| 17 |
46323 |
LEVER ASSY., PUMP CONTROL -LH Price: Call Us |
| 18 |
27554 |
Gasket-Plunger, Drain Price: Call Us |
| 18 |
46324 |
LEVER ASSY., PUMP CONTROL -RH Price: Call Us |
| 19 |
27137 |
Spring, Drain Plunger Price: Call Us |
| 19 |
46439 |
BATTERY BOX KIT Price: Call Us |
| 20 |
27138 |
Retainer, Plunger Spring Price: Call Us |
| 20 |
48015 |
BATTERY Price: Call Us |
| 23 |
48099 |
PAD Price: Call Us |
| 23 |
630740 |
ORing Price: Call Us |
| 24 |
42392 |
BATTERY COVER Price: Call Us |
| 25 |
04029-01 |
WING NUT, 1/4-20 Price: Call Us |
| 26 |
423356 |
Battery Support This part replaces 45384. Price: Call Us |
| 26 |
631038 |
Fitting Fuel Inlet Price: Call Us |
| 27 |
48661 |
PAD, RUBBER Price: Call Us |
| 27 |
631039 |
Pin Price: Call Us |
| 28 |
630747 |
Plug, Cup Price: Call Us |
| 29 |
481902 |
HUB ASSY., WHEEL This part replaces 48468-05. Price: Call Us |
| 29 |
631081 |
BalI, Steel Price: Call Us |
| 30 |
481081 |
WHEEL ASSY.,(INCL. 29,31,32,34) Price: Call Us |
| 31 |
481618 |
Tire, 16 x 6.50, 4 ply This part replaces 481081-02. Price: Call Us |
| 32 |
481890 |
Rim Assy This part replaces 48004-04. Price: Call Us |
| 33 |
48679 |
HEX CASTLE NUT, 3/4-28 UNEF Price: Call Us |
| 34 |
48004-06 |
NUT, LUG Price: Call Us |
| 35 |
48205 |
PAD, RUBBER-FUEL TANK, LOWER Price: Call Us |
| 36 |
46767 |
ENGINE DECK, 16" WIDE, W/DECLS. Price: Call Us |
| 36A |
461548 |
ENG DECK W/DECAL - SWZ-L This part replaces 46768. Price: Call Us |
| 37 |
04063-15 |
KEY, 3/16 X 3/16 X .75 Price: Call Us |
| 40 |
04019-02 |
NUT, 1/4-20 SERRATED FLANGE Price: Call Us |
| 42 |
04017-18 |
CAPSCR., 5/16-18 X 1.25 SR. FLG. Price: Call Us |
| 43 |
04001-22 |
BOLT, 3/8-16 X 2-3/4" HEX HEAD Price: Call Us |
| 44 |
04017-27 |
CAPSCREW, 3/8-16 X 1" SERR. FLG. Price: Call Us |
| 47 |
04012-04 |
SETSCREW, 5/16-18 X 3/8" Price: Call Us |
| 48 |
48437 |
WHEEL MOTOR Price: Call Us |
| 49 |
482755 |
Pulley, Pump Drive Engine This part replaces 48988. Price: Call Us |
| 50 |
04063-14 |
KEY, 5.0 X 5.0 X 25MM Price: Call Us |
| 51 |
482751 |
Pulley, Pump Shaft This part replaces 48586. Price: Call Us |
| 52 |
48553 |
BELT, PUMP DRIVE Price: Call Us |
| 52A |
48587 |
BELT, PUMP DRIVE Price: Call Us |
| 53 |
461074 |
CLUTCH ASSEMBLY This part replaces 48786. Price: Call Us |
| 54 |
04041-18 |
FLAT WASHER, 7/16 Price: Call Us |
| 57 |
04001-13 |
HEX HEAD BOLT, 5/16-18 X 2.75" Price: Call Us |
| 58 |
421564 |
BACKING PLATE, CLUTCH STOP Price: Call Us |
| 59 |
48814 |
RUBBER PAD, CLUTCH STOP Price: Call Us |
| 62 |
04041-07 |
FLAT WASHER, 3/8 Price: Call Us |
| 63 |
483213 |
Pulley, Idler 4.5" This part replaces 48473. Price: Call Us |
| 65 |
04001-08 |
HEX HEAD BOLT, 5/16-18 X .75" Price: Call Us |
| 66 |
48051 |
SPRING, PUMP BELT IDLER Price: Call Us |
| 67 |
04040-14 |
FLAT WASHER, 1/4 Price: Call Us |
| 68 |
04050-02 |
RETAINING RING, 3/4 EXT. "E" Price: Call Us |
| 69 |
48114-04 |
GREASE FITTING, STR. 1/4-28 Price: Call Us |
| 70 |
45212 |
PIVOT, IDLER ARM Price: Call Us |
| 71 |
46467 |
IDLER ARM,(INCL. 69 & 84) Price: Call Us |
| 72 |
04021-10 |
NUT, 5/16-18 ELASTIC STOP Price: Call Us |
| 73 |
48030-09 |
CLAMP Price: Call Us |
| 74 |
04003-04 |
CARRAGE BOLT, 5/16-18 X 1" Price: Call Us |
| 75 |
421370 |
CLUTCH BRACKET Price: Call Us |
| 76A |
04002-01 |
METRIC HH BOLT, M8-1.25 X M30 Price: Call Us |
| 78 |
04031-09 |
LOCK WASHER, 5/16 INT. TOOTH Price: Call Us |
| 79 |
04030-03 |
LOCK WASHER, 5/16 Price: Call Us |
| 84 |
48100-05 |
BUSHING, 3/4 SINTERED Price: Call Us |
| 86 |
45283 |
SHAFT WELDMENT, RH PUMP CNTL. Price: Call Us |
| 90 |
04061-03 |
COTTER PIN, 3/32 X 1.25" Price: Call Us |
| 91 |
48029-02 |
BATTERY CABLE, 31.5" RED Price: Call Us |
| 93 |
423308 |
Battery Box This part replaces 42802. Price: Call Us |
| 94 |
48126 |
RUBBER BOOT Price: Call Us |
| 95 |
04017-16 |
CAPSCR., 5/16-18 X .75" SR. FLG. Price: Call Us |
| 96 |
48030-10 |
CABLE CLAMP, .75 ID Price: Call Us |
| 97 |
04002-07 |
METRIC H H BOLT, 8-1.25 X 10 Price: Call Us |
| 98 |
45418 |
PULLEY GUARD, 16" FRAME Price: Call Us |
| 98 |
45419 |
PULLEY GUARD, 20" FRAME Price: Call Us |
| 102 |
04041-08 |
WASHER, 3/4-.766 X 1.2 X .06 Price: Call Us |
