| Ref | Part Number | Description |
|---|
| 1 |
71673 |
PLUNGER CAP T Price: Call Us |
| 1 |
719-3002 |
Housing, Grille Price: Call Us |
| 1 |
76-7010 |
RING-RETAINING Price: $3.66 |
| 2 |
105-3331 |
SEAL-SHAFT This part replaces 94-3008. Price: $35.63 |
| 2 |
703-0008 |
GRILLE HOUSING RETAINER Not Available Price: |
| 3 |
60-6240 |
WASHER This part replaces 94-3007. Price: $15.20 |
| 4 |
703-0165 |
SCREEN, GRILLE Not Available Price: |
| 4 |
76-7000 |
RING-RETAINING Price: $7.46 |
| 4 |
8156H |
FOOT PEDAL COVER Price: Call Us |
| 5 |
76-6950 |
RACE-THRUST Price: $25.65 |
| 6 |
719-3003 |
Grille Price: Call Us |
| 6 |
76-6960 |
BEARING-THRUST Price: $23.23 |
| 6 |
76020312 |
SUB= 3145 Price: Call Us |
| 7 |
19131016 |
WASHER Price: Call Us |
| 7 |
703-0010 |
LATCH-HOOD Not Available Price: |
| 7 |
94-3004 |
SHAFT-DRIVE, SPLINED Price: $564.48 |
| 8 |
17490508 |
SCREW LT Price: Call Us |
| 8 |
750-3000 |
SPACER-325 x 437 X Not Available Price: |
| 8 |
94-3002 |
SCREW-CAP Price: $7.19 |
| 9 |
136-2366 |
BACKPLATE ASM This part replaces 95-2081. Price: $957.74 |
| 9 |
76020412 |
COTTER PIN Price: Call Us |
| 10 |
19131316 |
WASHER Price: Call Us |
| 10 |
76-6980 |
O-RING Price: $11.28 |
| 11 |
137-4286 |
SENSOR-SPEED ASM This part replaces 94-3010. Price: $634.90 |
| 12 |
139933 |
PEDAL ASM CL/BK36 Price: Call Us |
| 15 |
133332 |
PVT BRAKE ARM ASM Price: Call Us |
| 15 |
94-3003 |
PLATE-VALVE Price: $515.64 |
| 16 |
19251816 |
WASHER T Price: Call Us |
| 16 |
76-6910 |
ROTATING KIT Price: $2,143.15 |
| 17 |
12000034 |
KLIP RING Price: Call Us |
| 17 |
76-6970 |
INSERT-PLATE, CAM Price: $140.84 |
| 18 |
151332 |
SPRING ROD BRAKE Price: Call Us |
| 19 |
73350600 |
NUT Price: Call Us |
| 20 |
73800600 |
NUT Price: Call Us |
| 21 |
131460 |
SUB= 532131460 Price: Call Us |
| 22 |
144585 |
TRUNNION.LIFT. Price: Call Us |
| 24 |
19132012 |
WASHER Price: Call Us |
| 25 |
4921H |
SPRING.RETAINER Price: Call Us |
| 26 |
73930600 |
LOCKNUT Price: Call Us |
| 28 |
140776 |
LIFT ASM MOW REAR Price: Call Us |
| 29 |
72110506 |
SUB= 72270506 Price: Call Us |
| 30 |
73510500 |
NUT Price: Call Us |
| 31 |
3146R |
RETAINER.SPRING Price: Call Us |
